HP t540 - Thin client
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
HP t540 - Thin client
- USFF 1 x Ryzen Embedded R1305G / up to 2.8 GHz
- RAM 8 GB
- flash
- eMMC 64 GB
- Radeon Vega 3
- Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6)
- Win 10 IoT Enterprise for Thin Clients
- monitor: none
- keyboard: US
- Smart Buy
| Additional Details | |
|---|---|
| Mfr Part #: | 2Q6W1UT#ABA |
| SHI Part #: | 41785457 |
| Category: | Thin client or diskless workstations |
| UNSPSC: | 43211506 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
Audio/Video Cables
- Video adapter
- DisplayPort (M) to HDMI (F)
- 4K support
- for HP 260 G4, t540; Desktop Pro 300 G6; Elite Slice G2; EliteDesk 805 G6; ProDesk 405 G6
- 19 cm
- for Elite 600 G9, 800 G9, t655; EliteDesk 80X G8; Pro t550; ProOne 440 G9; Workstation Z2 G9
Memory (RAM)
| General Information | |
|---|---|
| Category | Thin client or diskless workstations |
| Description | HP t540 - Thin client - USFF 1 x Ryzen Embedded R1305G / up to 2.8 GHz - RAM 8 GB - flash - eMMC 64 GB - Radeon Vega 3 - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6) - Win 10 IoT Enterprise for Thin Clients - monitor: none - keyboard: US - Smart Buy |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211506 |
| Main Specifications | |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 20 cm |
| Dimensions & Weight / Height | 20 cm |
| Dimensions & Weight / Weight | 1.4 kg |
| Dimensions & Weight / Width | 3.5 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 64 GB |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 IoT Enterprise for Thin Clients |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 1.5 GHz |
| Processor / Manufacturer | AMD |
| Processor / Number of Cores | Dual-Core |
| Processor / Processor Number | R1305G |
| Processor / Type | Ryzen Embedded |
| RAM / Data Integrity Check | Non-ECC |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 2400 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 64 GB |
| System / Type | Thin client |
| Video Output / Graphics Processor | AMD Radeon Vega 3 |
| Cache Memory | |
| Cache Per Processor | 4 MB |
| Installed Size | L3 cache - 4 MB |
| Dimensions & Weight | |
| Depth | 20 cm |
| Height | 20 cm |
| Weight | 1.4 kg |
| Width | 3.5 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Weight | 2.879 kg |
| Environmental Parameters | |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 10 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| Slots | 1 (total) / 0 (free) x M.2 Card |
| General | |
| Embedded Security | Trusted Platform Module (TPM) Security Chip |
| Localization | Language: English / region: United States |
| Product Form Factor | USFF |
| Type | Thin client |
| Graphics Controller | |
| Graphics Processor | AMD Radeon Vega 3 |
| Max Monitors Supported | 2 |
| Video Interfaces | DisplayPort |
| Hard Drive | |
| Capacity | 1 x 64 GB |
| Type | Flash - eMMC |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Keyboard Name | HP USB Business Slim Keyboard |
| Localization & Layout | US |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Compliant Standards | UL, VCCI, BSMI, GS, CB, CCC, FCC, KCC, WEEE, CISPR, ICES, ERP, CECP, RoHS2, SEPA, low halogen, EN |
| Included Accessories | HP Smart AC Adapter |
| Manufacturer Selling Program | HP Smart Buy |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Technology | Optical |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6) |
| Ethernet Controller | Realtek RTL8111HSH |
| Features | Dual stream (2x2) |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6 AX 200 |
| Operating System / Software | |
| OS Provided | Windows 10 IoT Enterprise for Thin Clients English |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Power Provided | 45 watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Processor / Chipset | |
| Clock Speed | 1.5 GHz |
| CPU | AMD Ryzen Embedded R1305G |
| CPU Qty | 1 |
| CPU Upgradability | Not upgradable |
| L2 cache | 2 x 512 KB |
| Max CPU Qty | 1 |
| Max Turbo Speed | 2.8 GHz |
| Number of Cores | Dual-Core |
| RAM | |
| Configuration Features | 1 x 8 GB |
| Effective Memory Speed | 2400 MHz |
| Form Factor | SO-DIMM 260-pin |
| Installed Size | 8 GB (installed) / 16 GB (max) |
| Rated Memory Speed | 2400 MHz |
| Slots | 1 (total) / 0 (empty) |
| Technology | DDR4 SDRAM - non-ECC |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| EPEAT Compliant | EPEAT Silver |
| TCO Certified | TCO Certified Desktops 9 |
