HP ZCentral 4R - Rack-mountable 1U
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HP ZCentral 4R - Rack-mountable 1U
- 1 x Xeon W W-2223 / up to 3.9 GHz
- vPro
- RAM 16 GB
- SSD 512 GB
- HP Z Turbo Drive, TLC
- Quadro T400
- Gigabit Ethernet, 10 Gigabit Ethernet
- Win 11 Pro
- monitor: none
- keyboard: US
- black
- Smart Buy
- with HP Wolf Pro Security Edition (1 year)
| Additional Details | |
|---|---|
| Mfr Part #: | 88T77UT#ABA |
| SHI Part #: | 46121628 |
| Category: | Storage device trays or assemblies |
| UNSPSC: | 43201609 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
Audio/Video Cables
- USB, 24 pin USB-C male to Quick Disconnect male
- 1.3 m
- for OMEN 40L by HP GT21-1026nd; Poly DA70, DA75, DA80, DA85-M
- Mini DisplayPort (M) to DisplayPort (F)
- for Elite 800 G9; Workstation Z2 G8, Z2 G9, Z4 G5, Z6 G5; ZBook Fury 15 G8, 16 G9, 17 G8
Control/Interface Boards
- Interface adapter
- M.2
- PCIe 3.0 x4
- for Workstation Z4 G4, Z6 G4, Z8 G4; ZCentral 4R
| General Information | |
|---|---|
| Category | Storage device trays or assemblies |
| Description | HP ZCentral 4R - Rack-mountable 1U - 1 x Xeon W W-2223 / up to 3.9 GHz - vPro - RAM 16 GB - SSD 512 GB - HP Z Turbo Drive, TLC - Quadro T400 - Gigabit Ethernet, 10 Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: US - black - Smart Buy - with HP Wolf Pro Security Edition (1 year) |
| Manufacturer | HP, Inc. |
| UNSPSC | 43201609 |
| Main Specifications | |
| Chassis / Form Factor | Rack-mountable |
| Dimensions & Weight / Depth | 62.5 cm |
| Dimensions & Weight / Height | 4.28 cm |
| Dimensions & Weight / Weight | 10.7 kg |
| Dimensions & Weight / Width | 43.815 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 512 GB |
| Hard Drive / Interface | Serial ATA-600 |
| Hard Drive / Interface Type | Serial ATA-600 |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel C422 |
| Mainboard / Processor Socket | LGA2066 Socket |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 11 Pro |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.6 GHz |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | Quad-Core |
| Processor / Processor Number | W-2223 |
| Processor / Type | Xeon W |
| RAM / Data Integrity Check | ECC |
| RAM / Form Factor | DIMM 288-pin |
| RAM / Memory Speed | 2933 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 512 GB |
| System / Platform Technology | Intel vPro Platform |
| System / Type | Workstation |
| Video Memory / Technology | GDDR6 SDRAM |
| Video Output / Graphics Processor | NVIDIA Quadro T400 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Cache Memory | |
| Cache Per Processor | 8.25 MB |
| Installed Size | L3 cache - 8.25 MB |
| Dimensions & Weight | |
| Depth | 62.5 cm |
| Dimensions & Weight Details | 48.681 cm - 64.57 cm - 4.28 cm - with front bezel |
| Height | 4.28 cm |
| Weight | 10.7 kg |
| Width | 43.815 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 82.5 cm |
| Shipping Height | 18.5 cm |
| Shipping Width | 59 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Bays |
|
| Interfaces |
|
| Slots |
|
| General | |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| Color | Black |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Platform Technology | Intel vPro Platform |
| Product Form Factor | Rack-mountable - 1U |
| Type | Workstation |
| Graphics Controller | |
| Graphics Processor | NVIDIA Quadro T400 |
| Video Interfaces | DisplayPort |
| Video Memory | 4 GB GDDR6 SDRAM |
| Hard Drive | |
| Capacity | 1 x 512 GB |
| Features | HP Z Turbo Drive, triple-level cell (TLC) |
| Interface Type | SATA 6Gb/s |
| Type | SSD |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Keyboard Name | HP 320K |
| Localization & Layout | US |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Miscellaneous | |
| Included Accessories | HP Keyed Cable Lock Kit |
| Manufacturer Selling Program | HP Smart Buy |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately), padlock loop |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Mouse Name | HP 320M |
| Networking | |
| Compliant Standards | DASH 1.1 |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, 10 Gigabit Ethernet |
| Ethernet Controller | Intel I219-LM, Marvel AQtion AQC-107 |
| Ethernet Ports | 1 x 10 Gigabit Ethernet, 1 x Gigabit Ethernet |
| Features | Wake on LAN (WoL), Intel Active Management Technology (AMT) 11, PXE 2.1 support |
| Interface (Bus) Type | PCI Express |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Software | HP Remote Graphics Software, HP Support Assistant, HP Performance Advisor, HP Secure Erase, HP Sure Click, HP Sure Sense, HP ZCentral Remote Boost 2020, HP Sure Recover Gen3, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP MIK for Microsoft SCCM Gen 2, HP Sure Start Gen6 |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power supply |
| Efficiency | 90% |
| Max Supported Qty | 2 |
| Power Factor Correction | Yes (active) |
| Power Provided | 675 Watt |
| Voltage Required | AC 90-269 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel C422 |
| Clock Speed | 3.6 GHz |
| CPU | Intel Xeon W W-2223 |
| CPU Qty | 1 |
| CPU Socket | LGA2066 Socket |
| CPU Upgradability | Upgradable |
| Max CPU Qty | 1 |
| Max Turbo Speed | 3.9 GHz |
| Number of Cores | Quad-Core |
| Processor Main Features | Hyper-Threading Technology, Intel Turbo Boost Technology 2 |
| RAM | |
| Configuration Features | 2 x 8 GB |
| Effective Memory Speed | 2933 MHz |
| Features | Registered |
| Form Factor | DIMM 288-pin |
| Installed Size | 16 GB (installed) / 512 GB (max) |
| Rated Memory Speed | 2933 MHz |
| Slots | 4 (total) / 2 (empty) |
| Technology | DDR4 SDRAM - ECC |
| Storage Controller | |
| Channel Qty | 4 |
| Controller Interface Type | SATA 6Gb/s / PCIe 3.0 x4 (NVMe) |
| RAID Level | RAID 0, RAID 1, RAID 10 |
| Type | 1 x SATA/NVMe |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
