Hanwha Vision PNO-A9311RLP
MSRP$3,500.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Hanwha Vision PNO-A9311RLP
- Network surveillance camera
- bullet
- color (Day&Night)
- 3840 x 2160
- auto iris
- motorized
- audio
- composite, USB
- GbE
- MJPEG, H.264, H.265
- DC 12 V / PoE Plus
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $3,500.00 |
| Mfr Part #: | PNO-A9311RLP |
| SHI Part #: | 48052206 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hanwha Vision PNO-A9311RLP - Network surveillance camera - bullet - color (Day&Night) - 3840 x 2160 - auto iris - motorized - audio - composite, USB - GbE - MJPEG, H.264, H.265 - DC 12 V / PoE Plus |
| Manufacturer | HANWHA VISION |
| MSRP | $3,500.00 |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 13.62 cm |
| Dimensions & Weight / Height | 35.87 cm |
| Dimensions & Weight / Weight | 3.2 kg |
| Dimensions & Weight / Width | 13.62 cm |
| Header / Brand | Hanwha Vision |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Capture Resolution | 1024 x 768, 1280 x 1024, 1280 x 720, 1280 x 960, 1600 x 1200, 1920 x 1080, 2048 x 1536, 2560 x 1440, 2592 x 1944, 2688 x 1520, 3072 x 1728, 3840 x 2160, 640 x 360, 640 x 480, 720 x 480, 720 x 576, 800 x 448, 800 x 600 |
| Digital Video Format | MJPEG, H.264, H.265 |
| Exposure Range | 1/5 sec - 1/12000 sec |
| Features | Auto ICR, Backlight Compensation (BLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNR) V, Digital Image Stabilization (DIS), built-in gyroscope, image masking, Automatic Tracing White (ATW), Automatic White Balance Control (AWC), image flip, image mirror, Hallway View, network disconnection trigger, alarm function, notification picture to FTP, notification picture to E-mail, NAS alerts, Handover, WiseIR, WiseNR II, Variable Bitrate (VBR), Constant Bitrate (CBR), Multicast Streaming, Unicast Streaming, digest authentication, IP address filtering, user access log, 802.1x authentication, TPM 2.0 module, secure boot, ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support, ONVIF (Profile M) support, brute force delay protection, vehicle model recognition, vehicle make recognition, vehicle color recognition, Smart Search, WiseStream II support, License plate recognition (LPR), Automatic Number Plate Recognition (ANPR), vehicle speed detection, dual lane |
| Flash Memory | 1024 MB |
| Frame Rate (max) | 30 frames per second |
| Infrared Distance | 70 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 3840 x 2160 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 4 GB |
| Type | Color - Day&Night - fixed |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -40 °C |
| Relative Humidity (operating) | 0 - 90% RH |
| Expansion / Connectivity | |
| Encryption Algorithm | FIPS 140-2 Level 2 |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Formats | G.726, ADPCM, AAC-LC, G.711, U-LAW |
| Audio Support | Yes |
| Connectivity Technology | Wired |
| Depth | 13.62 cm |
| Device Type | Network surveillance camera |
| Form Factor | Bullet |
| Height | 35.87 cm |
| Weight | 3.2 kg |
| Width | 13.62 cm |
| Image Sensor | |
| Type | CMOS 1/1.8" |
| Interfaces | |
| Alarm Inputs Qty | 1 |
| Alarm Outputs Qty | 1 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, UDP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, UPnP, LLDP, SRTP, MQTT, Bonjour, EAP |
| Video | Composite video, USB |
| Lens Construction | |
| Diagonal Field of View (degree) | 2.52 - 69.18 |
| Focal Length | 6.91 mm - 214.7 mm |
| Horizontal Field of View (degree) | 2.2 - 60.92 |
| Lens Iris | F/1.36-4.6 auto iris (P-Iris) |
| Min Focus Distance | 3 m |
| Optical Zoom | 31 x |
| Type | Motorized zoom |
| Vertical Field of View (degree) | 1.24 - 35.26 |
| Miscellaneous | |
| Color | White, RAL 9003 |
| Compliant Standards | NEMA Type 4X, IP67, IP66, IK10, FCC 47 CFR Part 15 Subpart B Class A, ICES-3(A)/NMB-3(A), UKCA, EN 55032 Class A, EN 50130-4, EN 61000-3-2, EN 61000-3-3, VCCI-CISPR 32 Class A, AS/NZS CISPR 32 Class A, UL 62368-1, CAN/CSA-C22.2 No. 62368-1, IEC/EN 62471, IEC/EN 63000 |
| Included Accessories | 32 GB microSD card |
| Power | |
| Power Requirements | DC 12 V / PoE Plus |
| Software / System Requirements | |
| Software Included | Wisenet Road AI |
