ATEN VE8952R - Video/audio extender
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
ATEN VE8952R - Video/audio extender
- receiver
- up to 100 m
- for VanCryst VM1600A, VM3200, VM5404H, VM6809H, VS0801H
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | VE8952R |
| SHI Part #: | 41544525 |
| Category: | Serial port cards |
| UNSPSC: | 43201559 |
| Manufacturer: | ATEN |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Serial port cards |
| Description | ATEN VE8952R - Video/audio extender - receiver - up to 100 m - for VanCryst VM1600A, VM3200, VM5404H, VM6809H, VS0801H |
| Manufacturer | ATEN |
| MSRP | $899.00 |
| UNSPSC | 43201559 |
| Main Specifications | |
| Dimensions & Weight / Depth | 12.49 cm |
| Dimensions & Weight / Height | 2.9 cm |
| Dimensions & Weight / Weight | 680 g |
| Dimensions & Weight / Width | 16.6 cm |
| Header / Brand | ATEN |
| Networking / Connectivity Technology | Wired |
| Networking / Form Factor | External |
| Networking / Type | Video/audio extender |
| Packaged Quantity | 1 |
| Service & Support / Type | 3-year warranty |
| Compatibility Information | |
| Designed For | ATEN VanCryst VM1600A, VM3200, VM5404H, VM6809H, VS0801H |
| Dimensions & Weight | |
| Depth | 12.49 cm |
| Height | 2.9 cm |
| Weight | 680 g |
| Width | 16.6 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 80% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Device Type | Video/audio extender (receiver) |
| Form Factor | External |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | RoHS, KCC, FCC Part 15 A |
| Included Accessories | 4 foot pads, RS-232 terminal block |
| Networking | |
| Connectivity Technology | Wired |
| Features | HDCP compliant, 4K resolution support, metal housing, EDID Expert, HD video scaler |
| Max Resolution | 4096 x 2160 / 3840 x 2160 @ 30 Hz |
| Max Transfer Distance | 100 m |
| Remote Management Protocol | Telnet, HTTP, CLI |
| Power | |
| Power Consumption Operational | 5.22 Watt |
| Power Device | External power adapter |
