1161R HPG5 NEMA 1.5KVA 120/12
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
1161R HPG5 NEMA 1.5KVA 120/12
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | Q1L88A |
| SHI Part #: | 47418761 |
| Category: | Power conditioning equipment |
| UNSPSC: | 39121000 |
| Manufacturer: | Eaton |
| Product Type: | Other |
| Product Line: | Tripp Lite |
| General Information | |
|---|---|
| Category | Power conditioning equipment |
| Description | 1161R HPG5 NEMA 1.5KVA 120/12 |
| Manufacturer | Eaton |
| MSRP | $364.68 |
| UNSPSC | 39121000 |
| Main Specifications | |
| Battery | |
| Features | Maintenance free, sealed |
| Recharge Time | 24 hours |
| Run Time (Up To) |
|
| Technology | Lead acid |
| Voltage Provided | 36 V |
| Dimensions & Weight | |
| Depth | 55.4 cm |
| Height | 4.3 cm |
| Weight | 19.72 kg |
| Width | 43.8 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 78 cm |
| Shipping Height | 15.5 cm |
| Shipping Weight | 24.7 kg |
| Shipping Width | 58 cm |
| Environmental Parameters | |
| Humidity Range Operating | 0 - 90% (non-condensing) |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | 0 °C |
| Sound Emission | 45 dBA |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Device Type | UPS - rack-mountable |
| Height (Rack Units) | 1U |
| Localization | North America |
| Manufacturer Warranty | |
| Service & Support |
|
| Miscellaneous | |
| Cables Included |
|
| Compliant Standards | UL, cUL, TUV, C-Tick, EAC, VCCI Class B, GS, KC, EK, BSMI, BIS, UL 1778, UL 60950, CSA 22.2, CB, IEC 62040-1, IEC 60950-1, EN 60950-1, EN 62040-1, EN 61000-3-2, EN 61000-3-3, CISPR 22, FCC CFR47 Part 15, EN 50091-2, EN55024, IEC 61000-4-2, IEC 61000-4-6, IEC 61000-4-11, ANSI C62.41 |
| Equipment Protection Value | 250000 US Dollars |
| Features | VRLA battery support, LCD display |
| Included Accessories | Rack mounting rails |
| Rack Mounting Kit | Included |
| Networking | |
| Remote Management Interface | RS-232, USB |
| Power Device | |
| Efficiency | 92% |
| Frequency Required | 50/60 Hz |
| Input Connectors | 1 x power NEMA 5-15P |
| Input Voltage | AC 100/120-125 V |
| Input Wiring | 1-phase |
| Output Waveform | Sinewave |
| Power Capacity | 1920 Watt / 1920 VA |
| Power Output Connectors Details | 5 x power NEMA 5-15R |
| UPS Technology | Line interactive |
| Software / System Requirements | |
| Software Included | HP Power Protector (free download) |
