XPG CORE REACTOR II - Power supply (internal)


$157.00
XPG CORE REACTOR II - Power supply (internal)

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • ATX12V 3.0/ EPS12V 2.92
  • 80 PLUS Gold
  • AC 100-240 V
  • 750 Watt
  • active PFC
XPG CORE REACTOR II - Power supply (internal)
  • ATX12V 3.0/ EPS12V 2.92
  • 80 PLUS Gold
  • AC 100-240 V
  • 750 Watt
  • active PFC
  • United States
  • black
  Additional Details
Price: $157.00
Mfr Part #: 75261179
SHI Part #: 46460407
Category: Power supply units
UNSPSC: 39121004
Manufacturer: ADATA
Product Type: Hardware
General Information
CategoryPower supply units
DescriptionXPG CORE REACTOR II - Power supply (internal) - ATX12V 3.0/ EPS12V 2.92 - 80 PLUS Gold - AC 100-240 V - 750 Watt - active PFC - United States - black
ManufacturerADATA
MSRP$129.99
UNSPSC39121004
Main Specifications
Dimensions & Weight / Depth14 cm
Dimensions & Weight / Height8.6 cm
Dimensions & Weight / Weight1.596 kg
Dimensions & Weight / Width15 cm
General / SubcategoryPower supplies
Header / BrandXPG
Header / Country KitsUnited States
Miscellaneous / Product ColorBlack
Packaged Quantity1
Power Device / Form FactorInternal
Power Device / Power Supply CompatibilityPC/Server
Power Device / Voltage RequiredAC 100-240 V
Product TypePower supply
Service & Support / Type10-year warranty
Dimensions & Weight
Depth14 cm
Height8.6 cm
Weight1.596 kg
Width15 cm
Dimensions & Weight (Shipping)
Shipping Weight3.1 kg
Environmental Parameters
Max Operating Temperature50 °C
General
ColorBlack
Device TypePower supply - active Power Factor Correction (PFC) - internal
LocalizationUnited States
PSU Form FactorATX
Specification ComplianceATX12V 3.0/ EPS12V 2.92
Manufacturer Warranty
Service & SupportLimited warranty - 10 years
Miscellaneous
Cables Included
  • Power 24 pin ATX modular cable - external - 65 cm
  • 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section modular cable - external - 65 cm
  • 16-pin 12VHPWR power cable - external - 65 cm
  • 2 x 2x 8 pin PCI Express power with detachable 2 pin section modular cable - external - 65 cm
  • 2 x 8 pin PCI Express power with detachable 2 pin section modular cable - external - 65 cm
  • 2 x 15 pin Serial ATA power modular cable - external
  • 4 pin internal power cable - external
Compliant StandardsTUV, BSMI, NOM, CB, CCC, FCC, S Mark, cTUVus, EAC, RCM, UKCA
Cooling System120 mm fan
FeaturesOverheat protection, overcurrent protection, overvoltage protection, overpower protection, undervoltage protection, short-circuit protection, surge & inrush protection, fluid dynamic bearing cooling fan, no load operation protection, Cybenetics Platinum
MTBF100,000 hours
Power Device
80 PLUS Certification80 PLUS Gold
Frequency Required47 - 63 Hz
Input VoltageAC 100-240 V
Modular Cable ManagementYes
Output Current
  • +3.3V - 22 A
  • +5V - 22 A
  • +12V - 62.5 A
  • -12V - 0.3 A
  • +5VSB - 3 A
Output Voltage+3.3, +5, ±12 V, +5Vsb V
Power Capacity750 Watt
Power Factor (PF)0.99
Power Output Connectors Details
  • 1 x power 24 pin ATX with detachable 4 pin section
  • 2 x power 8 pin EPS12V with detachable 4 pin ATX12V section
  • 1 x 12VHPWR 600 W
  • 6 x 8 pin PCI Express power with detachable 2 pin section
  • 8 x 15 pin Serial ATA power
  • 4 x 4 pin internal power
