HP Mini IP Conference PC

Quick Details
Mini desktop Core i7 13700T / up to 4.9 GHz vPro RAM 16 GB SSD 256 GB NVMe

Mini desktop Core i7 13700T / up to 4.9 GHz
vPro
RAM 16 GB
SSD 256 GB
NVMe
UHD Graphics 770
Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
Win 11 IoT Enterprise
monitor: none
with Microsoft Team Rooms

Additional Details
Mfr Part #:	A1ZB6AW#ABA
SHI Part #:	48535976
Category:	Desktop computers
UNSPSC:	43211507
Manufacturer:	HP, Inc.
Product Type:	Hardware

Keyboards and Keypads

HP Desktop 320K - Keyboard

US
for HP 470 G8; Chromebook 11 G9, 14 G7; Chromebook x360; EliteBook 840; ProBook x360

Login for Price

HP Desktop 320MK - Keyboard and mouse set

US
for HP 34; EliteBook 830 G6; Presence Small Space Solution with Zoom Rooms

Login for Price

HP 125 - Keyboard - USB

US
for HP 34; Laptop 15; Pro Mobile Thin Client mt440 G3

Login for Price

Monitors and Displays

HP 524pf - Series 5 Pro

LED monitor
24" (23.8" viewable)
1920 x 1080 Full HD (1080p) @ 100 Hz
IPS
350 cd/m²
1500:1

Login for Price

HP P24h G5 - LED monitor

23.8"
1920 x 1080 Full HD (1080p) @ 75 Hz
IPS
250 cd/m²
1000:1
5 ms

Login for Price

HP E24 G5 - E-Series

LED monitor
23.8"
1920 x 1080 Full HD (1080p) @ 75 Hz
IPS
250 cd/m²
1000:1

Login for Price

Audio/Video Cables

HP - Display cable kit

DisplayPort (M) to DisplayPort (M)
2 m
for Elite t655; Presence Small Space Solution with Zoom Rooms; Pro t550

Login for Price

HP - DisplayPort adapter

Mini DisplayPort (M) to DisplayPort (F)
for Elite 800 G9; Workstation Z2 G8, Z2 G9, Z4 G5, Z6 G5; ZBook Fury 15 G8, 16 G9, 17 G8

Login for Price

Memory (RAM)

HP - DDR5 - module - 16 GB

SO-DIMM 262-pin
4800 MHz / PC5-38400
unbuffered
non-ECC
for Elite 600 G9, 800 G9, Mini Conference G9; Workstation Z2 G9

Login for Price

HP - DDR5 - module - 32 GB

SO-DIMM 262-pin
4800 MHz / PC5-38400
unbuffered
non-ECC
for Elite 600 G9, 800 G9, Mini Conference G9; Workstation Z2 G9

Login for Price

General Information
Category	Desktop computers
Description	HP Mini IP Conference PC - Mini desktop Core i7 13700T / up to 4.9 GHz - vPro - RAM 16 GB - SSD 256 GB - NVMe - UHD Graphics 770 - Gigabit Ethernet, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 IoT Enterprise - monitor: none - with Microsoft Team Rooms
Manufacturer	HP, Inc.
UNSPSC	43211507
Main Specifications
Chassis / Form Factor	Ultra small form factor
Dimensions & Weight / Depth	17.5 cm
Dimensions & Weight / Height	3.4 cm
Dimensions & Weight / Weight	1.42 kg
Dimensions & Weight / Width	17.7 cm
Display / Type	None.
Hard Drive / Capacity	256 GB
Header / Brand	HP
Header / Country Kits	United States
Header / Localization	English
Mainboard / Chipset Type	Intel Q670
Miscellaneous / Product Color	Black
Networking / Data Link Protocol	2.5 Gigabit Ethernet Bluetooth 5.3 Ethernet Fast Ethernet Gigabit Ethernet IEEE 802.11a IEEE 802.11ac IEEE 802.11ax (Wi-Fi 6E) IEEE 802.11b IEEE 802.11g IEEE 802.11n
Networking / Wireless LAN Supported	Yes
Networking / Wireless Protocol	802.11a/b/g/n/ac/ax (Wi-Fi 6E) Bluetooth 5.3
Optical Storage / Drive Type	No optical drive
Optical Storage / Type	None
OS Provided / Type	Windows 11 IoT Enterprise
Packaged Quantity	1
Processor / Clock Speed	1.4 GHz
Processor / Generation	13
Processor / Manufacturer	Intel
Processor / Number of Cores	16-core
Processor / Processor Number	I7-13700T
Processor / Type	Core i7
RAM / Form Factor	SO-DIMM 262-pin
RAM / Memory Speed	2400 MHz
RAM / Technology	DDR5 SDRAM
System / Hard Drive Capacity	256 GB
System / Platform Technology	Intel vPro Platform
System / Type	Personal computer
Video Output / Graphics Processor	Intel UHD Graphics 770
Video Output / HDCP compatible	Yes
Audio Output
Compliant Standards	High Definition Audio
Max Sampling Rate	192 kHz
Sound Output Mode	Stereo
Cache Memory
Cache Per Processor	30 MB
Installed Size	L3 cache - 30 MB
Dimensions & Weight
Depth	17.5 cm
Height	3.4 cm
Weight	1.42 kg
Width	17.7 cm
Dimensions & Weight (Shipping)
Shipping Depth	11.4 cm
Shipping Height	25.1 cm
Shipping Weight	2.95 kg
Shipping Width	49.2 cm
Environmental Parameters
Humidity Range Operating	10 - 90% RH (non-condensing)
Max Operating Temperature	35 °C
Min Operating Temperature	10 °C
Expansion / Connectivity
Bays	1 (total) / 1 (free) x internal 2.5"
Interfaces	1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) 1 x DisplayPort/USB-C 3.2 Gen 1 (1 rear) (one of them is 15W charging) 1 x USB-C 3.2 Gen 1 (1 rear) (15W charging) 4 x USB 3.2 Gen 2 (2 front, 2 rear) (two of them with wake functionality, one of them is charging) 1 x headphones/microphone (1 front) (CTIA and OMTP headset support) 2 x DisplayPort 1.4a (2 rear) 1 x HDMI (1 rear) 1 x HDMI input (1 rear) 1 x LAN (2.5Gigabit Ethernet) - RJ-45 (1 rear) (up to 25W PoE) 1 x LAN (1 rear)
Slots	1 (total) / 0 (free) x M.2 Card - 2230 (for wireless module) 2 (total) / 1 (free) x M.2 Card - 2280 (for internal storage)
General
Bundled with	Microsoft Team Rooms
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Localization	Language: English / region: United States
Platform Technology	Intel vPro Platform
Product Form Factor	Mini desktop
Type	Personal computer
Graphics Controller
Graphics Processor	Intel UHD Graphics 770 Dynamic Video Memory Technology
HDCP Compatible	Yes
Video Interfaces	HDMI, DisplayPort
Hard Drive
Capacity	1 x 256 GB
Features	NVM Express (NVMe)
Interface Type	PCI Express
Type	SSD - M.2 2280
Miscellaneous
Security Slot Type	Kensington security slot
Theft/Intrusion Protection	Security lock slot (cable lock sold separately), retractable padlock loop
Monitor
Monitor Type	None.
Networking
Compliant Standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.11d, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
Ethernet Controller	Intel I219-LM
Features	Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2)
Interface (Bus) Type	PCI Express Mini Card (M.2)
Remote Management Protocol	SNMP 2
Wireless LAN Supported	Yes
Wireless NIC	Intel Wi-Fi 6E AX 211
Operating System / Software
OS Provided	Windows 11 IoT Enterprise English
Software	HP Image Assistant (free download), HP Sure Sense, Microsoft Teams Rooms, Poly Lens management software, HP Manageability Integration Kit (free download), HP Sure Start Gen7, HP Console Control, HP Sure Start
Optical Storage
Type	No optical drive
Power
Device Type	Power adapter
Efficiency	89% (230VAC), 88% (115VAC)
Power Factor Correction	Yes (active)
Power Provided	150 Watt
Voltage Required	AC 90-264 V (50/60 Hz)
Processor / Chipset
Chipset Type	Intel Q670
Clock Speed	1.4 GHz (P-core) / 1 GHz (E-core)
CPU	Intel Core i7 (13th Gen) 13700T
CPU Qty	1
CPU Upgradability	Upgradable
L2 cache	24 MB
Max CPU Qty	1
Max Turbo Speed	4.9 GHz (P-core) / 3.6 GHz (E-core)
Number of Cores	16-core
Processor Main Features	Intel Turbo Boost Technology
RAM
Configuration Features	2 x 8 GB
Effective Memory Speed	2400 MHz
Form Factor	SO-DIMM 262-pin
Installed Size	16 GB (installed) / 64 GB (max)
Rated Memory Speed	2400 MHz
Slots	2 (total) / 0 (empty)
Technology	DDR5 SDRAM
Storage Controller
Controller Interface Type	SATA-600 / NVMe
Type	1 x SATA/NVMe
