QNAP QVP-85B - NVR - 16 channels

QNAP QVP-85B - NVR - 16 channels

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • networked
QNAP QVP-85B - NVR - 16 channels
  • networked
  Additional Details
Price: $2,855.00
Mfr Part #: QVP-85B-US
SHI Part #: 46056989
Category: Surveillance video or audio recorders
UNSPSC: 46171621
Manufacturer: QNAP
Product Type: Hardware
General Information
CategorySurveillance video or audio recorders
DescriptionQNAP QVP-85B - NVR - 16 channels - networked
Main Specifications
Dimensions & Weight / Depth28.1 cm
Dimensions & Weight / Height18.8 cm
Dimensions & Weight / Weight7.3 kg
Dimensions & Weight / Width32.9 cm
Header / BrandQNAP
Miscellaneous / Product ColorBlack
Packaged Quantity1
Network Port2.5GBase-T x 2
Other PortsM.2 2280 x 2, USB 3.2 Gen2 Type A x 2, USB 3.2 Gen2 Type C x 2
Video Output PortsHDMI x 1
Dimensions & Weight
Depth28.1 cm
Height18.8 cm
Weight7.3 kg
Width32.9 cm
Environmental Parameters
Humidity Range Operating5 - 95% RH (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Cables IncludedNetwork cable - RJ-45 - RJ-45 - 1 pcs.
Compression FormatH.264
Device TypeNVR
Image Resolution1920x1080
IP Cameras Supported16
Max Supported Video Channels64
OS ProvidedQNAP QVR Pro
Package Content2 heatsinks, 2 x HDD tray keys, 24 screws (for 3.5" HDD), 18 screws (for 2.5" HDD), power cable
Video Channels16
Warranty3 years
Hard Drive
InterfaceSerial ATA
Quantity Supported8
FeaturesWake on LAN (WOL), online RAID capacity expansion, online RAID level migration, 1080p resolution support, built-in hardware transcoding, EXT4 file system, 2+1 fans, built-in buzzer, RAID Hot Spare, schedule on/off, RAID Recovery, Single Disk
Network InterfacesEthernet 2.5GBase-T
Supported ProtocolsTelnet, SSH, Syslog
Power Consumption85.701 Watt
Power Consumption DetailsWith drives fully populated
Voltage100 - 240 V
Security DVR
FeaturesRAID 5 support, RAID 10 support, RAID 1 support, JBOD support, RAID 5 hot spare support, RAID 6 support, RAID 6 hot spare support, RAID 10 hot spare support
Frame Rate (Record)30 fps
Video Server
CPUIntel Core i5
FeaturesLED indicator, on-screen display, Intel UHD Graphics 730, PCIe 4.0 x16 slot, PCIe 4.0 x4 slot
Flash Memory5 GB
