HP 2012 90W Docking Station


HP 2012 90W Docking Station

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Docking station
  • 90 Watt
  • United States
HP 2012 90W Docking Station
  • Docking station
  • 90 Watt
  • United States
  Additional Details
Mfr Part #: A7E32AA#ABA
SHI Part #: 26043613
Category: Docking stations
UNSPSC: 43211602
Manufacturer: HP, Inc.
Product Type: Hardware
General Information
CategoryDocking stations
DescriptionHP 2012 90W Docking Station - Docking station - 90 Watt - United States
ManufacturerHP, Inc.
UNSPSC43211602
Main Specifications
Dimensions & Weight / Depth16.36 cm
Dimensions & Weight / Height6.6 cm
Dimensions & Weight / Weight1.07 kg
Dimensions & Weight / Width26 cm
Header / BrandHP
Header / Country KitsUnited States
Header / LocalizationEnglish
Packaged Quantity1
Service & Support / Type1-year warranty
System / Device Type (AI)Docking station
Compatibility Information
Designed For
  • HP EliteBook 2170p, 8440p Notebook, 8460p Notebook, 8470p Notebook, 8470w Mobile Workstation, 8560p Notebook, 8570p Notebook, 8570w Mobile Workstation, 8740w Mobile Workstation, 8770w Mobile Workstation
  • HP Mobile Thin Client mt40, mt41
  • HP ProBook 6360b, 640 G1 Notebook, 6440b, 645 G1 Notebook, 6450b, 6460b, 6465b, 6470b, 6475b, 650 G1 Notebook, 6540b, 6545b, 655 G1 Notebook, 6550b, 6555b, 6560b, 6570b
Environmental Parameters
Max Operating Temperature35 °C
Min Operating Temperature10 °C
Expansion / Connectivity
Interfaces
  • 4 x SuperSpeed USB 3.0 - 9 pin USB Type A
  • 1 x monitor stand port
  • 1 x parallel - parallel - 25 pin D-Sub (DB-25)
  • 1 x display / video - DVI-Digital - 24+1 pin digital DVI
  • 1 x network - RJ-45
  • 1 x audio / video - DisplayPort - 20 pin DisplayPort
  • 1 x display / video - VGA - 15 pin HD D-Sub (HD-15)
  • 1 x serial - RS-232 - 9 pin D-Sub (DB-9)
  • 1 x audio - line-in - mini-phone 3.5 mm
  • 1 x headphones - output - mini-phone 3.5 mm
  • 1 x mouse - generic - 6 pin mini-DIN (PS/2 style)
  • 1 x keyboard - generic - 6 pin mini-DIN (PS/2 style)
General
Depth16.36 cm
Height6.6 cm
LocalizationEnglish / United States
Product TypeDocking station
Weight1.07 kg
Width26 cm
Manufacturer Warranty
Service & SupportLimited warranty - 1 year
Miscellaneous
FeaturesSecurity lock slot (cable lock sold separately)
Security Slot TypeKensington security slot
Power
Power DevicePower adapter - external
Power Provided90 Watt
Voltage RequiredAC 120/230 V (50/60 Hz)
