Hardware Networking and Security Network Security
Add to My Favorites
Network Security

FORTIWIFI-80F-2R-3G4G-DSL 8 X GE RJ45 PORTS

MSRP$4,117.00
$3,182.00
FORTIWIFI-80F-2R-3G4G-DSL 8 X GE RJ45 PORTS
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
FORTIWIFI-80F-2R-3G4G-DSL 8 X GE RJ45 PORTS
  Additional Details
Price: $3,182.00
MSRP: $4,117.00
Mfr Part #: FWF80F-2R-3G4G-DSL-P
SHI Part #: 49813090
Category: Firewall appliances
UNSPSC: 43222501
Manufacturer: Fortinet
Product Type: Hardware
General Information
CategoryFirewall appliances
DescriptionFORTIWIFI-80F-2R-3G4G-DSL 8 X GE RJ45 PORTS
ManufacturerFortinet
MSRP$4,117.00
UNSPSC43222501
Main Specifications
Height0.00
Length0.00
UPC0195875124224
Width0.00
Antenna
AntennaExternal detachable
Antenna Qty6
Communications
Cellular BandUMTS/HSPA+ B1/B2/B4/B5/B6/B8/B9/B19 / LTE B1/B2/B3/B4/B5/B7/B8/B9/B12/B13/B18/B19/B20/B26/B28/B29/B30/B32/B41/B42/B43/B46/B48/B66
Cellular ProtocolUMTS, HSPA+, LTE
Digital Signaling ProtocolADSL2, ADSL2+, VDSL2
Generation3G, 4G
Mobile Broadband AccessYes
Protocols & SpecificationsITU G.992.1 (G.DMT), ITU G.992.2 (G.Lite)
Environmental Parameters
Humidity Range Operating20 - 90% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Expansion / Connectivity
Expansion Slots2 Nano SIM card
Interfaces
  • 2 x 1000Base-T/1000Base-X - RJ-45/SFP (mini-GBIC) (WAN)
  • 6 x 1000Base-T - RJ-45
  • 2 x 1000Base-T (FortiLink) - RJ-45
  • 1 x DSL - RJ-11
  • 1 x USB 3.0 - Type A
  • 1 x console - RJ-45
  • 6 x antenna - SMA
General
Built-in DevicesDSL modem
Depth17.8 cm
Device TypeSecurity appliance
Height6 cm
LocalizationRussia, Kazakhstan
Weight1.6 kg
Width21.6 cm
Miscellaneous
Cables Included
  • 1 x network cable
  • 1 x RJ-11 cable
Compliant StandardsFCC, ICES, RCM, VCCI, BSMI, UL, cUL, CB, USGv6
Networking
Capacity
  • Concurrent TCP sessions: 1500000
  • New TCP sessions per second: 45000
  • Firewall policies: 5000
  • Gateway to gateway IPSec VPN Tunnels: 200
  • Client to gateway IPSec VPN tunnels: 2500
  • Concurrent SSL VPN users: 200
  • SSL inspection CPS: 700
  • SSL inspection concurrent sessions: 100000
  • Virtual domains: 10
  • Maximum virtual domains: 10
  • Number of FortiSwitches: 24
  • Number of FortiAP devices: 96
  • Number of FortiAP devices (tunnel): 48
  • Number of FortiToken devices: 500
Cloud-ManagedYes
Compliant StandardsIEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax
Connectivity TechnologyWireless, wired
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet, Bluetooth LE, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6)
Encryption AlgorithmSSL, 256-bit AES, 256-bit SHA, TLS 1.3
FeaturesVPN support, Trusted Platform Module (TPM), 3G/4G USB Dongle Support, SSL inspection, 3x3 MIMO technology, SD-WAN support, GNSS Bias
Form FactorDesktop / wall mountable
Framing FormatANSI T1.413
Frequency Band2.4 GHz, 5 GHz
Network / Transport ProtocolTCP/IP, UDP/IP, IPSec, HTTP, HTTPs, IPv4, IPv6
Performance
  • IPS throughput (enterprise traffic mix): 1.4 Gbps
  • NGFW throughput (enterprise traffic mix): 1 Gbps
  • Threat protection throughput (enterprise traffic mix): 900 Mbps
  • IPv4 firewall throughput (1518-byte UDP): 10 Gbps
  • IPv4 firewall throughput (512-byte UDP): 10 Gbps
  • IPv4 firewall throughput (64-byte UDP): 7 Gbps
  • Firewall latency (64-byte UDP): 3.23 µs
  • Firewall throughput: 10.5 Mpps
  • VPN throughput (512-bit IPSec): 6.5 Gbps
  • VPN throughput (SSL): 950 Mbps
  • SSL inspection throughput: 715 Mbps
  • Application control throughput: 1.8 Gbps
  • CAPWAP throughput: 9 Gbps
  • Maximum data rate (2.4 GHz): 574 Mbps
  • Maximum data rate (5 GHz): 1201 Mbps
Remote Management ProtocolHTTP, HTTPS
Status IndicatorsPower, status, WAN, SFP, HA, DSL, 3G/4G, Wi-Fi
Power
Installed Qty1
Max Supported Qty2
Power Consumption Operational28.07 Watt
Power DeviceExternal power adapter
Power RedundancyOptional
Voltage RequiredAC 100-240 V (50/60 Hz)
Processor / Memory / Storage
Hard Drive128 GB x 1
Processors Installed1 x Fortinet FortiASIC SOC4
Software / System Requirements
OS ProvidedFortiOS
