Hanwha Vision WiseNet X XND-8093RV
MSRP$1,850.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Hanwha Vision WiseNet X XND-8093RV
- Network surveillance camera
- dome
- color (Day&Night)
- 6 MP
- 3328 x 1872
- auto iris
- motorized
- audio
- composite
- GbE
- H.265, H.264, MJPEG
- DC 12 V / PoE Plus Class 4
- TAA Compliant
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $1,850.00 |
| Mfr Part #: | XND-8093RV/KEX |
| SHI Part #: | 46012905 |
| Category: | Digital cameras |
| UNSPSC: | 45121504 |
| Manufacturer: | HANWHA VISION |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Digital cameras |
| Description | Hanwha Vision WiseNet X XND-8093RV - Network surveillance camera - dome - color (Day&Night) - 6 MP - 3328 x 1872 - auto iris - motorized - audio - composite - GbE - H.265, H.264, MJPEG - DC 12 V / PoE Plus Class 4 - TAA Compliant |
| Manufacturer | HANWHA VISION |
| MSRP | $1,850.00 |
| UNSPSC | 45121504 |
| Main Specifications | |
| Dimensions & Weight / Depth | 16 cm |
| Dimensions & Weight / Height | 12.5 cm |
| Dimensions & Weight / Weight | 1.6 kg |
| Dimensions & Weight / Width | 16 cm |
| Header / Brand | Hanwha Vision |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Camera | |
| Digital Video Format | H.265, H.264, MJPEG |
| Exposure Range | 2 sec - 1/12000 sec |
| Features | WiseIR, Extreme Wide Dynamic Range (E-WDR), WiseNR II, WiseStream III support, Object Detection, Intelligent Video Analysis (IVA), Virtual Line detection, loitering detection, intrusion detection, Defocus Detection, Motion Detection Technology, tamper-detection, fog detection, Audio Detection, sound classification, shock detection, appearing / disappearing detection, Metadata, Backlight Compensation (BLC), Highlight Compensation (HLC), Samsung Super Dynamic Range (SSDR), Samsung Super Noise Reduction (SSNRV), built-in gyroscope, Defog, Privacy Mask Function, Gain Control, Lens Distortion Compensation (LDC), image flip, image mirror, Hallway View, people counting, queue management, Heat Map, Constant Bitrate (CBR), Variable Bitrate (VBR), Unicast Streaming, Multicast Streaming, Trusted Platform Module (TPM), IP address filtering, ONVIF (Profile S) support, ONVIF (Profile G) support, ONVIF (Profile T) support |
| Flash Memory | 512 MB |
| Infrared Distance | 70 m |
| Infrared LEDs | Yes |
| Max Digital Video Resolution | 3328 x 1872 |
| Minimum Illumination |
|
| Motion Detection | Yes |
| RAM | 4 GB |
| Type | Color - Day&Night - fixed |
| Video Capture | 3328 x 1872 @ 30 fps |
| Video Format | NTSC, PAL |
| Environmental Parameters | |
| Max Operating Temperature | 50 °C |
| Min Operating Temperature | -25 °C |
| Relative Humidity (operating) | 0 - 95% (non-condensing) |
| Expansion / Connectivity | |
| Ports |
|
| Supported Memory Cards | microSD Card, microSDHC Card, microSDXC Card |
| General | |
| Audio Formats | G.711, U-LAW, G.726, ADPCM, AAC-LC |
| Audio Support | Yes: two-way audio capability |
| Connectivity Technology | Wired |
| Depth | 16 cm |
| Device Type | Network surveillance camera |
| Form Factor | Dome |
| Height | 12.5 cm |
| Weight | 1.6 kg |
| Width | 16 cm |
| Image Sensor | |
| Type | 6 MP CMOS 1/1.8" |
| Interfaces | |
| Network Interface | Ethernet 10Base-T/100Base-TX/1000Base-T |
| Network Protocols | IPv4, IPv6, TCP/IP, UDP/IP, RTP, RTCP, RTSP, NTP, HTTP, HTTPS, SSL, TLS, DHCP, FTP, SMTP, ICMP, IGMP, SNMP 1, SNMP 2c, SNMP 3, ARP, DNS, DDNS, QOS, UPnP, Bonjour, LLDP, SRTP, EAP |
| Video | Composite video |
| Lens Construction | |
| Diagonal Field of View (degree) | 17.1 - 48.7 |
| Focal Length | 10.9 mm - 29 mm |
| Focus Adjustment | Manual |
| Horizontal Field of View (degree) | 15 - 42 |
| Lens Iris | F/1.7-1.73 auto iris (DC) |
| Min Focus Distance | 2.5 m |
| Optical Zoom | 2.7 x |
| Type | Motorized zoom |
| Vertical Field of View (degree) | 8.4 - 22.8 |
| Miscellaneous | |
| Color | White, RAL 9003 |
| Compliant Standards | IP52, IK10, FIPS 140-2 Level 2, IEEE 802.1x, IEEE 802.3at |
| TAA Compliant | Yes |
| Panning | |
| Range (degree) | 0 to 360 |
| Power | |
| Power Device | 22.5 Watt |
| Power Requirements | DC 12 V / PoE Plus Class 4 |
| Tilting | |
| Range (degree) | -45 to +85 |
