Lenovo ThinkStation P7 30F2
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Lenovo ThinkStation P7 30F2
- Tower 1 x Xeon W5-3423 / up to 4.2 GHz
- vPro Enterprise
- RAM 128 GB
- SSD 512 GB
- TCG Opal Encryption, NVMe, Performance, SSD 15.3 TB
- Radeon PRO W6400
- Gigabit Ethernet, 10 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E)
- Win 11 Pro for Workstations
- monitor: none
| Additional Details | |
|---|---|
| Mfr Part #: | 30F2S1SK00 |
| SHI Part #: | 47601430 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | Lenovo |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | Lenovo ThinkStation P7 30F2 - Tower 1 x Xeon W5-3423 / up to 4.2 GHz - vPro Enterprise - RAM 128 GB - SSD 512 GB - TCG Opal Encryption, NVMe, Performance, SSD 15.3 TB - Radeon PRO W6400 - Gigabit Ethernet, 10 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E) - Win 11 Pro for Workstations - monitor: none |
| Manufacturer | Lenovo |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Tower |
| Dimensions & Weight / Depth | 50.8 cm |
| Dimensions & Weight / Height | 43.44 cm |
| Dimensions & Weight / Weight | 24.5 kg |
| Dimensions & Weight / Width | 17.5 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 512 GB |
| Hard Drive / Interface | PCI Express 4.0 x4 |
| Hard Drive / Interface Type | PCI Express 4.0 x4 |
| Header / Brand | Lenovo |
| Mainboard / Chipset Type | Intel W790 |
| Mainboard / Processor Socket | FCLGA4677 Socket |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 11 Pro for Workstations |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 2.1 GHz |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 12-core |
| Processor / Processor Number | W5-3423 |
| Processor / Type | Xeon |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 2200 MHz |
| RAM / Technology | DDR5 SDRAM |
| System / Hard Drive Capacity | 15.812 TB |
| System / Platform Technology | Intel vPro Enterprise |
| System / Type | Workstation |
| Video Memory / Technology | GDDR6 SDRAM |
| Video Output / Graphics Processor | AMD Radeon PRO W6400 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Cache Memory | |
| Cache Per Processor | 30 MB |
| Installed Size | 30 MB |
| Dimensions & Weight | |
| Depth | 50.8 cm |
| Height | 43.44 cm |
| Weight | 24.5 kg |
| Width | 17.5 cm |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays |
|
| Interfaces |
|
| Slots |
|
| General | |
| Built-in Devices | Speaker |
| Embedded Security | Discrete Trusted Platform Module (TPM 2.0) Security Chip |
| Platform Technology | Intel vPro Enterprise |
| Product Form Factor | Tower |
| Type | Workstation |
| Graphics Controller | |
| Graphics Processor | AMD Radeon PRO W6400 |
| Video Interfaces | DisplayPort |
| Video Memory | 4 GB GDDR6 SDRAM |
| Hard Drive | |
| Capacity | 1 x 512 GB |
| Features | TCG Opal Encryption, NVM Express (NVMe), Performance |
| Interface Type | PCI Express 4.0 x4 |
| Manufacturer | Samsung |
| Type | SSD - M.2 2280 |
| Hard Drive (2nd) | |
| Capacity | 1 x 15.3 TB |
| Interface Class | PCI Express |
| Interface Type | NVM Express U.3 |
| Manufacturer | Micron |
| Type | SSD |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Miscellaneous | |
| Compliant Standards | RoHS, FIPS 140-2, TCG Certified |
| Included Accessories | M.2 SSD Flex adapter, PCIe to M.2 riser card |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), chassis intrusion switch |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, 10 Gigabit Ethernet, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.1, IEEE 802.11ax (Wi-Fi 6E) |
| Ethernet Controller | Marvell AQtion AQC-113C, Intel I219-LM |
| Ethernet Ports | 1 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), dual stream (2x2), Intel Active Management Technology (AMT) 16 |
| Interface (Bus) Type | M.2 Card |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 210 |
| Operating System / Software | |
| OS Provided | Windows 11 Pro for Workstations |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| 80 PLUS Certification | 80 PLUS Platinum |
| Device Type | Power supply |
| Efficiency | 92% |
| Power Provided | 1000 watt |
| Voltage Required | AC 100-240 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel W790 |
| Clock Speed | 2.1 GHz |
| CPU | Intel Xeon W5-3423 |
| CPU Qty | 1 |
| CPU Socket | FCLGA4677 Socket |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.2 GHz |
| Number of Cores | 12-core |
| RAM | |
| Configuration Features | 8 x 16 GB |
| Effective Memory Speed | 2200 MHz |
| Form Factor | DIMM 288-pin |
| Installed Size | 128 GB (installed) / 1 TB (max) |
| Rated Memory Speed | 2200 MHz |
| Slots | 8 (total) / 0 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5 |
| Type | 1 x RAID |
| Storage Controller (2nd) | |
| Controller Interface Type | PCI Express |
| Type | 1 x NVMe |
| Sustainability Information | |
| TCO Certified | TCO Certified Desktops 9 |
