Cisco Nexus 9396TX - Switch
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Cisco Nexus 9396TX - Switch
- L3
- managed
- 48 x 10GBase-T + 12 x 40 Gigabit QSFP+
- desktop, rack-mountable
| Additional Details | |
|---|---|
| Mfr Part #: | N9K-C9396TX= |
| SHI Part #: | 29763660 |
| Category: | Network switches |
| UNSPSC: | 43222612 |
| Manufacturer: | Cisco Systems |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Network switches |
| Description | Cisco Nexus 9396TX - Switch - L3 - managed - 48 x 10GBase-T + 12 x 40 Gigabit QSFP+ - desktop, rack-mountable |
| Manufacturer | Cisco Systems |
| UNSPSC | 43222612 |
| Main Specifications | |
| Dimensions & Weight / Depth | 57.1 cm |
| Dimensions & Weight / Height | 8.9 cm |
| Dimensions & Weight / Width | 44.5 cm |
| Header / Brand | Cisco |
| Miscellaneous / Product Color | Gray |
| Networking / Form Factor |
|
| Networking / Ports Qty | 48 |
| Networking / Type | Switch |
| Packaged Quantity | 1 |
| Service & Support / Type | 1-year warranty |
| Dimensions & Weight | |
| Depth | 57.1 cm |
| Height | 8.9 cm |
| Width | 44.5 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Max Storage Temperature | 70 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 0 (free) x expansion slot |
| Installed Modules Qty (Max) | 1 (installed) / 1 (max) |
| Interfaces |
|
| General | |
| Authentication Method | RADIUS, TACACS+ |
| Capacity |
|
| Compliant Standards | IEEE 802.3z, IEEE 802.1D, IEEE 802.1Q, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.1w, IEEE 802.3ae, IEEE 802.1s, IEEE 801.1p, IEEE 802.3ba |
| Device Type | Switch - 48 ports - L3 - managed |
| Enclosure Type | Desktop, rack-mountable 2U |
| Features | Flow control, modular design, load balancing, VLAN support, WRR queuing, Broadcast Storm Control, Multicast Storm Control, Unicast Storm Control, WRED, STP support, RSTP support, MSTP support, ACL support, QoS, RADIUS support, RDMA support, LLDP support, LACP, DSCP support |
| Performance | Bandwidth: 1.92 Tbps |
| Ports | 48 x 10GBase-T + 12 x 40 Gigabit QSFP+ |
| Remote Management Protocol | SNMP 1, SNMP 2, RMON, Telnet, SNMP 3, SSH-2 |
| Subtype | 10 Gigabit Ethernet |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - advance parts replacement - 1 year - response time: 10 days |
| Miscellaneous | |
| Compliant Standards | CISPR 22 Class A, BSMI CNS 13438 Class A, CISPR 24, EN 61000-3-2, EN 61000-3-3, EN55024, EN55022 Class A, AS/NZS 60950-1, ICES-003 Class A, RoHS, UL 60950-1 Second Edition, GB 4943, CSA C22.2 No. 60950-1 Second Edition, EN 60950-1 Second Edition, IEC 60950-1 Second Edition, EN 61000-3-1, VCCI Class A, KN22 Class A, AS/NZS CISPR 22, EN 300386 |
| Power | |
| Max Supported Qty | 2 |
| Power Device | Internal power supply (not installed) - hot-plug |
| Power Redundancy | Yes |
