HPE 64QSFP28 P2C SW SN4600CM W/NVD PL-4R

MSRP$76,500.00
$18,809.00
HPE 64QSFP28 P2C SW SN4600CM W/NVD PL-4R
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
HPE 64QSFP28 P2C SW SN4600CM W/NVD PL-4R
  Additional Details
Price: $18,809.00
MSRP: $76,500.00
Mfr Part #: S2T80A
SHI Part #: 48469878
Category: Computer data switches
UNSPSC: 43211601
Manufacturer: HPE - STORAGE
Product Type: Hardware
Product Line: HPE - Storage
General Information
CategoryComputer data switches
DescriptionHPE 64QSFP28 P2C SW SN4600CM W/NVD PL-4R
ManufacturerHPE - STORAGE
MSRP$76,500.00
UNSPSC43211601
Main Specifications
Height17.00
Length80.00
UPC0190017701226
Width60.00
Dimensions & Weight
Depth42.8 cm
Height8.8 cm
Weight14.64 kg
Width56.85 cm
Environmental Parameters
Humidity Range Operating10 - 85% (non-condensing)
Max Operating Temperature40 °C
Max Storage Temperature70 °C
Min Operating Temperature0 °C
Min Storage Temperature-40 °C
Expansion / Connectivity
Interfaces
  • 64 x 40/100Gbit LAN QSFP28
  • 1 x USB 2.0 Type A
  • 1 x management RJ-45
  • 1 x serial RJ-45
General
Authentication MethodRADIUS, TACACS+
Built-in Devices30 GB SSD
Capacity
  • Jumbo frame size: 9216
  • Groups per system: 64
  • Packet buffer size: 64 MB
Compliant StandardsIEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.1x, IEEE 802.1s, IEEE 802.1ab (LLDP), IEEE 802.1Qbb, IEEE 802.1Qaz
Device TypeSwitch - 64 ports - L3 - managed
Enclosure TypeBack to front airflow rack-mountable 2U
FeaturesFlow control, IP-routing, VLAN support, IGMP snooping, port mirroring, store and forward, IPv6 support, WRED, VRRP support, MSTP support, DCBX support, QoS, BFD, LACP support, LLDP support, DHCP relay, VRF, port isolation, sFlow v5, cut-through, PTP, OpenFlow support, ECN, PFC, CoPP, VXLAN, MLAG, RoCE v2, OSPF, EVPN, SDN, NTP, Root Guard, Loop Guard, Voice VLAN, ToR, BPDU Filter, ERSPAN, PIM, 64MB packet buffer, BPDU Guard, Q-in-Q tunneling, SPAN mode, LAG, Rapid Convergence Spanning Tree Protocol
Jumbo Frame SupportYes
Performance
  • Switching capacity: 12.8 Tbps
  • Latency: 500 ns
  • Processing capacity: 8.4 Bpps
Ports64 x 40/100 Gigabit Ethernet QSFP28
RAM8 GB
Remote Management ProtocolSNMP 1, SNMP 2, Telnet, SNMP 3, TFTP, SSH-2, CLI, SCP, DHCP, JSON, LDAP
Routing ProtocolBGP-4, BGP, IGMP, OSPFv2, PIM-SM, PIM-SSM, ECMP, BGP-MP
Subtype100 Gigabit Ethernet
Manufacturer Warranty
Service & SupportLimited warranty - parts and labor - 3 years - on-site
Miscellaneous
Cables Included1 x DB-9 to RJ-45 adapter
Compliant StandardsEN 60950-1:2006+A11:2009+A1:2010+A12:2011+AC:2011+A2:2013, IEC 60950-1:2005 Second Edition + A1:2009 + A2:2013, EN 60950-1:2006 + A11:2009 + A1:2010 + A12:2011 + AC:2011 + A2:2013, UL 60950-1:2007 R10.14, CAN/CSA C22.2 No. 60950 -1-07+A1:2011+A2:2014, IEC 60950-1:2005 (ed.2)+A1:2009+A2:2013, LV, TR CU 020/2011, TR CU 004/2011, EMC, EN 55032:2012/AC:2013 Class A, EN 55024:2010, EN 61000-3-2:2014, EN 61000-3-3:2013, EN 61000-4-2:2002, EN 61000-4-3:2006+A1:2008+A2:2010, EN 61000-4-4:2004+A1:2010, EN 61000-4-5:2006, EN 61000-4-6:2014, EN 61000-4-11:2004, FCC CFR47 Part 15:2017 Sub-part B:2019 Class A, ICES-003 issue 6 Class A, VCCI-CISPR 32:2016 Class A, AZ/NZS CISPR 32:2015 Class A, KN22:2009 Class A, KN24:2009, RoHS, CB, cTUVus, CU, S Mark, FCC, VCCI, ICES, RCM, BSMI, KCC, CCC
Included Accessories3 fan trays, rack mount kit, cable retaining straps
Rack Mounting KitIncluded
Power
80 PLUS Certification80 PLUS Gold
FeaturesPower-to-port airflow
Installed Qty2
Max Supported Qty2
Power Consumption Operational466 Watt
Power DeviceInternal power supply - hot-plug
Power Provided1100 Watt
Power RedundancyYes
Power Redundancy Scheme1+1
Voltage RequiredAC 100-264 V (50/60 Hz)
Software / System Requirements
Software IncludedNVIDIA Cumulus Linux
