Digital Cameras and Camcorders

i-PRO WV-X67310-Z4L3

MSRP$13,689.90
$9,755.00
i-PRO WV-X67310-Z4L3
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Network surveillance camera
  • PTZ
  • turret
  • dust resistant / water resistant / shock resistant / wind resistant / corrosion resistant / tamper resistant
  • color (Day&Night)
i-PRO WV-X67310-Z4L3
  • Network surveillance camera
  • PTZ
  • turret
  • dust resistant / water resistant / shock resistant / wind resistant / corrosion resistant / tamper resistant
  • color (Day&Night)
  • 2 MP
  • 2048 x 1536
  • motorized
  • audio
  • LAN 10/100
  • H.265, H.264, MJPEG
  • DC 24 V / AC 24 V / PoE++ Class 8
  Additional Details
Price: $9,755.00
MSRP: $13,689.90
Mfr Part #: WV-X67310-Z4L3
SHI Part #: 49022124
Category: Digital cameras
UNSPSC: 45121504
Manufacturer: i-Pro Americas Inc.
Product Type: Hardware
General Information
CategoryDigital cameras
Descriptioni-PRO WV-X67310-Z4L3 - Network surveillance camera - PTZ - turret - dust resistant / water resistant / shock resistant / wind resistant / corrosion resistant / tamper resistant - color (Day&Night) - 2 MP - 2048 x 1536 - motorized - audio - LAN 10/100 - H.265, H.264, MJPEG - DC 24 V / AC 24 V / PoE++ Class 8
Manufactureri-Pro Americas Inc.
MSRP$13,689.90
UNSPSC45121504
Main Specifications
Dimensions & Weight / Depth26.6 cm
Dimensions & Weight / Height45 cm
Dimensions & Weight / Weight8.1 kg
Dimensions & Weight / Width22.6 cm
Header / Brandi-Pro
Miscellaneous / Product ColorGray
Packaged Quantity1
System Requirements / OS Required
  • Android
  • Apple iOS 8.0 or higher
Camera
Digital Video Capture Resolution2048 x 1536, 1280 x 960, 1920 x 1080, 1280 x 720, 640 x 360, 320 x 180
Digital Video FormatH.265, H.264, MJPEG
Digital Zoom640
Exposure Range1/25 sec - 1/10000 sec
FeaturesRugged housing, white LED, Intelligent Auto Tracking, up to 270km/h wind resistance, Automatic Tracing White (ATW), Automatic White Balance Control (AWC), 144 dB dynamic range, 32 privacy zones, 8 VIQS zones, Adaptive Black Stretch (ABS), AI Analytics, AI Sound Classification, Audio Detection, Automatic Gain Control (AGC), Backlight Compensation (BLC), built-in gyroscope, built-in OSD menu, digital noise reduction, fog compensation, Highlight Compensation (HLC), ICR filter, image stabilizer, Video Motion Detection (VMD), DORI coverage, Ambarella CV25M CPU, 256 preset positions, auto-pan mode, Patrol Mode, self return, Smart Coding Technology, up to 14 users, ONVIF (Profile T) support, ONVIF (Profile M) support, ONVIF (Profile S) support, die-cast housing, easy kitting
Frame Rate (max)30 frames per second
Infrared Distance560 m
Infrared LEDsYes
Max Digital Video Resolution2048 x 1536
Minimum Illumination
  • 0.011 lux - color - F1.6 - 30 IRE - shutter 1/30 sec / AGC on
  • 0.015 lux - color - F1.6 - 50 IRE - shutter 1/30 sec / AGC on
  • 0.001 lux - color - F1.6 - 50 IRE - shutter 16/30 sec / AGC on
  • 0 lux - B&W - F1.6 - 50 IRE - shutter 1/30 sec / AGC on / infrared LEDs on
  • 0.0004 lux - B&W - F1.6 - 50 IRE - shutter 16/30 sec / AGC on
Motion DetectionYes
Supported Image FormatsJPEG
TypeColor - Day&Night - pan / tilt / zoom - dust resistant / water resistant / shock resistant / wind resistant / corrosion resistant / tamper resistant
Video Modes2K, 1080p, 720p
Environmental Parameters
Max Operating Temperature65 °C
Min Operating Temperature-50 °C
Relative Humidity (operating)10 - 100% (non-condensing)
Expansion / Connectivity
Encryption AlgorithmFIPS 140-2 Level 3
Ports
  • LAN - RJ-45
  • 3 x audio line in - bare wire
  • 3 x audio line out
  • Relay
Supported Memory CardsmicroSD Card, microSDHC Card, microSDXC Card
General
Audio FormatsG.726, ADPCM, G.711, AAC-LC
Audio SupportYes
Connectivity TechnologyWired
Depth26.6 cm
Device TypeNetwork surveillance camera
Form FactorTurret
Height45 cm
Weight8.1 kg
Width22.6 cm
Image Sensor
Type2 MP CMOS 1/2.8"
Interfaces
Alarm Inputs Qty3
Network InterfaceEthernet 10Base-T/100Base-TX
Network ProtocolsIPv6, TCP/IP, UDP/IP, HTTP, HTTPS, SSL, SMTP, DNS, NTP, DHCPv6, RTP, MLD, ICMP, ARP, DiffServ, FTP, SFTP, LLDP, MQTT, IPv4, RTSP, DHCP, DDNS, UPnP, IGMP, SRTP, NTCIP, TLS, RTCP, SNMP 1, SNMP 2, SNMP 3
Lens Construction
Focal Length4.25 mm - 170 mm
Horizontal Field of View (degree)1.4 - 66
Lens IrisF/1.6
Min Focus Distance3 m
Optical Zoom40 x
TypeMotorized zoom
Vertical Field of View (degree)1.1 - 39
Miscellaneous
ColorGray (Munsell N7) semi-gloss
Compliant StandardsNDAA, IP66, IP68, IK10, IEEE 802.1x, UL 62368-1, C-UL, CSA C22.2 No. 62368-1, IEC 62368-1, FCC Part 15 A, ICES 003, EN 55032, EN 55035, EN 61000-6-2, EN 50121-4, IEC 62236-4, IEEE 802.3bt, IEC 60068-2-1, IEC 60068-2-2, IEC 60068-2-14, IEC 60068-2-30, IEC 60068-2-78, MIL-STD-810 H, NEMA TS-2, ISO 14993
Panning
Range (degree)360
Speed (degree/sec)Up to 200
Power
Power RequirementsDC 24 V / AC 24 V / PoE++ Class 8
Software / System Requirements
OS RequiredAndroid, Apple iOS 8.0 or higher
Tilting
Range (degree)-90 to +90
Speed (degree/sec)Up to 200
