Hanwha Vision TNS-9050IBC
MSRP$9,500.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Hanwha Vision TNS-9050IBC
- Document camera
- color
- 4096 x 2160
- fixed focal
- GbE
- H.265, H.264, MJPEG
- DC 24 V
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $9,500.00 |
| Mfr Part #: | TNS-9050IBC |
| SHI Part #: | 48470445 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hanwha Vision TNS-9050IBC - Document camera - color - 4096 x 2160 - fixed focal - GbE - H.265, H.264, MJPEG - DC 24 V |
| Manufacturer | HANWHA VISION |
| MSRP | $9,500.00 |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 12.71 cm |
| Dimensions & Weight / Height | 18.1 cm |
| Dimensions & Weight / Weight | 3.438 kg |
| Dimensions & Weight / Width | 25.58 cm |
| Header / Brand | Hanwha Vision |
| Miscellaneous / Product Color | Black |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Capture Resolution | 4096 x 2160 |
| Digital Video Format | H.265, H.264, MJPEG |
| Exposure Range | 1/30 sec - 1/10000 sec |
| Features | Samsung Super Noise Reduction (SSNR) V, Automatic White Balance Control (AWC), vertical flip and mirror, barcode scan, built-in white LED lamp, Variable Bitrate (VBR), Constant Bitrate (CBR), Unicast Streaming, Multicast Streaming, ONVIF (Profile M) support, aluminum enclosure |
| Flash Memory | 512 MB |
| Frame Rate (max) | 20 frames per second |
| Max Digital Video Resolution | 4096 x 2160 |
| RAM | 4 GB |
| Type | Color - fixed |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 0 - 95% RH (non-condensing) |
| Expansion / Connectivity | |
| Encryption Algorithm | EAP-TLS, EAP-LEAP, EAP-PEAP, MSCHAPv2 |
| Ports | LAN - M12 |
| General | |
| Connectivity Technology | Wired |
| Depth | 12.71 cm |
| Device Type | Document camera |
| Height | 18.1 cm |
| Weight | 3.438 kg |
| Width | 25.58 cm |
| Image Sensor | |
| Type |
|
| Interfaces | |
| Alarm Outputs Qty | 1 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, DHCP, FTP, SMTP, ICMP, IGMP, ARP, DNS, DDNS, QOS, UPnP, Bonjour, SRTP, MQTT, RTP, UDP, TCP, TLS, SNMP 1, SNMP 2c, SNMP 3, SUNAPI |
| Lens Construction | |
| Diagonal Field of View (degree) | 34.2 |
| Focus Adjustment | Manual |
| Horizontal Field of View (degree) | 30.4 |
| Lens Iris | F/8.0 |
| Lens System |
|
| Min Focus Distance | 15 cm |
| Type | Fixed focal |
| Vertical Field of View (degree) | 16.6 |
| Miscellaneous | |
| Color | Black, RAL 9005 |
| Compliant Standards | EMC, FCC 47 CFR Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), CE/UKCA, EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, KS C 9832 Class A, KS C 9835, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, IEC/EN 62471, EN 60068-2-6, EN 60068-2-27, NEMA TS-2 (2.2.7-2.2.9), IEC/EN 60529 IP67, IEC/EN 60529 IP66, IEC/EN 62262 IK10 |
| Power | |
| Power Device | 13.7 watt |
| Power Requirements | DC 24 V |
