Axiom C565e Series Desktop
MSRP$93.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Axiom C565e Series Desktop
- Solid state drive
- encrypted
- 120 GB
- internal
- SATA 6Gb/s
- 256-bit AES
- TCG Opal Encryption 2.0
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $93.00 |
| Mfr Part #: | AXG99089 |
| SHI Part #: | 42471741 |
| Category: | Solid state drive SSD |
| UNSPSC: | 43201830 |
| Manufacturer: | Axiom Memory |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Solid state drive SSD |
| Description | Axiom C565e Series Desktop - Solid state drive - encrypted - 120 GB - internal - SATA 6Gb/s - 256-bit AES - TCG Opal Encryption 2.0 |
| Manufacturer | Axiom Memory |
| MSRP | $93.00 |
| UNSPSC | 43201830 |
| Main Specifications | |
| Hard Drive / Capacity | 120 GB |
| Hard Drive / Hard Drive Type | Internal hard drive |
| Hard Drive / Interface | Serial ATA-600 |
| Hard Drive / Interface | Serial ATA-600 |
| Header / Brand | Axiom |
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Storage / Type | Solid state drive |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% |
| Max Operating Temperature | 70 °C |
| Max Storage Temperature | 85 °C |
| Min Operating Temperature | 0 °C |
| Min Storage Temperature | -40 °C |
| Shock Tolerance (operating) | 1500 g @ 0.5 ms |
| Vibration Tolerance (operating) | 3.1 g @ 2-500 Hz |
| Expansion & Connectivity | |
| Interfaces | 1 x SATA 6 Gb/s |
| General | |
| Capacity | 120 GB |
| Device Type | Solid state drive - internal |
| Encryption Algorithm | 256-bit AES |
| Features | Temperature sensor, Native Command Queuing (NCQ), TRIM support, Dynamic and Static Wear Leveling, StaticDataRefresh Technology, Garbage Collection technology, DRAM cache, DEVSLP SATA low power mode, LDPC error correction, Silicon Motion SM2258 controller, SLC cache, S.M.A.R.T. |
| Hardware Encryption | Yes |
| Interface | SATA 6Gb/s |
| NAND Flash Memory Type | 3D triple-level cell (TLC) |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | RoHS, ATA-8 ACS3 |
| TAA Compliant | Yes |
| Performance | |
| Drive Transfer Rate | 600 MBps (external) |
| Drive Writes Per Day (DWPD) | 0.27 |
| Internal Data Rate | 565 MBps (read) / 430 MBps (write) |
| Maximum 4KB Random Read | 36000 IOPS |
| Maximum 4KB Random Write | 88000 IOPS |
| SSD Endurance | 40 TB |
| Power | |
| Power Consumption |
|
| Reliability | |
| MTBF | 1,500,000 hours |
| Non-Recoverable Errors | 1 per 10^16 |
