GX075-V3 TOUCH DISPLAY
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
GX075-V3 TOUCH DISPLAY
| Additional Details | |
|---|---|
| Mfr Part #: | GX175-V3 |
| SHI Part #: | 47434163 |
| Category: | Input devices |
| UNSPSC: | 43211700 |
| Manufacturer: | Smart |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Input devices |
| Description | GX075-V3 TOUCH DISPLAY |
| Manufacturer | Smart |
| UNSPSC | 43211700 |
| Main Specifications | |
| Height | 6.00 |
| Length | 71.00 |
| UPC | 0628012403420 |
| Width | 45.00 |
| Audio System | |
| Output Power / Total | 40 watt |
| Speaker System | 2 speakers |
| Speakers | 2 x main channel speaker - 20 watt |
| Connections | |
| Connector Type |
|
| Dimensions & Weight (Shipping) | |
| Depth (Shipping) | 16 cm |
| Height (Shipping) | 128.5 cm |
| Weight (Shipping) | 71 kg |
| Width (Shipping) | 182 cm |
| Display | |
| Additional Features | Infrared touch technology, simultaneous tool differentiation, Object Awareness, Silktouch, split screen, picture in picture (no tuner), Over-the-Air Update (OTA) |
| Backlight Life | 50,000 hour(s) |
| Brightness | 400 cd/m² |
| Coating | Heat-tempered glass, anti-glare |
| Commercial Features | Open Pluggable Standard (OPS) support |
| Display Format | 4K UHD (2160p) |
| Display Menu Language | Danish, Hungarian, Czech, Indonesian, Thai, Chinese (traditional), Chinese (simplified), Vietnamese, Ukrainian, English, German, French, Italian, Norwegian, Portuguese, Polish, Finnish, Swedish, Russian, Spanish, Dutch, Greek, Turkish, Arabic, Lithuanian, Romanian, Japanese, Korean |
| Frame Rate & Enhancement Technology | 60 Hz Refresh Rate |
| Image Aspect Ratio | 16:9 |
| LCD Backlight Technology | LED backlight |
| Resolution | 3840 x 2160 |
| Response Time | 8 ms |
| Touchpoints Qty | 20 |
| Viewing Angle | 178° |
| Environmental Parameters | |
| Humidity Range Operating | 20 - 80% RH (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Combined With | Whiteboard and touchscreen (multi touch) |
| Commercial Use | Yes - interactive |
| Depth | 8.6 cm |
| Diagonal Class | 75" |
| Enclosure Color | Black |
| HDMI Ports Qty | 3 ports |
| Height | 103.3 cm |
| Modes | Overlay Mode |
| Operating System | Android OS 11 |
| PC Interface | DisplayPort, VGA (HD-15), USB-C |
| Platform | Android |
| Power Consumption Operational | 88 watt |
| Product Type | LED-backlit LCD flat panel display |
| Protection | Bonded glass |
| Sensors | Ambient light sensor (ALS), Infrared (IR) |
| Series | GX (V3) Series |
| TV Tuner | No tuner |
| TV Tuner Presence | No |
| Video Interface | HDMI |
| Weight | 52 kg |
| Width | 171.8 cm |
| Media Player | |
| Configuration | Quad-Core - 8 GB DDR4 - 64 GB |
| USB Port | Yes |
| USB Ports Qty | 9 |
| Miscellaneous | |
| Cables Included | USB type A to USB type B cable - 5 m |
| Compliant Standards | HDCP 1.4, HDCP 2.2, DisplayPort 1.2, cULus, FCC, ISED, TSCA, CONEG, UKCA, LVD, CB, EMCD, RED, REACH, RoHS, WEEE, POP, RCM, IEEE 802.1x, CP65 |
| Included Accessories | 2 pens, SMART Notebook software, SMART Product Drivers, SMART Ink, 2 antennas |
| Network & Internet Multimedia | |
| Bluetooth Version | Bluetooth 5.0 |
| Connect & Share | Screen Share |
| Connectivity | Wi-Fi, LAN, Bluetooth |
| Encryption | WPA, WEP, WPA2, WPA3-PSK |
| Functionality | WEB browsing, cloud storage playback |
| LAN Protocol | Gigabit Ethernet |
| Wi-Fi Protocol | 802.11ax |
| Power | |
| Input Voltage | AC 100-240 V (50/60 Hz) |
| Power Consumption Stand by | 0.5 watt |
| Power Device | Power supply |
| Remote Control | |
| Battery Form Factor | AAA type |
| Battery Included | Yes |
| Battery Included Qty | 2 |
| Battery Required Qty | 2 |
| Type | Remote control |
| Stands & Mounts | |
| Flat Panel Mount Interface | 800 x 400 mm |
| VESA Compatibility | Yes |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
