HP Elite t660 - Thin client

Login for Price
HP Elite t660 - Thin client
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • SFF 1 x U-Series U300E / up to 4.3 GHz
  • RAM 16 GB
  • flash 64 GB
  • eMMC
  • UHD Graphics
HP Elite t660 - Thin client
  • SFF 1 x U-Series U300E / up to 4.3 GHz
  • RAM 16 GB
  • flash 64 GB
  • eMMC
  • UHD Graphics
  • Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
  • 11 IoT Enterprise 2024 LTSC
  • monitor: none
  • keyboard: US
  • Smart Buy
  Additional Details
Mfr Part #: B94VJUT#ABA
SHI Part #: 49879326
Category: Thin client or diskless workstations
UNSPSC: 43211506
Manufacturer: HP, Inc.
Product Type: Hardware
General Information
CategoryThin client or diskless workstations
DescriptionHP Elite t660 - Thin client - SFF 1 x U-Series U300E / up to 4.3 GHz - RAM 16 GB - flash 64 GB - eMMC - UHD Graphics - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7) - 11 IoT Enterprise 2024 LTSC - monitor: none - keyboard: US - Smart Buy
ManufacturerHP, Inc.
UNSPSC43211506
Main Specifications
Chassis / Form FactorSmall form factor
Dimensions & Weight / Depth20 cm
Dimensions & Weight / Height20 cm
Dimensions & Weight / Weight1.2 kg
Dimensions & Weight / Width3.5 cm
Display / TypeNone.
Hard Drive / Capacity64 GB
Header / BrandHP
Header / Country KitsUnited States
Header / LocalizationEnglish
Miscellaneous / Product ColorBlack
Networking / Data Link Protocol
  • Bluetooth 5.4
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax (Wi-Fi 6)
  • IEEE 802.11b
  • IEEE 802.11be (Wi-Fi 7)
  • IEEE 802.11g
  • IEEE 802.11n
Networking / Wireless LAN SupportedYes
Networking / Wireless Protocol
  • 802.11a/b/g/n/ac/ax/be
  • Bluetooth 5.4
Optical Storage / Drive TypeNo optical drive
Optical Storage / TypeNone
OS Provided / TypeWindows 11 IoT Enterprise 2024 LTSC
Packaged Quantity1
Processor / Clock Speed1.1 GHz
Processor / ManufacturerIntel
Processor / Number of Cores5-core
Processor / Processor NumberU300E
Processor / TypeU-Series
RAM / Form FactorSO-DIMM 262-pin
RAM / Memory Speed2600 MHz
RAM / TechnologyDDR5 SDRAM
Service & Support / Type3-year warranty
System / Hard Drive Capacity64 GB
System / TypeThin client
Video Output / Graphics ProcessorIntel UHD Graphics
Cache Memory
Cache Per Processor8 MB
Installed SizeL3 cache - 8 MB
Dimensions & Weight
Depth20 cm
Dimensions & Weight Details
  • 3.5 cm - 20 cm - 20 cm - 1.2 kg - with stand
  • - 1.15 kg - without stand
Height20 cm
Weight1.2 kg
Width3.5 cm
Dimensions & Weight (Shipping)
Shipping Depth13.2 cm
Shipping Height26 cm
Shipping Weight2.98 kg
Shipping Width49.5 cm
Environmental Parameters
Humidity Range Operating10 - 90% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature10 °C
Expansion / Connectivity
Interfaces
  • 3 x USB 3.2 Gen 1 (2 front, 1 rear)
  • 1 x USB 3.2 Gen 2 (1 rear)
  • 1 x Thunderbolt 4/USB4/DisplayPort 1.4 (1 front) (Power Delivery, HP Sleep and Charge)
  • 1 x audio line-out/line-in (1 rear)
  • 1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear)
  • 2 x USB 2.0 (2 rear)
  • 1 x audio line-in/headphones - mini-jack (1 front)
  • 3 x DisplayPort 1.4 (3 rear)
Slots1 (total) / 0 (free) x M.2 Card (for internal storage)
General
Built-in DevicesSpeaker
Embedded SecurityTrusted Platform Module (TPM 2.0) Security Chip
LocalizationLanguage: English / region: United States
Product Form FactorSFF
TypeThin client
Graphics Controller
Graphics ProcessorIntel UHD Graphics
Max Monitors Supported4
Video InterfacesDisplayPort
Hard Drive
Capacity1 x 64 GB
FeatureseMMC
TypeFlash
Input Device
TypeMouse, keyboard
Keyboard
InterfaceUSB
Keyboard NameHP 320K
Localization & LayoutUS
Manufacturer Warranty
Service & SupportLimited warranty - parts and labor - 3 years
Miscellaneous
Compliant StandardsFCC Class B certified, UL, BSMI, GS, CB, CCC, ICES Class B, WEEE, KCC Class B, AS/NZS, ERP, CECP, RoHS2, VCCI Class B, CISPR Class B, SEPA, low halogen, HP GSE, EN60601-1-2, CNS Class B
Manufacturer Selling ProgramHP Smart Buy
Security Slot TypeKensington security slot
Theft/Intrusion ProtectionSecurity lock slot (cable lock sold separately)
VESA Mounting Interface100 x 100 mm
Monitor
Monitor TypeNone.
Mouse
Mouse NameHP 320M
Networking
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
Ethernet ControllerRealtek RTL8111HSH-CG
FeaturesWake on LAN (WoL), dual stream (2x2)
Wireless LAN SupportedYes
Wireless NICIntel WI-FI 7 BE200
Operating System / Software
OS ProvidedWindows 11 IoT Enterprise 2024 LTSC English
SoftwareCitrix ICA, Microsoft RDP, Microsoft Windows Media Player, Microsoft Firewall, HP Remote Graphics Software, HP Easy Tools, HP Device Manager, LogOn Manager, Citrix HDX, HP Secure Erase, CyberLink Power Media Player, HP ThinUpdate, HP True Graphics, HP Easy Shell, Microsoft Edge, Microsoft SCCM/EDM-agent, HP USB Port Manager, HP Smart Zero Client Services, HP Write Manager, HP Sure Admin, Microsoft Unified Write Filter, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, Microsoft RFX, Microsoft Direct Access, HP User State Tool, HP Sure Start, Microsoft AVD
Optical Storage
TypeNo optical drive
Power
Device TypePower adapter
Efficiency87%
Power Device NameHP Smart AC Adapter
Power Provided45 watt
Voltage RequiredAC 100-240 V (50/60 Hz)
Processor / Chipset
Clock Speed1.1 GHz
CPUIntel U-Series U300E
CPU Qty1
CPU UpgradabilityNot upgradable
Max CPU Qty1
Max Turbo Speed4.3 GHz (P-core) / 3.2 GHz (E-core)
Number of Cores5-core
Processor Main FeaturesIntel Turbo Boost Technology
RAM
Configuration Features2 x 8 GB
Effective Memory Speed2600 MHz
Form FactorSO-DIMM 262-pin
Installed Size16 GB (installed) / 32 GB (max)
Rated Memory Speed2800 MHz
Slots2 (total) / 0 (empty)
TechnologyDDR5 SDRAM
Sustainability Information
ENERGY STAR CertifiedYes
EPEAT CompliantEPEAT Gold
TCO CertifiedTCO Certified Desktops 9
