Schneider Electric Easy UPS 3S E3SUPS10KFBS
MSRP$17,475.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
Schneider Electric Easy UPS 3S E3SUPS10KFBS
- UPS
- AC 208 V
- 10000 Watt
- 10000 VA
- 3-phase
- white, RAL 9003
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $17,475.00 |
| Mfr Part #: | E3SUPS10KFBS |
| SHI Part #: | 42815011 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | Schneider Electric Easy UPS 3S E3SUPS10KFBS - UPS - AC 208 V - 10000 Watt - 10000 VA - 3-phase - white, RAL 9003 |
| Manufacturer | APC by Schneider Electric |
| MSRP | $17,475.00 |
| UNSPSC | 39121011 |
| Main Specifications | |
| Dimensions & Weight / Depth | 96 cm |
| Dimensions & Weight / Height | 140 cm |
| Dimensions & Weight / Weight | 120 kg |
| Dimensions & Weight / Width | 38 cm |
| Header / Brand | Schneider |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Power Capacity (VA) | 10000 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 208 V |
| Product Type | UPS |
| Service & Support / Type | 1-year warranty |
| Dimensions & Weight | |
| Depth | 96 cm |
| Height | 140 cm |
| Weight | 120 kg |
| Width | 38 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 120 cm |
| Shipping Height | 159.5 cm |
| Shipping Weight | 152 kg |
| Shipping Width | 80 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 65 dBA |
| General | |
| Color | White, RAL 9003 |
| Device Type | UPS - external |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 1 year - on-site |
| Miscellaneous | |
| Compliant Standards | UL 1778, FCC Part 15 B, IEC 62040-3, IEC 62040-2, cTUVus, REACH, IP20, China RoHS, ISTA 2B, EU RoHS, Mercury-free |
| Features | Built-in static bypass, touch screen LCD display, double conversion |
| Included Accessories | Dust filter |
| Power Device | |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 40 - 70 Hz |
| Input Voltage | AC 208 V |
| Input Wiring | 3-phase |
| Output Voltage | AC 208 V 50/60 Hz |
| Power Capacity | 10000 Watt / 10000 VA |
| UPS Technology | On-line |
