Eaton Tripp Lite Series
MSRP$650.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Eaton Tripp Lite Series
- Fiber media converter
- 10GbE, 2.5GbE
- over CAT 5/5e/6/6a
- 10GBase-T, 100Base-TX, 1000Base-T, 2.5GBase-T
- SFP+ / RJ-45
- up to 80 km
- 850 nm / 1310 nm
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $650.00 |
| Mfr Part #: | N786-001-SFP |
| SHI Part #: | 50616646 |
| Category: | Transceivers |
| UNSPSC: | 43201553 |
| Manufacturer: | Eaton |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Transceivers |
| Description | Eaton Tripp Lite Series - Fiber media converter - 10GbE, 2.5GbE - over CAT 5/5e/6/6a - 10GBase-T, 100Base-TX, 1000Base-T, 2.5GBase-T - SFP+ / RJ-45 - up to 80 km - 850 nm / 1310 nm |
| Manufacturer | Eaton |
| MSRP | $650.00 |
| UNSPSC | 43201553 |
| Main Specifications | |
| Dimensions & Weight / Depth | 10.9 cm |
| Dimensions & Weight / Height | 2.34 cm |
| Dimensions & Weight / Weight | 853 g |
| Dimensions & Weight / Width | 7.37 cm |
| Header / Brand | Eaton |
| Networking / Connectivity Technology | Wired |
| Networking / Data Link Protocol |
|
| Networking / Data Transfer Rate | 10 Gbps |
| Networking / Form Factor | External |
| Networking / Type | Fiber media converter |
| Packaged Quantity | 1 |
| Service & Support / Type | 2-year warranty |
| Dimensions & Weight | |
| Depth | 10.9 cm |
| Height | 2.34 cm |
| Weight | 853 g |
| Width | 7.37 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 24 cm |
| Shipping Height | 5.99 cm |
| Shipping Width | 13 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 80% RH (non-condensing) |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Color | Black |
| Device Type | Fiber media converter |
| Form Factor | External |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Compliant Standards | Plug and Play, RoHS, GS, LPS, TUV, UL, WEEE, cUL, CAN/CSA-C22.2 No. 62368-1, FCC Part 15 Class B, IEC 62368-1, REACH, UKCA, UL 62368-1, OM3, OM4, OM5, OS2 |
| Networking | |
| Cabling Type | 10GBase-T, 100Base-TX, 1000Base-T, 2.5GBase-T |
| Compliant Standards | IEEE 802.3x |
| Connectivity Technology | Wired |
| Data Link Protocol | 10GbE, 100Mb LAN, 1GbE, 2.5GbE |
| Data Transfer Rate | 10 Gbps |
| Features | Auto-uplink (auto MDI/MDI-X), metal housing, half/full duplex mode |
| Max Transfer Distance | 80 km |
| Optical Wave Length | 850 nm / 1310 nm |
| Status Indicators | Power, link/activity, signal detect fiber, speed |
| Power | |
| Power Consumption Operational | 10 Watt |
| Power Device | External power adapter |
| Voltage Required | AC 100-240 V (50/60 Hz) |
