HP Workstation Z2 Mini G5

Login for Price
HP Workstation Z2 Mini G5
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Mini
  • 1 x Core i7 10700 / 2.9 GHz
  • vPro
  • RAM 16 GB
  • SSD 512 GB
HP Workstation Z2 Mini G5
  • Mini
  • 1 x Core i7 10700 / 2.9 GHz
  • vPro
  • RAM 16 GB
  • SSD 512 GB
  • TLC
  • Quadro P620 / UHD Graphics 630
  • GigE
  • WLAN: Bluetooth 5.0, 802.11a/b/g/n/ac/ax
  • Win 10 Pro 64-bit
  • monitor: none
  • keyboard: US
  • Smart Buy
  Additional Details
Mfr Part #: 2X3J0UT#ABA
SHI Part #: 41721927
Category: Desktop computers
UNSPSC: 43211507
Manufacturer: HP, Inc.
Product Type: Hardware

Keyboards and Keypads

HP 235 - Keyboard and mouse set
HP 235 - Keyboard and mouse set
  • wireless
  • US
  • Smart Buy
Login for Price
HP Desktop 320MK - Keyboard and mouse set
HP Desktop 320MK - Keyboard and mouse set
  • USB
  • US
  • Smart Buy
  • for Chromebook 11 G9, 14 G7; Chromebook x360; Elite x2; EliteBook 83X G8, 840, 84X G8, 85X G8
Login for Price

Monitors and Displays

HP E22 G5 - E-Series
HP E22 G5 - E-Series
  • LED monitor
  • 21.5"
  • 1920 x 1080 Full HD (1080p) @ 75 Hz
  • IPS
  • 250 cd/m²
  • 1000:1
Login for Price
HP P34hc G4 - P-Series
HP P34hc G4 - P-Series
  • LED monitor
  • curved
  • 34"
  • 3440 x 1440 WQHD @ 60 Hz
  • VA
  • 250 cd/m²
Login for Price
HP E24mv G4 Conferencing Monitor
HP E24mv G4 Conferencing Monitor
  • E-Series
  • LED monitor
  • 23.8"
  • 1920 x 1080 Full HD (1080p) @ 60 Hz
  • IPS
  • 250 cd/m²
Login for Price
General Information
CategoryDesktop computers
DescriptionHP Workstation Z2 Mini G5 - Mini - 1 x Core i7 10700 / 2.9 GHz - vPro - RAM 16 GB - SSD 512 GB - TLC - Quadro P620 / UHD Graphics 630 - GigE - WLAN: Bluetooth 5.0, 802.11a/b/g/n/ac/ax - Win 10 Pro 64-bit - monitor: none - keyboard: US - Smart Buy
ManufacturerHP, Inc.
UNSPSC43211507
Main Specifications
A/V Interface TypePCI Express 3.0 x16
Chassis / Form FactorUltra small form factor
Dimensions & Weight / Depth21.6 cm
Dimensions & Weight / Height5.8 cm
Dimensions & Weight / Weight2.1 kg
Dimensions & Weight / Width21.6 cm
Display / TypeNone.
Hard Drive / Capacity512 GB
Header / BrandHP
Header / Country KitsUnited States
Header / LocalizationEnglish
Mainboard / Chipset TypeIntel W480
Mainboard / Processor SocketLGA1200 Socket
Miscellaneous / Product Color
  • Black
  • Gray
Networking / Data Link Protocol
  • Bluetooth 5.0
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax (Wi-Fi 6)
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
Networking / Wireless LAN SupportedYes
Networking / Wireless Protocol
  • 802.11a/b/g/n/ac/ax
  • Bluetooth 5.0
Optical Storage / Drive TypeNo optical drive
Optical Storage / TypeNone
OS Provided / TypeWindows 10 Pro 64-bit Edition
Packaged Quantity1
Processor / Clock Speed2.9 GHz
Processor / Generation10
Processor / ManufacturerIntel
Processor / Number of Cores8-core
Processor / Processor NumberI7-10700
Processor / TypeCore i7
RAM / Data Integrity CheckNon-ECC
RAM / Form FactorSO-DIMM 260-pin
RAM / Memory Speed2933 MHz
RAM / TechnologyDDR4 SDRAM
Service & Support / Type3-year warranty
System / Hard Drive Capacity512 GB
System / Platform TechnologyIntel vPro Platform
System / TypeWorkstation
Video Memory / TechnologyGDDR5 SDRAM
Video Output / Graphics ProcessorNVIDIA Quadro P620 / Intel UHD Graphics 630
Audio Output
Compliant StandardsHigh Definition Audio
Cache Memory
Cache Per Processor16 MB
Installed Size16 MB
Dimensions & Weight
Depth21.6 cm
Height5.8 cm
Weight2.1 kg
Width21.6 cm
Dimensions & Weight (Shipping)
Shipping Depth49.9 cm
Shipping Height29.8 cm
Shipping Width17 cm
Environmental Parameters
Humidity Range Operating10 - 85% (non-condensing)
Max Operating Temperature35 °C
Min Operating Temperature5 °C
Expansion / Connectivity
Interfaces
  • 4 x USB 3.1 Gen 2 (2 rear, 2 side) (one of them is charging)
  • 1 x headphones/microphone (1 side)
  • 1 x LAN (Gigabit Ethernet)
  • 2 x DisplayPort
  • 1 x USB-C 3.1 Gen 2 (1 side) (charging)
Slots
  • 1 (total) / 0 (free) x M.2 Card - 2230 (x1 mode)
  • 2 M.2 Card - 2280 (x4 mode)
  • 1 (total) / 0 (free) x MXM (x16 mode)
General
Embedded SecurityTrusted Platform Module (TPM 2.0) Security Chip
LocalizationLanguage: English / region: United States
Platform TechnologyIntel vPro Platform
Product Form FactorMini
TypeWorkstation
Graphics Controller
Graphics ProcessorNVIDIA Quadro P620 / Intel UHD Graphics 630
Interface TypePCIe 3.0 x16
Max Monitors Supported3
Multi-GPU Configuration1 single GPU card / integrated GPU
Video InterfacesDisplayPort
Video Memory4 GB GDDR5 SDRAM
Hard Drive
Capacity1 x 512 GB
FeaturesTriple-level cell (TLC)
TypeSSD
Input Device
TypeMouse, keyboard
Keyboard
InterfaceUSB
Keyboard NameHP 320K
Localization & LayoutUS
Manufacturer Warranty
Service & SupportLimited warranty - parts and labor - 3 years - on-site
Miscellaneous
Compliant StandardsACPI, RoHS, WEEE, Common Criteria EAL4+, CECP, low halogen
Manufacturer Selling ProgramHP Smart Buy
Security Slot TypeKensington security slot
Theft/Intrusion ProtectionSecurity lock slot (cable lock sold separately)
Monitor
Monitor TypeNone.
Mouse
Mouse NameHP 320M
Networking
Compliant StandardsIEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.0, IEEE 802.11ax (Wi-Fi 6)
Ethernet ControllerIntel I219-LM
FeaturesWake on LAN (WoL), PXE support, auto-uplink (auto MDI/MDI-X), dual stream (2x2)
Wireless LAN SupportedYes
Wireless NICIntel Wi-Fi 6 AX 201
Operating System / Software
OS ProvidedWindows 10 Pro 64-bit Edition English
SoftwareHP ZCentral Remote Boost 2020
Optical Storage
TypeNo optical drive
Power
Device TypePower adapter
Efficiency90%
Power Provided280 Watt
Voltage RequiredAC 120/230 V (50/60 Hz)
Processor / Chipset
Chipset TypeIntel W480
Clock Speed2.9 GHz
CPUIntel Core i7 (10th Gen) 10700
CPU Qty1
CPU SocketLGA1200 Socket
CPU UpgradabilityUpgradable
Max CPU Qty1
Max Turbo Speed4.8 GHz
Number of Cores8-core
Processor Main FeaturesHyper-Threading Technology, Intel Turbo Boost Technology 3
RAM
Configuration Features1 x 16 GB
Effective Memory Speed2933 MHz
FeaturesDual channel memory architecture
Form FactorSO-DIMM 260-pin
Installed Size16 GB (installed) / 64 GB (max)
Rated Memory Speed3200 MHz
Slots2 (total) / 1 (empty)
TechnologyDDR4 SDRAM - non-ECC
Storage Controller
RAID LevelRAID 0, RAID 1
Type1 x SATA
Sustainability Information
EPEAT CompliantEPEAT Gold
