HP Workstation Z2 Mini G5
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
HP Workstation Z2 Mini G5
- Mini 1 x Core i7 10700 / up to 4.8 GHz
- RAM 16 GB
- SSD 512 GB
- HP Z Turbo Drive, NVMe, TLC
- Quadro P620
- Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6)
- Win 10 Pro (includes Win 11 Pro License)
- monitor: none
- keyboard: US
- with HP Wolf Pro Security Edition (1 year)
| Additional Details | |
|---|---|
| Mfr Part #: | 804M5UA#ABA |
| SHI Part #: | 46213930 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | HP Workstation Z2 Mini G5 - Mini 1 x Core i7 10700 / up to 4.8 GHz - RAM 16 GB - SSD 512 GB - HP Z Turbo Drive, NVMe, TLC - Quadro P620 - Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) - Win 10 Pro (includes Win 11 Pro License) - monitor: none - keyboard: US - with HP Wolf Pro Security Edition (1 year) |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211507 |
| Main Specifications | |
| A/V Interface Type | PCI Express 3.0 x16 |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 21.6 cm |
| Dimensions & Weight / Height | 5.8 cm |
| Dimensions & Weight / Weight | 2.1 kg |
| Dimensions & Weight / Width | 21.6 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 512 GB |
| Hard Drive / Interface | PCI Express 3.0 x4 |
| Hard Drive / Interface Type | PCI Express 3.0 x4 |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel W480 |
| Mainboard / Processor Socket | FCLGA1200 Socket |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 Pro |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 2.9 GHz |
| Processor / Generation | 10 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 8-core |
| Processor / Processor Number | I7-10700 |
| Processor / Type | Core i7 |
| RAM / Data Integrity Check | Non-ECC |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 2933 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 512 GB |
| System / Type | Workstation |
| Video Memory / Technology | GDDR5 SDRAM |
| Video Output / Graphics Processor | NVIDIA Quadro P620 / Intel UHD Graphics 630 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Cache Memory | |
| Cache Per Processor | 16 MB |
| Installed Size | L3 cache - 16 MB |
| Dimensions & Weight | |
| Depth | 21.6 cm |
| Height | 5.8 cm |
| Weight | 2.1 kg |
| Width | 21.6 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 49.9 cm |
| Shipping Height | 29.8 cm |
| Shipping Width | 17 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| Slots |
|
| General | |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Product Form Factor | Mini |
| Type | Workstation |
| Graphics Controller | |
| Graphics Processor | NVIDIA Quadro P620 / Intel UHD Graphics 630 |
| Interface Type | PCIe 3.0 x16 |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Video Interfaces | DisplayPort |
| Video Memory | 4 GB GDDR5 SDRAM |
| Hard Drive | |
| Capacity | 1 x 512 GB |
| Features | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Interface Type | PCI Express 3.0 x4 |
| Type | SSD - M.2 2280 |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Keyboard Name | HP 320K |
| Localization & Layout | US |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | ACPI, RoHS, WEEE, Common Criteria EAL4+, CECP, low halogen |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Mouse Name | HP 320M |
| Networking | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6) |
| Ethernet Controller | Intel I219-LM |
| Features | Wake on LAN (WoL), PXE support, auto-uplink (auto MDI/MDI-X), dual stream (2x2) |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6 AX 201 |
| Operating System / Software | |
| OS Provided | Windows 10 Pro (available through downgrade rights from Windows 11 Pro) + Windows 11 Pro License - English |
| Software | HP Remote Graphics Software, HP Support Assistant, HP Performance Advisor, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP Image Assistant, HP Sure Click, HP Manageability Integration Kit, HP Sure Sense, HP Sure Admin, HP Sure Recover Gen3, HP Client Security Manager Gen6, HP Sure Run Gen3, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Start Gen6 |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Efficiency | 90% |
| Power Factor Correction | Yes (active) |
| Power Provided | 280 watt |
| Voltage Required | AC 90-264 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel W480 |
| Clock Speed | 2.9 GHz |
| CPU | Intel Core i7 (10th Gen) 10700 |
| CPU Qty | 1 |
| CPU Socket | FCLGA1200 Socket |
| CPU Upgradability | Upgradable |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.8 GHz |
| Number of Cores | 8-core |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0 |
| RAM | |
| Configuration Features | 1 x 16 GB |
| Effective Memory Speed | 2933 MHz |
| Form Factor | SO-DIMM 260-pin |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Rated Memory Speed | 3200 MHz |
| Slots | 2 (total) / 1 (empty) |
| Technology | DDR4 SDRAM - non-ECC |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1 |
| Type | 1 x SATA |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
