Hanwha Vision WiseNet X XNB-8002
MSRP$950.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Hanwha Vision WiseNet X XNB-8002
- Network surveillance camera (no lens)
- box
- color (Day&Night)
- 6 MP
- 3328 x 1872
- C/CS-mount
- auto iris
- audio
- composite
- GbE
- H.265, H.264, MJPEG
- DC 12 V / AC 24 V / PoE
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $950.00 |
| Mfr Part #: | XNB-8002 |
| SHI Part #: | 46400224 |
| Category: | Security cameras |
| UNSPSC: | 46171610 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Security cameras |
| Description | Hanwha Vision WiseNet X XNB-8002 - Network surveillance camera (no lens) - box - color (Day&Night) - 6 MP - 3328 x 1872 - C/CS-mount - auto iris - audio - composite - GbE - H.265, H.264, MJPEG - DC 12 V / AC 24 V / PoE |
| Manufacturer | HANWHA VISION |
| MSRP | $950.00 |
| UNSPSC | 46171610 |
| Main Specifications | |
| Dimensions & Weight / Depth | 16.5 cm |
| Dimensions & Weight / Height | 6.7 cm |
| Dimensions & Weight / Weight | 880 g |
| Dimensions & Weight / Width | 8.1 cm |
| Header / Brand | Hanwha Techwin |
| Miscellaneous / Product Color | Black |
| Packaged Quantity | 1 |
| System Requirements / OS Required |
|
| Camera | |
| Digital Video Capture Resolution | 3328 x 1872, 3072 x 1728, 2592 x 1944, 2688 x 1520, 1920 x 1080, 1600 x 1200, 1280 x 1024, 1280 x 960, 1280 x 720, 1024 x 768, 800 x 600, 800 x 448, 720 x 576, 720 x 480, 640 x 480, 640 x 360, 320 x 240 |
| Digital Video Format | H.265, H.264, MJPEG |
| Exposure Range | 1/5 sec - 1/12000 sec |
| Features | WiseStream II support, Extreme WDR, loitering detection, Directional Detection, Defocus Detection, fog detection, tamper-detection, Motion Detection Technology, shock detection, face detection, Object Detection, Hallway View, sound classification, built-in gyroscope, Digital Image Stabilization (DIS), Backlight Compensation (BLC), Highlight Compensation (HLC), Wide Dynamic Range (WDR), Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNRV), Defog, Privacy Mask Function, Gain Control, auto white balance, Lens Distortion Compensation (LDC), image flip, image mirror, digital auto tracking, Virtual Line detection, Audio Detection, body detection, people counting, queue management, Heat Map, Smart Codec, Variable Bitrate (VBR), Constant Bitrate (CBR), Unicast Streaming, Multicast Streaming, IP address filtering, ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support, i-CS lens |
| Flash Memory | 512 MB |
| Frame Rate (max) | 30 frames per second |
| Max Digital Video Resolution | 3328 x 1872 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 4 GB |
| Type | Color - Day&Night - fixed |
| Video Format | NTSC, PAL |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | -10 °C |
| Relative Humidity (operating) | 0 - 95% RH (non-condensing) |
| Expansion / Connectivity | |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDXC Card, microSDHC Card |
| General | |
| Audio Formats | G.711, G.726, ADPCM, AAC-LC |
| Audio Support | Yes: two-way audio capability, built-in microphone |
| Connectivity Technology | Wired |
| Depth | 16.5 cm |
| Device Type | Network surveillance camera (no lens) |
| Form Factor | Box |
| Height | 6.7 cm |
| Weight | 880 g |
| Width | 8.1 cm |
| Image Sensor | |
| Type | 6 MP CMOS 1/2.8" |
| Interfaces | |
| Control Interface | RS-485 |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, UPnP, Bonjour, LLDP, SRTP, EAP |
| Video | Composite video |
| Lens Construction | |
| Lens Iris | Auto iris (DC, P-Iris) |
| Type | C/CS-mount |
| Miscellaneous | |
| Color | Black |
| Compliant Standards | IEEE 802.1x, IEEE 802.3af |
| Power | |
| Power Device | 12.95 Watt |
| Power Requirements | DC 12 V / AC 24 V / PoE |
| Software / System Requirements | |
| OS Required | Windows 8.1, Apple macOS 10.13 |
