Tripp Lite SmartOnLine SVTX Series 3-Phase 380/400/415V 30kVA 27kW On-Line Double-Conversion UPS, Tower, Extended Run, SNMP Option
MSRP$15,471.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Tripp Lite SmartOnLine SVTX Series 3-Phase 380/400/415V 30kVA 27kW On-Line Double-Conversion UPS, Tower, Extended Run, SNMP Option
- UPS
- 48.9 A
- AC 220/230/240/380/400/415 V
- 27 kW
- 30000 VA
- 3-phase WYE (star) 9 Ah
- RS-232
- PFC
- RAL 9005
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $15,471.00 |
| Mfr Part #: | SVT30KX |
| SHI Part #: | 32857303 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | Tripp Lite |
| Product Type: | Hardware |
Computer Services
- Installation / configuration (for 3-phase 400V UPS)
- on-site
- evening/weekend hours
- response time: 10 business days
- for P/N: S3M10K1B, S3M10K2B, S3M10K3B, S3M10K-NIB, S3M15K2B, S3M15K3B, S3M15K-NIB, SVT20KX
MSRP $3,165.75
$2,114.00
- Installation / configuration (for 3-phase 400V UPS including 1 extra battery)
- on-site
- evening/weekend hours
- response time: 10 business days
- for P/N: S3M10K1B, S3M10K2B, S3M10K3B, S3M10K-NIB, S3M15K2B, S3M15K3B, S3M15K-NIB, SVT20KX
MSRP $3,600.00
$2,404.00
- Installation / configuration (for 3-phase 400V UPS)
- on-site
- business hours
- response time: 10 business days
- for P/N: S3M10K1B, S3M10K2B, S3M10K3B, S3M10K-NIB, S3M15K2B, S3M15K3B, S3M15K-NIB, SVT20KX
MSRP $2,315.25
$1,546.00
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | Tripp Lite SmartOnLine SVTX Series 3-Phase 380/400/415V 30kVA 27kW On-Line Double-Conversion UPS, Tower, Extended Run, SNMP Option - UPS - 48.9 A - AC 220/230/240/380/400/415 V - 27 kW - 30000 VA - 3-phase WYE (star) 9 Ah - RS-232 - PFC - RAL 9005 |
| Manufacturer | Tripp Lite |
| MSRP | $15,471.00 |
| UNSPSC | 39121011 |
| Main Specifications | |
| Dimensions & Weight / Depth | 30 cm |
| Dimensions & Weight / Height | 99.82 cm |
| Dimensions & Weight / Weight | 233.6 kg |
| Dimensions & Weight / Width | 81.28 cm |
| General / Subcategory | UPS |
| Header / Brand | Tripp Lite |
| Miscellaneous / Product Color | Black |
| Networking / Remote Management Interface | RS-232 |
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Power Capacity (VA) | 30000 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 220/230/240/380/400/415 V |
| Product Type | UPS |
| Service & Support / Type | 2-year warranty |
| Battery | |
| Capacity | 9 Ah |
| Run Time (Up To) |
|
| Voltage Provided | 12 V |
| Dimensions & Weight | |
| Depth | 30 cm |
| Height | 99.82 cm |
| Weight | 233.6 kg |
| Width | 81.28 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 95% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 65 dBA |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x expansion slot |
| Interfaces | 1 x management (RS-232) - 9 pin D-Sub (DB-9) |
| General | |
| Color | RAL 9005 |
| Device Type | UPS - Power Factor Correction (PFC) - external |
| Manufacturer Warranty | |
| Service & Support |
|
| Miscellaneous | |
| Cables Included |
|
| Compliant Standards | TUV, IEC 62040-2, RoHS, WEEE, EN 62040-1-1, EN 62040-2, IEC 62040-1, EN 62040-1 |
| Features | Audible alarm, emergency power off, LCD display, LED indicators, overvoltage protection, built-in bypass switch, cold-start function, cooling fan, Eco-Mode |
| Networking | |
| Remote Management Interface | RS-232 |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Efficiency | 92% AC mode |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | Hardwire |
| Input Voltage | AC 220/230/240/380/400/415 V |
| Input Wiring | 3-phase WYE (star) |
| Max Electric Current | 48.9 A |
| Output Voltage | AC 220/230/240/380/400/415 V ± 1% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 27 kW / 30000 VA |
| Power Factor (PF) | 0.9 |
| Power Output Connectors Details | Hardwire |
| Total Harmonic Distortion (THD) | 6 % |
| UPS Technology | On-line |
