APC SurgeArrest Essential PE6U21W
MSRP$68.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
APC SurgeArrest Essential PE6U21W
- surge protector
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $68.00 |
| Mfr Part #: | PE6U21W |
| SHI Part #: | 37194505 |
| Category: | Surge suppressers |
| UNSPSC: | 39121610 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Surge suppressers |
| Description | APC SurgeArrest Essential PE6U21W - surge protector |
| Manufacturer | APC by Schneider Electric |
| MSRP | $68.00 |
| UNSPSC | 39121610 |
| Main Specifications | |
| Dimensions & Weight / Depth | 13.2 cm |
| Dimensions & Weight / Height | 13.5 cm |
| Dimensions & Weight / Weight | 690 g |
| Dimensions & Weight / Width | 6.9 cm |
| General / Subcategory | Surge protection and power conditioning |
| Header / Brand | APC |
| Miscellaneous / Product Color | White |
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 6 |
| Power Device / Voltage Required | AC 120 V |
| Product Type | Surge protector |
| Service & Support / Type | Limited lifetime warranty |
| Dimensions & Weight | |
| Depth | 13.2 cm |
| Height | 13.5 cm |
| Weight | 690 g |
| Width | 6.9 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 17.1 cm |
| Shipping Height | 13.8 cm |
| Shipping Weight | 770 g |
| Shipping Width | 12 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| General | |
| Color | White |
| Device Type | Surge protector - external |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - lifetime |
| Miscellaneous | |
| Cables Included | Power cable - integrated - 1.83 m |
| Compliant Standards | UL 1363, UL 1449, FCC Part 15 B, RoHS, cULus, REACH, UL 1310 |
| Equipment Protection Value | 50000 US Dollars |
| Features | On/off switch |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Input Voltage | AC 120 V |
| Max Electric Current | 15 A |
| Max Spike Current | 48000 A |
| Power Output Connectors Details |
|
| Surge Energy Rating | 1080 Joules |
| Surge Response Time | 1 ns |
| Surge Suppression | Yes |
