TRENDnet TEG MGBS20D5
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
TRENDnet TEG MGBS20D5
- SFP (mini-GBIC) transceiver module
- GigE
- 1000Base-LX, Fibre Channel
- LC single-mode
- up to 20 km
- 1550 (TX) / 1310 (RX) nm
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | TEG-MGBS20D5 |
| SHI Part #: | 31884872 |
| Category: | Transceivers |
| UNSPSC: | 43201553 |
| Manufacturer: | TRENDnet |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Transceivers |
| Description | TRENDnet TEG MGBS20D5 - SFP (mini-GBIC) transceiver module - GigE - 1000Base-LX, Fibre Channel - LC single-mode - up to 20 km - 1550 (TX) / 1310 (RX) nm |
| Manufacturer | TRENDnet |
| MSRP | $57.99 |
| UNSPSC | 43201553 |
| Main Specifications | |
| Dimensions & Weight / Depth | 5.7 cm |
| Dimensions & Weight / Height | 1.2 cm |
| Dimensions & Weight / Weight | 18 g |
| Dimensions & Weight / Width | 1.3 cm |
| Header / Brand | TRENDnet |
| Networking / Connectivity Technology | Wired |
| Networking / Data Link Protocol | Gigabit Ethernet |
| Networking / Data Transfer Rate | 1.25 Gbps |
| Networking / Form Factor | Plug-in module |
| Networking / Type | SFP (mini-GBIC) transceiver module |
| Packaged Quantity | 1 |
| Service & Support / Type | Limited lifetime warranty |
| Dimensions & Weight | |
| Depth | 5.7 cm |
| Height | 1.2 cm |
| Weight | 18 g |
| Width | 1.3 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 85% (non-condensing) |
| Max Operating Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces | 1 x Ethernet 1000Base-LX - LC single-mode female |
| General | |
| Device Type | SFP (mini-GBIC) transceiver module |
| Form Factor | Plug-in module |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Compliant Standards | FCC, Laser Class 1, MSA |
| TAA Compliant | Yes |
| Networking | |
| Cabling Type | 1000Base-LX, Fibre Channel |
| Compliant Standards | IEEE 802.3z |
| Connectivity Technology | Wired |
| Data Link Protocol | 1GbE |
| Data Transfer Rate | 1.25 Gbps |
| Features | Hot swap module replacement |
| Max Transfer Distance | 20 km |
| Optical Wave Length | 1550 (TX) / 1310 (RX) nm |
| Power | |
| Power Consumption Operational | 0.8 watt |
