HP Workstation Z2 G9
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HP Workstation Z2 G9
- Mini 5U
- 1 x Core i5 13500 / up to 4.8 GHz
- RAM 16 GB
- SSD 512 GB
- HP Z Turbo Drive, NVMe, TLC
- T400
- Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3
- Win 11 Pro
- monitor: none
- keyboard: US
- Smart Buy
- with HP Wolf Pro Security Edition (1 year)
| Additional Details | |
|---|---|
| Mfr Part #: | 87C14UT#ABA |
| SHI Part #: | 46111025 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
Keyboards and Keypads
- USB
- US
- Smart Buy
- for Chromebook 11 G9, 14 G7; Chromebook x360; Elite x2; EliteBook 83X G8, 840, 84X G8, 85X G8
- US
- for HP 470 G8; Chromebook 11 G9, 14 G7; Chromebook x360; EliteBook 840; ProBook x360
Mice and Trackballs
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | HP Workstation Z2 G9 - Mini 5U - 1 x Core i5 13500 / up to 4.8 GHz - RAM 16 GB - SSD 512 GB - HP Z Turbo Drive, NVMe, TLC - T400 - Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 - Win 11 Pro - monitor: none - keyboard: US - Smart Buy - with HP Wolf Pro Security Edition (1 year) |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211507 |
| Main Specifications | |
| A/V Interface Type | PCI Express 3.0 x16 |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 21.8 cm |
| Dimensions & Weight / Height | 6.9 cm |
| Dimensions & Weight / Weight | 2.4 kg |
| Dimensions & Weight / Width | 21.1 cm |
| Display / Type | None. |
| Hard Drive / Capacity | 512 GB |
| Hard Drive / Interface | PCI Express 4.0 x4 |
| Hard Drive / Interface Type | PCI Express 4.0 x4 |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Mainboard / Chipset Type | Intel W680 |
| Mainboard / Processor Socket | LGA1700 Socket |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 11 Pro |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 2.5 GHz |
| Processor / Generation | 13 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | 14-core |
| Processor / Processor Number | I5-13500 |
| Processor / Type | Core i5 |
| RAM / Data Integrity Check | Non-ECC |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 4800 MHz |
| RAM / Technology | DDR5 SDRAM |
| System / Hard Drive Capacity | 512 GB |
| System / Type | Workstation |
| Video Memory / Technology | GDDR6 SDRAM |
| Video Output / Graphics Processor | NVIDIA T400 / Intel UHD Graphics 770 |
| Audio Output | |
| Compliant Standards | High Definition Audio |
| Cache Memory | |
| Cache Per Processor | 24 MB |
| Installed Size | L3 cache - 24 MB |
| Dimensions & Weight | |
| Depth | 21.8 cm |
| Height | 6.9 cm |
| Weight | 2.4 kg |
| Width | 21.1 cm |
| Dimensions & Weight (Shipping) | |
| Shipping Depth | 49.9 cm |
| Shipping Height | 29.8 cm |
| Shipping Weight | 4.8 kg |
| Shipping Width | 17 cm |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 85% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 5 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| Slots |
|
| General | |
| Bundled with | HP Wolf Pro Security Edition (1 year) |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Localization | Language: English / region: United States |
| Product Form Factor | Mini - 5U |
| Sensors | HP Tamper Lock |
| Type | Workstation |
| Graphics Controller | |
| Bandwidth | 80 GBps |
| Graphics Processor | NVIDIA T400 / Intel UHD Graphics 770 |
| Interface Type | PCIe 3.0 x16 |
| Multi-GPU Configuration | 1 single GPU card / integrated GPU |
| Video Interfaces | DisplayPort |
| Video Memory | 4 GB GDDR6 SDRAM |
| Hard Drive | |
| Capacity | 1 x 512 GB |
| Features | HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC) |
| Interface Type | PCI Express 4.0 x4 |
| Type | SSD - M.2 2280 |
| Input Device | |
| Type | Mouse, keyboard |
| Keyboard | |
| Interface | USB |
| Keyboard Name | HP 320K |
| Localization & Layout | US |
| Miscellaneous | |
| Compliant Standards | RoHS, FIPS 140-2, WEEE, CECP, low halogen |
| Manufacturer Selling Program | HP Smart Buy |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Monitor | |
| Monitor Type | None. |
| Mouse | |
| Interface | USB |
| Mouse Name | HP 320M |
| Networking | |
| Compliant Standards | IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.3 |
| Ethernet Controller | Intel I219-LM |
| Features | Wake on LAN (WoL), auto-uplink (auto MDI/MDI-X), MU-MIMO Support, PXE 2.1 support, dual stream (2x2), Intel Active Management Technology (AMT) 16 |
| Interface (Bus) Type | M.2 2230 (CNVi) |
| Wireless LAN Supported | Yes |
| Wireless NIC | Intel Wi-Fi 6E AX 211 |
| Operating System / Software | |
| OS Provided | Windows 11 Pro English |
| Software | HP Support Assistant, HP Performance Advisor, Windows Defender, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Config Utility, HP Image Assistant, HP Documentation, HP PC Hardware Diagnostics, HP System Software Manager, HP Notifications, Power On Authentication, HP Privacy Settings, HP Cloud Recovery, HP QuickDrop, HP BIOSphere Gen6, HP Desktop Support Utility, myHP, Touchpoint Customizer for Commercial, HP Easy Clean |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Efficiency | 90% |
| Power Factor Correction | Yes |
| Power Provided | 280 Watt |
| Voltage Required | AC 115/230 V (50/60 Hz) |
| Processor / Chipset | |
| Chipset Type | Intel W680 |
| Clock Speed | 2.5 GHz (P-core) / 1.8 GHz (E-core) |
| CPU | Intel Core i5 (13th Gen) 13500 |
| CPU Qty | 1 |
| CPU Socket | LGA1700 Socket |
| CPU Upgradability | Upgradable |
| L2 cache | 11.5 MB |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.8 GHz (P-core) / 3.5 GHz (E-core) |
| Number of Cores | 14-core |
| Processor Main Features | Intel Turbo Boost Technology |
| RAM | |
| Configuration Features | 1 x 16 GB |
| Effective Memory Speed | 4800 MHz |
| Features | Dual channel memory architecture |
| Form Factor | SO-DIMM 260-pin |
| Installed Size | 16 GB (installed) / 64 GB (max) |
| Rated Memory Speed | 4800 MHz |
| Slots | 2 (total) / 1 (empty) |
| Technology | DDR5 SDRAM - non-ECC |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s / PCIe 4.0 x4 (NVMe) |
| RAID Level | RAID 0, RAID 1 |
| Type | 1 x SATA/NVMe |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| EPEAT Compliant | EPEAT Gold |
| TCO Certified | TCO Certified Desktops 9 |
