Tripp Lite 8-Port Gigabit Ethernet Switch L2 Web-Smart Managed PoE+ , 10/100/1000Mbps, 2 Dedicated Gigabit SFP Slots, 20 Gbps, Web Interface
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Tripp Lite 8-Port Gigabit Ethernet Switch L2 Web-Smart Managed PoE+ , 10/100/1000Mbps, 2 Dedicated Gigabit SFP Slots, 20 Gbps, Web Interface
- Switch
- smart
- 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP
- rack-mountable
- PoE+
- AC 100
- 240 V
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | NGS8C2POE |
| SHI Part #: | 33975277 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | Eaton |
| Product Type: | Hardware |
Network Cables
- Patch cable
- LC single-mode (M) to LC single-mode (M)
- 3 m
- fiber optic
- duplex
- 9 / 125 micron
MSRP $26.00
$23.00
- Patch cable
- RJ-45 (M) to RJ-45 (M)
- 7.62 m
- UTP
- CAT 6
- molded, snagless, stranded
MSRP $22.38
$12.00
- Patch cable
- LC single-mode (M) to LC single-mode (M)
- 2 m
- fiber optic
- duplex
- 9 / 125 micron
MSRP $23.00
$20.00
Network Interface Cards
- Network adapter
- USB
- 1000Base-X x 1
- 1310 nm
- white
- for P/N: NG24, NGS8C2POE
MSRP $500.00
$191.00
- Network adapter
- USB
- 1000Base-X x 1
- 1310 nm
- white
- for P/N: NG24, NGS8C2POE
MSRP $500.00
$191.00
| General Information | |
|---|---|
| Category | Network switches |
| Description | Tripp Lite 8-Port Gigabit Ethernet Switch L2 Web-Smart Managed PoE+ , 10/100/1000Mbps, 2 Dedicated Gigabit SFP Slots, 20 Gbps, Web Interface - Switch - smart - 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP - rack-mountable - PoE+ - AC 100 - 240 V |
| Manufacturer | Eaton |
| MSRP | $196.77 |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 20.5 cm |
| Dimensions & Weight / Height | 4.39 cm |
| Dimensions & Weight / Weight | 2.45 kg |
| Dimensions & Weight / Width | 44 cm |
| Header / Brand | Tripp Lite |
| Miscellaneous / Product Color | Black |
| Networking / Form Factor | Rack-mountable |
| Networking / Ports Qty | 10 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | 5-year warranty |
| Dimensions & Weight | |
| Depth | 20.5 cm |
| Height | 4.39 cm |
| Weight | 2.45 kg |
| Width | 44 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.1w, IEEE 802.1x, IEEE 802.3at |
| Device Type | Switch - 10 ports - smart |
| Enclosure Type | Rack-mountable 1U |
| Features | Flow control, VPN support, auto-negotiation, trunking, VLAN support, auto-uplink (auto MDI/MDI-X), STP support, RSTP support, DHCP snooping, ACL support, QoS, fanless, Port Security, tagged VLAN, 802.1x authentication, crossover detection, metal housing, Storm Control, IPMB |
| Jumbo Frame Support | 9KB |
| MAC Address Table Size | 8000 entries |
| Performance | Switching capacity: 20 Gbps |
| Ports | 8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP |
| Power Over Ethernet (PoE) | PoE+ |
| Remote Management Protocol | SNMP, RMON |
| Status Indicators | Port status, power, PoE, SFP |
| Subtype | Gigabit Ethernet |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 5 years |
| Miscellaneous | |
| Color | Black |
| Compliant Standards | Plug and Play, RoHS, UL 60950-1:2007 Second Edition, CAN/CSA-C22.2 No. 60950-1-07 Second Edition |
| Included Accessories | 4 rubber feet |
| Rack Mounting Kit | Included |
| Power | |
| Power Consumption Operational | 300 Watt |
| Voltage Required | AC 100 - 240 V |
