HPE Aruba 6000 12G Class4 PoE 2G/2SFP 139W Switch

Login for Price
HPE Aruba 6000 12G Class4 PoE 2G/2SFP 139W Switch
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Switch
  • managed
  • 12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 1000Base-T
  • rack-mountable
  • PoE (139 W)
HPE Aruba 6000 12G Class4 PoE 2G/2SFP 139W Switch
  • Switch
  • managed
  • 12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 1000Base-T
  • rack-mountable
  • PoE (139 W)
  Additional Details
Mfr Part #: R8N89A#ACF
SHI Part #: 44056283
Category: Network switches
UNSPSC: 43222612
Manufacturer: Hewlett Packard Enterprise
Product Type: Hardware
General Information
CategoryNetwork switches
DescriptionHPE Aruba 6000 12G Class4 PoE 2G/2SFP 139W Switch - Switch - managed - 12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 1000Base-T - rack-mountable - PoE (139 W)
ManufacturerHewlett Packard Enterprise
UNSPSC43222612
Main Specifications
Dimensions & Weight / Depth25.5 cm
Dimensions & Weight / Height4.39 cm
Dimensions & Weight / Weight2.78 kg
Dimensions & Weight / Width25.4 cm
Header / BrandAruba
Header / Country KitsJapan
Header / LocalizationEnglish
Miscellaneous / Product ColorBlack
Networking / Form FactorRack-mountable
Networking / Ports Qty12
Networking / TypeSwitch
Packaged Quantity1
Service & Support / TypeLimited lifetime warranty
Dimensions & Weight
Depth25.5 cm
Height4.39 cm
Weight2.78 kg
Width25.4 cm
Environmental Parameters
Humidity Range Operating15 - 95% (non-condensing)
Humidity Range Storage15 - 90% (non-condensing)
Max Operating Temperature45 °C
Min Operating Temperature0 °C
Expansion / Connectivity
Interfaces
  • 12 x 10/100/1000 Base-T RJ-45 PoE Class 4 - 139 W
  • 2 x 10Gbit LAN SFP
  • 2 x Gigabit LAN
  • 1 x USB Type A
  • 1 x USB-C console
General
Authentication MethodSecure Shell (SSH), Secure Shell v.2 (SSH2), TACACS+, RADIUS
Capacity
  • Switched virtual interfaces (SVIs): 16
  • ARP entries: 1024
  • IPv4 routes (Unicast): 512
  • IPv6 routes (Unicast): 512
  • IGMP groups: 512
  • MLD groups: 512
  • IPv4 ACL entries (ingress): 256
  • IPv6 ACL entries (ingress): 128
  • MAC ACL entries (ingress): 256
Compliant StandardsIEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3az, IEEE 802.3x
Device TypeSwitch - 12 ports - managed - stackable
Enclosure TypeRack-mountable 1U
Encryption AlgorithmSSL
FeaturesDNS client, VLAN support, MSTP support, Rapid Reconfiguration of Spanning Tree (RSTP), LACP support, flow control, UDP, TFTP support, ARP support, DHCP client, ICMP, SNTP support, BOOTP support, DiffServ support, IPv6 addressing, IPv6 support, LLDP support, LLDP-MED, MIB, MLD snooping, NDP, sFlow, SNMP support, fanless, TPM, ACL support
Flash Memory16 GB
Jumbo Frame Support9198 bytes
MAC Address Table Size8192 entries
Performance
  • Packet buffer size: 12.38 MB
  • Throughput: 23.8 Mpps
  • Switching capacity: 32 Gbps
  • Latency (1 Gbps): 2.3 µs
  • Latency (10 Gbps): 2.6 µs
PoE Budget139 W
Ports12 x 10/100/1000 (PoE+) + 2 x Gigabit SFP + 2 x 1000Base-T
Power Over Ethernet (PoE)PoE
Processor1 x ARM A9: 1.016 GHz
RAM4 GB DDR3 SDRAM
Remote Management ProtocolRADIUS, SNMP 1, SNMP 2c, SNMP 3, HTTP, HTTPS
Routing ProtocolIGMPv2, IGMPv3
SubtypeGigabit Ethernet
Manufacturer Warranty
Service & SupportLimited warranty - lifetime
Miscellaneous
Compliant StandardsUL 60950-1, IEC 60950-1, EN 60950-1, CAN/CSA C22.2 No. 60950, EN 60825-1, UL 62368-1 Second Edition, IEC 62368-1 Second Edition, EN 62368-1:2014, VCCI-CISPR 32:2016 Class A, CNS 13438, ICES-003 issue 6 Class A, FCC CFR47 Part 15 A, EN 55032:2015/AC:2016-07 Class A, CISPR 32 Class A, CISPR 24, CISPR 35, EN55024:2010:A1, EN 55035:2017, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, IEC 61000-3-2, EN 61000-3-3, IEC 61000-3-3
LocalizationEnglish / Japan
Power
Power Consumption Operational21.9 Watt
Power DeviceInternal power supply
Voltage RequiredAC 100-240 V (50/60 Hz)
