Hanwha Vision WiseNet P PNV-A7082RZ
MSRP$2,200.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Hanwha Vision WiseNet P PNV-A7082RZ
- Gen 2
- network surveillance camera
- PTRZ
- dome
- outdoor
- vandal-resistant
- color (Day&Night)
- 4 MP
- 2592 x 1520
- motorized
- audio
- GbE
- H.265, H.264, MJPEG
- DC 12 V / PoE Plus
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $2,200.00 |
| Mfr Part #: | PNV-A7082RZ |
| SHI Part #: | 50701231 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hanwha Vision WiseNet P PNV-A7082RZ - Gen 2 - network surveillance camera - PTRZ - dome - outdoor - vandal-resistant - color (Day&Night) - 4 MP - 2592 x 1520 - motorized - audio - GbE - H.265, H.264, MJPEG - DC 12 V / PoE Plus |
| Manufacturer | HANWHA VISION |
| MSRP | $2,200.00 |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 18 cm |
| Dimensions & Weight / Height | 13.5 cm |
| Dimensions & Weight / Weight | 2.1 kg |
| Dimensions & Weight / Width | 18 cm |
| Header / Brand | Hanwha Vision |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Capture Resolution | 2592 x 1520, 2560 x 1440, 1920 x 1080, 1600 x 1200, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 640 x 480, 640 x 360, 320 x 240, 320 x 180 |
| Digital Video Format | H.265, H.264, MJPEG |
| Exposure Range | 2 sec - 1/30000 sec |
| Features | Hard-coated window, WiseStream support, WiseNR II, 120 dB wide dynamic range, Digital Image Stabilization (DIS), built-in gyroscope, Handover, dynamic privacy masking, AI-powered, Object Detection, Line Crossing Detection, sound classification, Person Detection, face detection, Vehicle Detection, license plate detection, gender recognition, clothing color recognition, bag detection, age recognition, mask detection, glasses detection, vehicle type classification, vehicle color recognition, Defocus Detection, Tampering detection, fog detection, Heat Map, queue management, people counting, vehicle counting, crowd counting, Backlight Compensation (BLC), Highlight Compensation (HLC), Samsung Super Dynamic Range (SSDR), 850nm illuminator, Variable Bitrate (VBR), Constant Bitrate (CBR), white balance, ONVIF (Profile G) support, ONVIF (Profile M) support, ONVIF (Profile S) support, ONVIF (Profile T) support |
| Flash Memory | 8 GB |
| Frame Rate (max) | 60 frames per second |
| Infrared Distance | 30 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 2592 x 1520 |
| Minimum Illumination |
|
| RAM | 4 GB |
| Type | Color - Day&Night - pan / tilt / roll / zoom - outdoor - vandal-resistant |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -50 °C |
| Relative Humidity (operating) | 0 - 100% (condensing) |
| Expansion / Connectivity | |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Support | Yes |
| Connectivity Technology | Wired |
| Depth | 18 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 13.5 cm |
| Weight | 2.1 kg |
| Width | 18 cm |
| Image Sensor | |
| Type | 4 MP CMOS 1/1.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | DDNS, DHCP, DNS, FTP, HTTP, NTP, SMTP, TCP/IP, UDP/IP, ARP, ICMP, SNMP 1, SNMP 2c, SNMP 3, RTSP, RTP, HTTPS, UPnP, TLS, IPv4, IPv6, Bonjour, RTCP, IGMP, SSL, QOS, SRTP, EAP, LLDP |
| Lens Construction | |
| Diagonal Field of View (degree) | 55 - 128 |
| Focal Length | 4.6 mm - 9.35 mm |
| Horizontal Field of View (degree) | 47 - 105 |
| Lens Iris | F/1.3-2.15 (P-Iris) |
| Min Focus Distance | 1.5 m |
| Optical Zoom | 2 x |
| Type | Motorized zoom |
| Vertical Field of View (degree) | 27 - 58 |
| Miscellaneous | |
| Color | White, RAL 9003 |
| Compliant Standards | IP66, IP67, IK10, NEMA Type 4X, NEMA TS-2, FIPS 140-3 Level 3, NDAA, FCC, EAC, cULus, ICES-3(A)/NMB-3(A), EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, KS C 9832 Class A, KS C 9835, UL 62368-1, IEC 62471, IEC/EN 63000, IEC 60529 IP66, IEC 60529 IP67, IEC 62262 IK10, NEMA 250 Type 4X, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-6, IEC 60068-2-14, IEC 60068-2-27, IEC 60068-2-78 |
| Panning | |
| Range (degree) | 0 to 350 |
| Power | |
| Power Device | 15 Watt |
| Power Requirements | DC 12 V / PoE Plus |
| Tilting | |
| Range (degree) | -45 to +85 |
