B&B Elinx ESW208-4MT-T
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
B&B Elinx ESW208-4MT-T
- Switch
- unmanaged
- 4 x 10/100 + 4 x 100Base-FX
- DIN rail mountable
| Additional Details | |
|---|---|
| Mfr Part #: | ESW208-4MT-T |
| SHI Part #: | 32392731 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | Advantech |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Network switches |
| Description | B&B Elinx ESW208-4MT-T - Switch - unmanaged - 4 x 10/100 + 4 x 100Base-FX - DIN rail mountable |
| Manufacturer | Advantech |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 4.4 cm |
| Dimensions & Weight / Height | 10.5 cm |
| Dimensions & Weight / Width | 13 cm |
| Header / Brand | B&B |
| Networking / Form Factor | DIN rail mountable |
| Networking / Ports Qty | 8 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Dimensions & Weight | |
| Depth | 4.4 cm |
| Height | 10.5 cm |
| Width | 13 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 95% (non-condensing) |
| Max Operating Temperature | 60 °C |
| Max Storage Temperature | 80 °C |
| Min Operating Temperature | -10 °C |
| Min Storage Temperature | -40 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Device Type | Switch - 8 ports - unmanaged |
| Enclosure Type | DIN rail mountable |
| Features | Flow control, auto-uplink (auto MDI/MDI-X), store and forward, half duplex mode, full duplex mode |
| MAC Address Table Size | 2K entries |
| Ports | 4 x 10/100 + 4 x 100Base-FX |
| Subtype | Fast Ethernet |
| Miscellaneous | |
| Compliant Standards | EN55022 Class B, EN 61000-4-4, EN 61000-4-2, EN 61000-4-3, EN 61000-4-6, EN 61000-4-5, FCC, EN 61000-6-2, RoHS, IEC 60068-2-27, IEC 60068-2-32, IEC 60068-2-6, IEC 60529 IP30 |
| MTBF | 200,000 hours |
| Power | |
| Power Consumption Operational | 4 Watt |
