HighPoint RocketRAID 3740C
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
HighPoint RocketRAID 3740C
- Storage controller (RAID)
- 16 Channel
- SATA 6Gb/s / SAS 12Gb/s
- low profile
- RAID RAID 0, 1, 5, 6, 10, 50, JBOD
- PCIe 3.0 x8
| Additional Details | |
|---|---|
| Mfr Part #: | RR3740C |
| SHI Part #: | 41938185 |
| Category: | Peripheral controller cards |
| UNSPSC: | 43201407 |
| Manufacturer: | HighPoint |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Peripheral controller cards |
| Description | HighPoint RocketRAID 3740C - Storage controller (RAID) - 16 Channel - SATA 6Gb/s / SAS 12Gb/s - low profile - RAID RAID 0, 1, 5, 6, 10, 50, JBOD - PCIe 3.0 x8 |
| Manufacturer | HighPoint |
| UNSPSC | 43201407 |
| Main Specifications | |
| Dimensions & Weight / Depth | 14.3 cm |
| Dimensions & Weight / Height | 6.88 cm |
| Dimensions & Weight / Width | 1.83 cm |
| General / Product Type | Storage controller (RAID) |
| Header / Brand | HighPoint |
| Miscellaneous / Product Color |
|
| Packaged Quantity | 1 |
| Storage Controller / Form Factor | Plug-in card |
| System Requirements / OS Required |
|
| Dimensions & Weight | |
| Depth | 14.3 cm |
| Height | 6.88 cm |
| Width | 1.83 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 4.8 cm |
| Shipping Height | 19.9 cm |
| Shipping Weight | 290 g |
| Shipping Width | 17 cm |
| Environmental Parameters | |
| Max Operating Temperature | 55 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Connections | 1 x PCIe 3.0 x8 |
| Interfaces | 4 x SATA 6Gb/s / SAS 12Gb/s - Mini SAS HD (SFF-8643) (internal) |
| General | |
| Device Type | Storage controller (RAID) - plug-in card - low profile |
| Host Bus | PCIe 3.0 x8 |
| Miscellaneous | |
| Compliant Standards | FCC, RoHS, WEEE, REACH |
| Features | Online Capacity Expansion (OCE), Online RAID Level Migration (RLM), Native Command Queuing (NCQ), BIOS plug and play support (PnP), Quick RAID Initialization, Staggered Drive Spin Up, Bootable RAID Array support, Storage Health Inspector, online array roaming |
| MTBF | 920,585 hours |
| Package Type | Retail |
| Software / System Requirements | |
| OS Required | Linux, FreeBSD, Microsoft Windows 7 or later, Microsoft Windows Server 2008 or later, Apple MacOS X 10.9 or later |
| Storage Controller | |
| Channel Qty | 16 |
| Data Transfer Rate | 12 Gbit/s |
| Interface | SATA 6Gb/s / SAS 12Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD |
| Supported Devices | Hard drive, disk array (RAID), solid state drive |
