ASUS RS700A-E12-RS4U
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
ASUS RS700A-E12-RS4U
- Server
- rack-mountable 1U
- 2-way
- no CPU
- RAM 0 GB
- SATA/PCI Express
- hot-swap 3.5" bay(s)
- no HDD
- AST2600
- 10 Gigabit Ethernet
- no OS
- monitor: none
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | RS700A-E12-RS4U-16W1G |
| SHI Part #: | 45828884 |
| Category: | Servers |
| UNSPSC: | 43211501 |
| Manufacturer: | ASUS |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Servers |
| Description | ASUS RS700A-E12-RS4U - Server - rack-mountable 1U - 2-way - no CPU - RAM 0 GB - SATA/PCI Express - hot-swap 3.5" bay(s) - no HDD - AST2600 - 10 Gigabit Ethernet - no OS - monitor: none |
| Manufacturer | ASUS |
| MSRP | $2,830.00 |
| UNSPSC | 43211501 |
| Main Specifications | |
| Chassis / Form Factor | Rack-mountable |
| Chassis / Server Storage Bays | Hot-swap |
| Chassis / Server Swappable Drive Interface | SATA/PCI Express |
| Dimensions & Weight / Depth | 84.25 cm |
| Dimensions & Weight / Height | 4.385 cm |
| Dimensions & Weight / Weight | 13.93 kg |
| Dimensions & Weight / Width | 44.9 cm |
| Display / Type | None. |
| Header / Brand | ASUS |
| Mainboard / Processor Socket | Socket SP5 |
| Miscellaneous / Product Color |
|
| Networking / Data Link Protocol | 10 Gigabit Ethernet |
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | No operating system |
| Packaged Quantity | 1 |
| Processor / Type | No CPU |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Technology | DDR5 SDRAM |
| System / Hard Drive Capacity | 0 GB |
| System / Type | Server |
| Video Output / Graphics Processor | ASPEED AST2600 |
| Dimensions & Weight | |
| Depth | 84.25 cm |
| Height | 4.385 cm |
| Weight | 13.93 kg |
| Width | 44.9 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 18.93 kg |
| Environmental Parameters | |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Bays | 4 (total) / 4 (free) x hot-swap 3.5" |
| Interfaces |
|
| Slots |
|
| General | |
| Hot-Swap Bays Qty | 4 |
| Product Form Factor | Rack-mountable - 1U |
| Server Scalability | 2-way |
| Type | Server |
| Graphics Controller | |
| Graphics Processor | ASPEED AST2600 |
| Video Interfaces | VGA |
| Video Memory | 64 MB |
| Hard Drive | |
| Type | No HDD |
| Miscellaneous | |
| Compliant Standards | FCC Class A certified, BSMI, CB, C-Tick |
| Included Accessories | ASMB10-iKVM Remote Management Card |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Data Link Protocol | 10 Gigabit Ethernet |
| Ethernet Controller | Intel X710-AT2 |
| Ethernet Ports | 2 x 10 Gigabit Ethernet |
| Features | KVM over IP support |
| Operating System / Software | |
| OS Provided | No operating system |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| 80 PLUS Certification | 80 PLUS Platinum |
| Device Type | Power supply |
| Installed Qty | 2 |
| Max Supported Qty | 2 |
| Power Provided | 1600 watt |
| Voltage Required | AC 100-127/200-240 V (50/60 Hz) |
| Processor / Chipset | |
| CPU | No CPU |
| CPU Socket | Socket SP5 |
| CPU Upgradability | Upgradable |
| Max CPU Qty | 2 |
| RAM | |
| Features | 12-channel memory architecture, 3DS registered |
| Form Factor | DIMM 288-pin |
| Installed Size | 0 GB (installed) / 3072 GB (max) |
| RAM Supported | 3072 GB registered |
| Slots | 24 (total) / 24 (empty) |
| Technology | DDR5 SDRAM |
| Storage Controller | |
| Channel Qty | 4 |
| Controller Interface Type | SATA 6Gb/s |
| Type | 1 x SATA |
