Hardware Computers and Tablets Desktops and Workstations
Add to My Favorites
Desktops and Workstations

DT Research 139M Medical

MSRP$1,508.00
$1,158.00
DT Research 139M Medical
Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Micro PC Core i7 10700T / up to 4.5 GHz
  • RAM 16 GB
  • SSD 512 GB
  • UHD Graphics 630
  • Gigabit Ethernet
DT Research 139M Medical
  • Micro PC Core i7 10700T / up to 4.5 GHz
  • RAM 16 GB
  • SSD 512 GB
  • UHD Graphics 630
  • Gigabit Ethernet
  • Ubuntu
  • monitor: none
  Additional Details
Price: $1,158.00
MSRP: $1,508.00
Mfr Part #: 139M5-U-5A
SHI Part #: 45447512
Category: Desktop computers
UNSPSC: 43211507
Manufacturer: DT Research
Product Type: Hardware
General Information
CategoryDesktop computers
DescriptionDT Research 139M Medical - Micro PC Core i7 10700T / up to 4.5 GHz - RAM 16 GB - SSD 512 GB - UHD Graphics 630 - Gigabit Ethernet - Ubuntu - monitor: none
ManufacturerDT Research
MSRP$1,508.00
UNSPSC43211507
Main Specifications
Chassis / Form FactorUltra small form factor
Dimensions & Weight / Depth23.2 cm
Dimensions & Weight / Height20.2 cm
Dimensions & Weight / Weight2.1 kg
Dimensions & Weight / Width4.35 cm
Display / TypeNone.
Hard Drive / Capacity512 GB
Header / BrandDT Research
Miscellaneous / Product ColorSilver
Networking / Data Link Protocol
  • Ethernet
  • Fast Ethernet
  • Gigabit Ethernet
Optical Storage / Drive TypeNo optical drive
Optical Storage / TypeNone
OS Provided / TypeUbuntu
Packaged Quantity1
Processor / Clock Speed2 GHz
Processor / Generation10
Processor / ManufacturerIntel
Processor / Number of Cores8-core
Processor / Processor NumberI7-10700T
Processor / TypeCore i7
Service & Support / Type3-year warranty
System / Hard Drive Capacity512 GB
System / TypePersonal computer
Video Output / Graphics ProcessorIntel UHD Graphics 630
Cache Memory
Cache Per Processor16 MB
Installed Size16 MB
Dimensions & Weight
Depth23.2 cm
Height20.2 cm
Weight2.1 kg
Width4.35 cm
Environmental Parameters
Humidity Range Operating0 - 90% (non-condensing)
Max Operating Temperature50 °C
Min Operating Temperature-10 °C
Expansion / Connectivity
Interfaces
  • 2 x HDMI (2 front)
  • 1 x DisplayPort (1 front)
  • 1 x audio connector (1 front)
  • 4 x USB 3.0 (2 front, 2 rear)
  • 4 x serial (RS-232) (4 rear)
  • 2 x LAN (Gigabit Ethernet) - RJ-45 (2 rear)
General
Product Form FactorMicro PC
TypePersonal computer
Graphics Controller
Graphics ProcessorIntel UHD Graphics 630
Video InterfacesHDMI, DisplayPort
Hard Drive
Capacity1 x 512 GB
FeaturesRAID 0 support, RAID 1 support
TypeSSD
Manufacturer Warranty
Service & SupportLimited warranty - 3 years
Miscellaneous
Compliant StandardsANSI/AAMI ES60601-1, NIST, IEC 60601-1-2, FCC part 18, FCC Part 15 Class B, EMC, RED, IEC 62368-1, RCM, CCC
Included AccessoriesPower adapter, power cable
Security Slot TypeKensington security slot
Theft/Intrusion ProtectionSecurity lock slot (cable lock sold separately)
VESA Mounting Interface75 x 75 mm, 100 x 100 mm
Monitor
Monitor FeaturesAntimicrobial enclosure, fanless cooling, aluminum enclosure
Monitor TypeNone.
Networking
Data Link ProtocolEthernet, Fast Ethernet, Gigabit Ethernet
Ethernet Ports2 x Gigabit Ethernet
Operating System / Software
OS ProvidedUbuntu
Optical Storage
TypeNo optical drive
Power
Device TypePower adapter
Voltage RequiredAC 100-240 V
Processor / Chipset
Clock Speed2 GHz
CPUIntel Core i7 (10th Gen) 10700T
CPU Qty1
Max CPU Qty1
Max Turbo Speed4.5 GHz
Number of Cores8-core
RAM
Installed Size16 GB (installed) / 64 GB (max)
Slots2 (total)
Storage Controller
RAID LevelRAID 0, RAID 1
