APC Smart-UPS 750 - UPS
MSRP$697.00
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
APC Smart-UPS 750 - UPS
- AC 230 V
- 500 Watt
- 750 VA
- USB
- 6 output connector(s)
| Additional Details | |
|---|---|
| Price: | |
| MSRP: | $697.00 |
| Mfr Part #: | SUA750IX38 |
| SHI Part #: | 16843837 |
| Category: | Rechargeable batteries |
| UNSPSC: | 26111701 |
| Manufacturer: | APC by Schneider Electric |
| Product Type: | Hardware |
Audio/Video Cables
- 2 m
- for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
MSRP $40.00
$32.00
- 4.57 m
- for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
MSRP $60.00
$49.00
Control/Interface Boards
- System bus extender
- for P/N: G3H10K3IM6X710, G3H10K3IM9X710, SRC1KI, SYA8K16PX798, SYA8K16PXRX798, SYA8K8PX798
MSRP $593.00
$452.00
| General Information | |
|---|---|
| Category | Rechargeable batteries |
| Description | APC Smart-UPS 750 - UPS - AC 230 V - 500 Watt - 750 VA - USB - 6 output connector(s) |
| Manufacturer | APC by Schneider Electric |
| MSRP | $697.00 |
| UNSPSC | 26111701 |
| Main Specifications | |
| Dimensions & Weight / Depth | 35.8 cm |
| Dimensions & Weight / Height | 15.7 cm |
| Dimensions & Weight / Weight | 13.2 kg |
| Dimensions & Weight / Width | 13.7 cm |
| General / Subcategory | UPS |
| Header / Brand | APC |
| Miscellaneous / Product Color | Black |
| Networking / Remote Management Interface | USB |
| Packaged Quantity | 1 |
| Power Device / Form Factor | External |
| Power Device / Output Connector Qty | 6 |
| Power Device / Power Capacity (VA) | 750 VA |
| Power Device / UPS Technology | Line interactive |
| Power Device / Voltage Required | AC 230 V |
| Product Type | UPS |
| Battery | |
| Quantity | 1 |
| Recharge Time | 3 hours |
| Run Time (Up To) | 4.8 min at full load |
| Technology | Lead acid |
| Dimensions & Weight | |
| Depth | 35.8 cm |
| Height | 15.7 cm |
| Weight | 13.2 kg |
| Width | 13.7 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 49.5 cm |
| Shipping Height | 27.9 cm |
| Shipping Weight | 14.6 kg |
| Shipping Width | 27.3 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 95% |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 55 dBA |
| Expansion / Connectivity | |
| Expansion Slots | 1 (total) / 1 (free) x SmartSlot |
| Interfaces | 1 x management (USB) - 4 pin USB Type B |
| General | |
| Battery Enclosure Type | Internal |
| Color | Black |
| Device Type | UPS - external |
| Miscellaneous | |
| Cables Included | USB cable |
| Compliant Standards | UL, C-Tick, GOST, UL 1449, VDE, IEC 60950, EN 50091-2, EN 50091-1 |
| Features | Audible alarm, LED indicators |
| Networking | |
| Remote Management Interface | USB |
| Power Device | |
| Frequency Provided | 50/60 Hz |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power IEC 60320 C14 |
| Input Voltage | AC 230 V |
| Input Voltage Range | AC 160 - 286 V |
| Input Voltage Range (Adjustable) | AC 151 - 302 V |
| Output Voltage | AC 220/230/240 V ± 5% - 50/60 Hz |
| Output Waveform | Sinewave |
| Power Capacity | 500 Watt / 750 VA |
| Power Output Connectors Details | 6 x power IEC 60320 C13 |
| Surge Energy Rating | 340 Joules |
| Surge Suppression | Yes |
| UPS Technology | Line interactive |
| Software / System Requirements | |
| Software Included | Drivers & Utilities |
