HP Workstation Z4 G4
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Want your tech today, but need time to pay?
Easy, flexible financing available with
HP Workstation Z4 G4
- MT
- 4U
- 1 x Xeon W-2223 / 3.6 GHz
- vPro
- RAM 8 GB
- HDD 1 TB
- DVD-Writer
- Quadro P2200
- GigE
- Win 10 Pro 64-bit
- monitor: none
- keyboard: US
- Smart Buy
| Additional Details | |
|---|---|
| Mfr Part #: | 9VB25UT#ABA |
| SHI Part #: | 39551238 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
Audio/Video Cables
- 19 cm
- for Elite 600 G9, 800 G9, t655; EliteDesk 80X G8; Pro t550; ProOne 440 G9; Workstation Z2 G9
- USB cable
- USB (F)
- for Workstation Z2 G4, Z230, Z240, Z4 G4, Z420, Z440, Z6 G4, Z620, Z640, Z840; ZCentral 4R
Network Interface Cards
- PCIe 3.0 x4
- 10Gb Ethernet x 2
- for Workstation Z2 G4, Z2 G5, Z4 G4, Z6 G4, Z8 G4; ZCentral 4R
- PCIe 2.1 x4 low profile
- Gigabit Ethernet x 4
- for Workstation Z2 G4, Z2 G5, Z2 G8, Z2 G9, Z4 G4, Z6 G4, Z8 G4
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | HP Workstation Z4 G4 - MT - 4U - 1 x Xeon W-2223 / 3.6 GHz - vPro - RAM 8 GB - HDD 1 TB - DVD-Writer - Quadro P2200 - GigE - Win 10 Pro 64-bit - monitor: none - keyboard: US - Smart Buy |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211507 |
| Main Specifications | |
| A/V Interface Type | PCI Express 3.0 x16 |
| Chassis / Form Factor | Tower |
| Dimensions & Weight / Depth | 44.5 cm |
| Dimensions & Weight / Height | 38.6 cm |
| Dimensions & Weight / Weight | 11.3 kg |
| Dimensions & Weight / Width | 16.9 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 1 TB |
| Hard Drive / Interface | Serial ATA-600 |
| Hard Drive / Interface Type | Serial ATA-600 |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel C422 |
| Mainboard / Processor Socket | LGA2066 Socket |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Optical Storage / Drive Type | DVD-Writer |
| Optical Storage / Type | DVD-Writer |
| OS Provided / Type | Windows 10 Pro 64-bit Edition |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.6 GHz |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | Quad-Core |
| Processor / Processor Number | W-2223 |
| Processor / Type | Xeon W |
| RAM / Data Integrity Check | ECC |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 2666 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 1 TB |
| System / Platform Technology | Intel vPro Platform |
| System / Type | Workstation |
| Video Memory / Technology | GDDR5X SDRAM |
| Video Output / Graphics Processor | NVIDIA Quadro P2200 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Cache Memory | |
| Cache Per Processor | 8.25 MB |
| Installed Size | 8.25 MB |
| Dimensions & Weight | |
| Depth | 44.5 cm |
| Height | 38.6 cm |
| Weight | 11.3 kg |
| Width | 16.9 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 56.3 cm |
| Shipping Height | 57.2 cm |
| Shipping Width | 31.4 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Bays |
|
| Interfaces |
|
| Slots |
|
| General | |
| Color | Black |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | MT - 4U |
| Type | Workstation |
| Graphics Controller | |
| Graphics Processor | NVIDIA Quadro P2200 |
| Interface Type | PCIe 3.0 x16 |
| Video Interfaces | DisplayPort |
| Video Memory | 5 GB GDDR5X SDRAM |
| Hard Drive | |
| Capacity | 1 x 1 TB |
| Interface Type | SATA 6Gb/s |
| Spindle Speed | 7200 rpm |
| Type | HDD |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Keyboard Name | HP USB Business Slim Keyboard |
| Localization & Layout | US |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years - on-site |
| Miscellaneous | |
| Compliant Standards | RoHS, WEEE, Common Criteria EAL4+, ACPI 5.0, low halogen |
| Manufacturer Selling Program | HP Smart Buy |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Technology | Optical |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet Controller | Intel I219-LM, I210-AT |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), PXE support |
| Operating System / Software | |
| OS Provided | Windows 10 Pro 64-bit Edition English |
| Optical Storage | |
| Type | DVD-Writer - SATA |
| Power | |
| 80 PLUS Certification | 80 PLUS |
| Device Type | Power supply |
| Efficiency | 90% |
| Power Factor Correction | Yes (active) |
| Power Provided | 750 Watt |
| Voltage Required | AC 120/230 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel C422 |
| Clock Speed | 3.6 GHz |
| CPU | Intel Xeon W W-2223 |
| CPU Qty | 1 |
| CPU Socket | LGA2066 Socket |
| Max CPU Qty | 1 |
| Max Turbo Speed | 3.9 GHz |
| Number of Cores | Quad-Core |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2 |
| RAM | |
| Configuration Features | 1 x 8 GB |
| Effective Memory Speed | 2666 MHz |
| Features | Registered |
| Form Factor | DIMM 288-pin |
| Installed Size | 8 GB (installed) / 512 GB (max) |
| Rated Memory Speed | 2933 MHz |
| Slots | 8 (total) / 7 (empty) |
| Technology | DDR4 SDRAM - ECC |
| Storage Controller | |
| Channel Qty | 6 |
| Controller Interface Type | SATA 6Gb/s |
| RAID Level | RAID 0, RAID 1, RAID 5, RAID 10 |
| Type | 1 x RAID |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| EPEAT Compliant | EPEAT Gold |
| TCO Certified | TCO Certified Desktops 9 |
