UPS 20KVA SMARTRACK US
MSRP$19,453.82
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
UPS 20KVA SMARTRACK US
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $19,453.82 |
| Mfr Part #: | SU20KRT |
| SHI Part #: | 22133742 |
| Category: | Uninterruptible power supplies |
| UNSPSC: | 39121011 |
| Manufacturer: | Eaton |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Uninterruptible power supplies |
| Description | UPS 20KVA SMARTRACK US |
| Manufacturer | Eaton |
| MSRP | $19,453.82 |
| UNSPSC | 39121011 |
| Main Specifications | |
| Dimensions & Weight / Depth | 82.6 cm |
| Header / Brand | Tripp Lite |
| Networking / Remote Management Interface |
|
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 10 |
| Power Device / Power Capacity (VA) | 20000 VA |
| Power Device / UPS Technology | On-line |
| Power Device / Voltage Required | AC 200/208/220/230/240 V |
| Product Type | Power array |
| Service & Support / Type | 2-year warranty |
| Battery | |
| Recharge Time | 8 hours |
| Run Time (Up To) |
|
| Dimensions & Weight | |
| Depth | 82.6 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 129 cm |
| Shipping Height | 91.4 cm |
| Shipping Weight | 272 kg |
| Shipping Width | 102 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 60 dBA |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Device Type | Power array - external |
| Height (Rack Units) | 12U |
| Rack Size | 19" |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 2 years |
| Miscellaneous | |
| Cables Included |
|
| Compliant Standards | CSA, IEC 61000-4-5, UL 1778, RoHS, FCC Part 15 A |
| Equipment Protection Value | 250000 US Dollars |
| Features | Audible alarm, LED indicators, noise filtering, overvoltage protection, built-in bypass switch, undervoltage protection, cold-start function, cooling fan, automatic shut down |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Remote Management Protocol | SNMP, HTTP |
| Power Device | |
| Circuit Protection | Circuit breaker |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x hardwire |
| Input Voltage | AC 200/208/220/230/240 V |
| Output Voltage | AC 200/208/220/230/240 V ± 2% |
| Output Waveform | Sinewave |
| Power Capacity | 18 kW / 20000 VA |
| Power Capacity (of Single Unit) | 10000 VA |
| Power Output Connectors Details |
|
| Power Redundancy | Yes |
| Power Redundancy Scheme | N+1 |
| Surge Suppression | Yes |
| UPS Technology | On-line |
| Software / System Requirements | |
| Software Included | TrippLite PowerAlert |
