TRENDnet TL2 G244 - Switch
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
TRENDnet TL2 G244 - Switch
- managed
- 24 x 10/100/1000 + 4 x shared Gigabit SFP
- rack-mountable
- TAA Compliant
| Additional Details | |
|---|---|
| Mfr Part #: | TL2-G244 |
| SHI Part #: | 22519077 |
| Category: | LAN switches |
| UNSPSC: | 43222612 |
| Manufacturer: | TRENDnet |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | LAN switches |
| Description | TRENDnet TL2 G244 - Switch - managed - 24 x 10/100/1000 + 4 x shared Gigabit SFP - rack-mountable - TAA Compliant |
| Manufacturer | TRENDnet |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 21 cm |
| Dimensions & Weight / Height | 4.4 cm |
| Dimensions & Weight / Weight | 2.9 kg |
| Dimensions & Weight / Width | 44 cm |
| Header / Brand | TRENDnet |
| Networking / Form Factor | Rack-mountable |
| Networking / Ports Qty | 24 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Dimensions & Weight | |
| Depth | 21 cm |
| Height | 4.4 cm |
| Weight | 2.9 kg |
| Width | 44 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -10 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Authentication Method | RADIUS |
| Built-in Devices | LED panel |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s |
| Device Type | Switch - 24 ports - managed |
| Enclosure Type | Rack-mountable 1U |
| Features | Flow control, auto-negotiation, trunking, load balancing, VLAN support, auto-uplink (auto MDI/MDI-X), IGMP snooping, port mirroring, store and forward, Broadcast Storm Control, half duplex mode, full duplex mode, Multicast Storm Control, STP support, RSTP support, MSTP support, TFTP support, ACL support, QoS, RADIUS support, SSH support |
| Jumbo Frame Support | 10000 bytes |
| MAC Address Table Size | 8K entries |
| Ports | 24 x 10/100/1000 + 4 x shared Gigabit SFP |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH |
| Status Indicators | Port status, power, link/activity |
| Subtype | Gigabit Ethernet |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Cables Included | 1 x serial cable - 3 m |
| Compliant Standards | FCC, RoHS |
| Rack Mounting Kit | Included |
| TAA Compliant | Yes |
| Power | |
| Power Consumption Operational | 21.79 Watt |
| Power Device | Internal power supply |
| Voltage Required | AC 120/230 V (50/60 Hz) |
