QNAP TES-3085U - NAS server

$10,046.00
QNAP TES-3085U - NAS server
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • 30 bays
  • rack-mountable
  • SATA 6Gb/s / SAS 12Gb/s
  • RAID RAID 0, 1, 5, 6, 10, 50, JBOD, 60
  • RAM 32 GB
QNAP TES-3085U - NAS server
  • 30 bays
  • rack-mountable
  • SATA 6Gb/s / SAS 12Gb/s
  • RAID RAID 0, 1, 5, 6, 10, 50, JBOD, 60
  • RAM 32 GB
  • Gigabit Ethernet / 10 Gigabit Ethernet
  • iSCSI support
  • 2U
  Additional Details
Price: $10,046.00
Mfr Part #: TES-3085U-D1548-32GR
SHI Part #: 33075555
Category: Electronic data storage equipment
UNSPSC: 43201800
Manufacturer: QNAP
Product Type: Hardware

Network Interface Cards

QNAP QXG-2G2T-I225 - Network adapter
QNAP QXG-2G2T-I225 - Network adapter
  • PCIe 2.0 x2 low profile
  • 2.5GBase-T x 2
  • for QNAP QGD-1600, TS-1232, 1253, 251, 253, 432, 453, 653, 832, 853, h1283, h977, TVS-672, 872
$93.00
QNAP QXG-2G4T-I225 - Network adapter
QNAP QXG-2G4T-I225 - Network adapter
  • PCIe 2.0 x4 low profile
  • 2.5GBase-T x 4
  • for QNAP TDS-16489, 16489U R2, TS-1886, 251, 2888, h1277, h1283, h977, TVS-1672, 672, 872, 972
$161.00
General Information
CategoryElectronic data storage equipment
DescriptionQNAP TES-3085U - NAS server - 30 bays - rack-mountable - SATA 6Gb/s / SAS 12Gb/s - RAID RAID 0, 1, 5, 6, 10, 50, JBOD, 60 - RAM 32 GB - Gigabit Ethernet / 10 Gigabit Ethernet - iSCSI support - 2U
ManufacturerQNAP
MSRP$8,499.00
UNSPSC43201800
Main Specifications
Dimensions & Weight / Depth48.45 cm
Dimensions & Weight / Height8.8 cm
Dimensions & Weight / Weight13.98 kg
Dimensions & Weight / Width43.9 cm
Header / BrandQNAP
Miscellaneous / Product ColorBlack
Networking / Data Link Protocol
  • 10 Gigabit Ethernet
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Optical Storage / TypeNone
Packaged Quantity1
Processor / Processor NumberD-1548
Processor / TypeXeon
Service & Support / Type5-year warranty
Storage / Rack-mountableRack-mountable
System Requirements / OS Required
  • Apple MacOS
  • Linux
  • Microsoft Windows 7 (32/64 bits)
  • Microsoft Windows Server 2008 R2
  • Microsoft Windows Server 2012
  • Microsoft Windows Server 2012 R2
  • UNIX
  • Windows 10 (32/64 bits)
  • Windows 8 (32/64 bits)
Environmental Parameters
Humidity Range Operating5 - 95% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Expansion / Connectivity
Expansion Bays
  • 24 (total) / 24 (free) x hot-swap - 2.5" / 3.5"
  • 6 (total) / 6 (free) - 2.5"
Expansion Slots
  • 4 (total) / 0 (free) x DIMM 288-pin
  • 1 (total) / 1 (free) x PCI Express 3.0 x8
  • 1 (total) / 1 (free) x PCI Express 2.0 x4
  • 1 (total) / 1 (free) x PCI Express 3.0 x4
  • 1 (total) / 1 (free) x PCI Express 3.0
Interfaces
  • 4 x Ethernet 1000Base-T - RJ-45
  • 2 x Ethernet 10Gb - SFP+
General
Built-in DevicesLED panel
Depth48.45 cm
Device TypeNAS server
Enclosure TypeRack-mountable - 2U
Height8.8 cm
Host ConnectivityGigabit Ethernet / 10 Gigabit Ethernet
Installed Devices / Modules Qty0 (installed) / 30 (max)
Total Storage Capacity0 GB
Weight13.98 kg ()
Width43.9 cm
Manufacturer Warranty
Service & SupportLimited warranty - 5 years
Miscellaneous
Cables Included4 x network cable
Compliant StandardsFIPS 140-2
FeaturesWake on LAN, AirPlay, built-in 4 cooling fans, hot-swappable fans
Networking
Compliant StandardsUPnP
Data Link Protocol10Mb LAN, 100Mb LAN, 1GbE, 10GbE
Encryption AlgorithmSSL, TLS, FIPS 140-2, 256-bit AES
FeaturesLoad balancing, LDAP support, wake on LAN (WOL), Syslog support, manageable, E-mail alert, print server, IPv6 support, High Availability, 256-bit encryption, firmware upgradable, proxy server, web server, backup server, download client, file sharing, event log, Trivial File Transfer Protocol (TFTP) support, Access Control List (ACL) support, SSH support, iTunes server, Jumbo Frames support, DHCP server, FTP server, SMS alert, BitTorrent Client, UPnP Media Server, Network Access Protection (NAP), reset button, bandwidth control, IPv4 support, surveillance station, teaming support, DLNA Media Server, Apple Time Machine compatible, LACP support, DHCP client, e-mail notification, cloud backup, VPN Server, SFTP client, SNMP support, Apple AirPlay, Dropbox support, Real-time Remote Replication (RTRR)
Network / Transport ProtocolTCP/IP, PPTP, iSCSI, SMTP, FTP, DHCP, Bonjour, SMB, DDNS, SFTP
Network Services CompatibilityMicrosoft Active Directory (AD), Apple Bonjour Protocol, File Level Security (ACLs), DHCP, DDNS, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV), SFTP
Remote Management ProtocolSNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH, CLI
Power
Installed Qty2
Max Supported Qty2
Power DeviceInternal power supply
Power Provided450 Watt
Power RedundancyYes
Power Redundancy Scheme1+1
Voltage RequiredAC 120/230 V (50/60 Hz)
Processor / Memory
Flash Memory Installed4 GB
Number of Cores8-core
Processors Installed1 x Intel Xeon D-1548 2 GHz
RAM32 GB (installed) / 128 GB (supported) - DDR4
Software / System Requirements
OS RequiredUNIX, Apple MacOS, Linux, Microsoft Windows Server 2008 R2, Microsoft Windows 7 (32/64 bits), Microsoft Windows Server 2012, Windows 8 (32/64 bits), Microsoft Windows Server 2012 R2, Windows 10 (32/64 bits)
Storage Operating SystemQNAP QES 1.1 / QTS 4.2
Storage Controller
Interface TypeSATA 6Gb/s / SAS 12Gb/s
RAID LevelRAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, JBOD, RAID 60
TypeRAID
