Hardware Computers and Tablets Desktops and Workstations

Desktops and Workstations

HP Workstation Z2 G9

Mfr Part #:

Copied To Clipboard

Click To Copy

SHI Part #:

Copied To Clipboard

Click To Copy

Quick Details
Tower 4U 1 x Core i7 i7-14700 / up to 5.4 GHz RAM 32 GB SSD 1 TB HP Z Turbo Drive, NVMe, TLC

HP Workstation Z2 G9

Tower 4U
1 x Core i7 i7-14700 / up to 5.4 GHz
RAM 32 GB
SSD 1 TB
HP Z Turbo Drive, NVMe, TLC
RTX A1000
Gigabit Ethernet
Win 11 Pro
monitor: none
keyboard: US
black
Smart Buy
with HP Wolf Pro Security Edition (1 year)

Additional Details
Mfr Part #:	B29Y9UT#ABA
SHI Part #:	48976623
Category:	Desktop computers
UNSPSC:	43211507
Manufacturer:	HP, Inc.
Product Type:	Hardware

Keyboards and Keypads

HP Desktop 320MK - Keyboard and mouse set

USB
US
Smart Buy
for Chromebook 11 G9, 14 G7; Chromebook x360; Elite x2; EliteBook 83X G8, 840, 84X G8, 85X G8

HP Desktop 320K - Keyboard

USB
US
Smart Buy
for HP 470 G8; Chromebook 11 G9, 14 G7; Chromebook x360; EliteBook 840; ProBook x360

HP Desktop 320K - Keyboard

US
for HP 470 G8; Chromebook 11 G9, 14 G7; Chromebook x360; EliteBook 840; ProBook x360

Mice and Trackballs

HP 125 - Mouse - wired

USB
black
promo

HP 125 - Mouse - wired

USB
black

Monitors and Displays

HP 524pf - Series 5 Pro

LED monitor
24" (23.8" viewable)
1920 x 1080 Full HD (1080p) @ 100 Hz
IPS
350 cd/m²
1500:1

HP 324pf - Series 3 Pro

LED monitor
24" (23.8" viewable)
1920 x 1080 Full HD (1080p) @ 100 Hz
IPS
250 cd/m²
1000:1

HP E24 G5 - E-Series

LED monitor
23.8"
1920 x 1080 Full HD (1080p) @ 75 Hz
IPS
250 cd/m²
1000:1

General Information
Category	Desktop computers
Description	HP Workstation Z2 G9 - Tower 4U - 1 x Core i7 i7-14700 / up to 5.4 GHz - RAM 32 GB - SSD 1 TB - HP Z Turbo Drive, NVMe, TLC - RTX A1000 - Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: US - black - Smart Buy - with HP Wolf Pro Security Edition (1 year)
Manufacturer	HP, Inc.
UNSPSC	43211507
Main Specifications
Chassis / Form Factor	Tower
Dimensions & Weight / Depth	38.5 cm
Dimensions & Weight / Height	35.6 cm
Dimensions & Weight / Weight	7.2 kg
Dimensions & Weight / Width	16.9 cm
Display / Type	None.
Hard Drive / Capacity	1 TB
Hard Drive / Interface	PCI Express 4.0
Hard Drive / Interface Type	PCI Express 4.0
Header / Brand	HP
Header / Country Kits	United States
Header / Localization	English
Mainboard / Chipset Type	Intel W680
Mainboard / Processor Socket	LGA1700 Socket
Miscellaneous / Product Color	Black
Networking / Data Link Protocol	Ethernet Fast Ethernet Gigabit Ethernet
Optical Storage / Drive Type	No optical drive
Optical Storage / Type	None
OS Provided / Type	Windows 11 Pro
Packaged Quantity	1
Processor / Clock Speed	2.1 GHz
Processor / Generation	14
Processor / Manufacturer	Intel
Processor / Number of Cores	20-core
Processor / Processor Number	I7-14700
Processor / Type	Core i7
RAM / Data Integrity Check	Non-ECC
RAM / Form Factor	DIMM 288-pin
RAM / Memory Speed	2400 MHz
RAM / Technology	DDR5 SDRAM
System / Hard Drive Capacity	1 TB
System / Type	Workstation
Video Memory / Technology	GDDR6 SDRAM
Video Output / Graphics Processor	NVIDIA RTX A1000 / Intel UHD Graphics 770
Audio Output
Compliant Standards	High Definition Audio
Cache Memory
Cache Per Processor	33 MB
Installed Size	L3 cache - 33 MB
Dimensions & Weight
Depth	38.5 cm
Height	35.6 cm
Weight	7.2 kg
Width	16.9 cm
Dimensions & Weight (Shipping)
Shipping Depth	49 cm
Shipping Height	51.8 cm
Shipping Width	29.5 cm
Environmental Parameters
Humidity Range Operating	10 - 85% RH (non-condensing)
Max Operating Temperature	35 °C
Min Operating Temperature	5 °C
Expansion / Connectivity
Bays	1 (total) / 1 (free) x external 5.25" 1 (total) / 1 (free) x external 5.25" Slim Line 2 (total) / 2 (free) x internal 3.5" 1 (total) / 1 (free) x internal 2.5"
Interfaces	1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) 1 x audio line-in 1 x audio line-out 2 x DisplayPort 1.4 1 x LAN (Gigabit Ethernet) 1 x USB 3.2 Gen 1 3 x USB 2.0 - Type A
Slots	1 (total) / 0 (free) x PCIe 5.0 x16 1 (total) / 1 (free) x PCIe 3.0 x4 (x1 mode) 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) 1 (total) / 1 (free) x PCIe 3.0 x4 3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode) 1 (total) / 1 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
General
Bundled with	HP Wolf Pro Security Edition (1 year)
Color	Black
Embedded Security	Trusted Platform Module (TPM 2.0) Security Chip
Localization	Language: English / region: United States
Product Form Factor	Tower - 4U
Sensors	HP Tamper Lock
Type	Workstation
Graphics Controller
Graphics Processor	NVIDIA RTX A1000 / Intel UHD Graphics 770
Multi-GPU Configuration	1 single GPU card / integrated GPU
Video Interfaces	DisplayPort
Video Memory	8 GB GDDR6 SDRAM
Hard Drive
Capacity	1 x 1 TB
Features	HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Interface Type	PCI Express 4.0
Type	SSD - M.2 2280
Input Device
Type	Mouse, keyboard
Keyboard
Keyboard Name	HP 320K
Localization & Layout	US
Miscellaneous
Compliant Standards	RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen
Manufacturer Selling Program	HP Smart Buy
Security Slot Type	Kensington security slot
Theft/Intrusion Protection	Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Monitor
Monitor Type	None.
Mouse
Mouse Name	HP 320M
Networking
Data Link Protocol	Ethernet, Fast Ethernet, Gigabit Ethernet
Ethernet Controller	Intel I219-LM
Features	Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 16
Operating System / Software
OS Provided	Windows 11 Pro English
Software	HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7
Optical Storage
Type	No optical drive
Power
Device Type	Power supply
Efficiency	90%
Power Factor Correction	Yes (active)
Power Provided	450 Watt
Voltage Required	AC 90-269 V (50/60 Hz)
Processor / Chipset
Chipset Type	Intel W680
Clock Speed	2.1 GHz (P-core) / 1.5 GHz (E-core)
CPU	Intel Core i7 (14th Gen) i7-14700
CPU Qty	1
CPU Socket	LGA1700 Socket
CPU Upgradability	Upgradable
L2 cache	28 MB
Max CPU Qty	1
Max Turbo Speed	5.4 GHz (P-core) / 4.2 GHz (E-core)
Number of Cores	20-core
Processor Main Features	Intel Turbo Boost Technology
RAM
Configuration Features	2 x 16 GB
Effective Memory Speed	2400 MHz
Features	Unbuffered, dual channel memory architecture
Form Factor	DIMM 288-pin
Installed Size	32 GB (installed) / 128 GB (max)
Rated Memory Speed	2400 MHz
Slots	4 (total) / 2 (empty)
Technology	DDR5 SDRAM - non-ECC
Storage Controller
Channel Qty	4
Controller Interface Type	SATA 6Gb/s
RAID Level	RAID 0, RAID 1
Type	1 x SATA
Sustainability Information
ENERGY STAR Certified	Yes
