HP Elite Mobile Thin Client mt645 G7
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
HP Elite Mobile Thin Client mt645 G7
- AMD Ryzen 3
- 5425U / up to 4.1 GHz
- Windows 10 IoT Enterprise for Thin Clients 64-bit
- Radeon Graphics
- 8 GB RAM
- 256 GB SSD NVMe
- 14" IPS 1920 x 1080 (Full HD)
- Gigabit Ethernet
- Wi-Fi 6
- kbd: English
| Additional Details | |
|---|---|
| Mfr Part #: | 769N2UT#ABA |
| SHI Part #: | 45384950 |
| Category: | Notebook computers |
| UNSPSC: | 43211503 |
| Manufacturer: | HP, Inc. |
| Product Type: | Hardware |
Laptop Docks and Port Replication
- USB-C
- GigE
- 100 Watt
- United States
- for OMEN 25L by HP; Chromebook x360; ENVY 17, TE01; Pavilion 14, TP01; Pavilion Gaming TG01
- Docking station
- HDMI, 2 x DP, Thunderbolt, USB-C
- 1GbE, 2.5GbE
- 120 Watt
- United States
- for Elite Mobile Thin Client mt645 G7; Pavilion x360 Laptop; Pro x360; ZBook Fury 16 G9
- Docking station
- USB-C / Thunderbolt 4
- HDMI, 2 x DP, Thunderbolt, USB-C
- 1GbE, 2.5GbE
- 280 Watt
- with combo cable
Monitors and Displays
- LED monitor
- 23.8"
- 1920 x 1080 Full HD (1080p) @ 75 Hz
- IPS
- 250 cd/m²
- 1000:1
- E-Series
- LED monitor
- 23.8"
- 1920 x 1080 Full HD (1080p) @ 75 Hz
- IPS
- 300 cd/m²
| General Information | |
|---|---|
| Category | Notebook computers |
| Description | HP Elite Mobile Thin Client mt645 G7 - AMD Ryzen 3 - 5425U / up to 4.1 GHz - Windows 10 IoT Enterprise for Thin Clients 64-bit - Radeon Graphics - 8 GB RAM - 256 GB SSD NVMe - 14" IPS 1920 x 1080 (Full HD) - Gigabit Ethernet - Wi-Fi 6 - kbd: English |
| Manufacturer | HP, Inc. |
| UNSPSC | 43211503 |
| Main Specifications | |
| Audio Input / Type | Dual array microphone |
| Dimensions & Weight / Depth | 21.39 cm |
| Dimensions & Weight / Height | 1.99 cm |
| Dimensions & Weight / Weight | 1.38 kg |
| Dimensions & Weight / Width | 32.19 cm |
| Display / Diagonal Size | 14 in |
| Display / Diagonal Size (metric) | 35.56 cm |
| Display / Native Resolution | 1920 x 1080 |
| Display / Type | LED |
| Display / Widescreen Display | Yes |
| Hard Drive / Capacity | 256 GB |
| Header / Brand | HP |
| Header / Country Kits | United States |
| Header / Localization | English |
| Input Device / Type |
|
| Miscellaneous / Product Color | Silver |
| Networking / Data Link Protocol |
|
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | Windows 10 IoT Enterprise for Thin Clients 64-bit Edition |
| Packaged Quantity | 1 |
| Processor / Manufacturer | AMD |
| Processor / Number of Cores | Quad-Core |
| Processor / Processor Number | 5425U |
| Processor / Type | Ryzen 3 |
| RAM / Form Factor | SO-DIMM 260-pin |
| RAM / Memory Speed | 3200 MHz |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 256 GB |
| System / Notebook Type | Mobile thin client |
| System / Security Devices | Fingerprint reader |
| Video Output / Graphics Processor | AMD Radeon Graphics |
| AC Adapter | |
| Input | AC 110 V |
| Output | 65 Watt, 20 V |
| Audio & Video | |
| Camera | Yes - HD |
| Camera Features | Privacy shutter |
| Codec | Realtek ALC3247-CG |
| Graphics Processor | AMD Radeon Graphics - up to |
| Sound | Stereo speakers, dual array microphone |
| Video Resolutions | 720p |
| Battery | |
| Capacity | 51 Wh |
| Technology | 3-cell lithium ion |
| Communications | |
| Compliant Standards | IEEE 802.11d, IEEE 802.11i, IEEE 802.11h, IEEE 802.11e, IEEE 802.11k, IEEE 802.11r, IEEE 802.11v |
| Features | Dual stream (2x2) |
| Network Interface | Gigabit Ethernet |
| Wireless | 802.11a/b/g/n/ac/ax, Bluetooth 5.2 |
| Wireless Controller | Realtek RTL8852BE - PCI Express Mini Card (M.2) |
| Connections & Expansion | |
| Interfaces Details |
|
| Dimensions & Weight | |
| Dimensions (WxDxH) | 32.19 cm x 21.39 cm x 1.99 cm |
| Weight | 1.38 kg |
| Display | |
| Color Gamut | 45% NTSC |
| Features | Full HD eDP anti-glare, narrow-bezel design |
| Image Brightness | 250 cd/m² |
| Keyboard Name | HP Premium |
| LCD Backlight Technology | WLED backlight |
| Resolution | 1920 x 1080 (Full HD) |
| Type | 14" - IPS |
| V-Sync Rate at Max Res. | 60 Hz |
| Widescreen | Yes |
| Environmental Parameters | |
| Humidity Range Operating | 10 - 90% (non-condensing) |
| Max Operating Temperature | 35 °C |
| Min Operating Temperature | 0 °C |
| Shock Tolerance (non-operating) | 200 g @ 2 ms half-sine |
| Shock Tolerance (operating) | 40 g @ 2 ms half-sine |
| Vibration Tolerance (non-operating) | 3.5 g @ RMS (random) |
| Vibration Tolerance (operating) | 1.043 g @ RMS (random) |
| General | |
| Operating System | Windows 10 IoT Enterprise for Thin Clients 64-bit Edition - English |
| Product Type | Mobile thin client |
| Input | |
| Features | Spill-resistant, multi-touch clickpad, ClickPad with gesture support |
| Keyboard Backlight | Yes |
| Keyboard Layout | English |
| Type | Keyboard, ClickPad |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - parts and labor - 3 years |
| Memory | |
| Empty Slots | 0 |
| Form Factor | SO-DIMM 260-pin |
| Max RAM Supported | 16 GB |
| RAM | 8 GB (2 x 4 GB) |
| Rated Speed | 3200 MHz |
| Slots Qty | 2 |
| Speed | 3200 MHz |
| Technology | DDR4 SDRAM |
| Miscellaneous | |
| Compliant Standards | CSA, UL, VCCI, BSMI, GOST, GS, SABS, IEC 60601-1-2, CCC, EMC, FCC, RoHS, AES-128, WEEE, A-Tick, ICES, EN 60601-1-2, KC, CECP, CIT, low halogen, ICCP, IEEE 802.1x, MIL-STD-810H, WPA-PSK, TKIP, BNCI, WPA, WPA2, WPA3 |
| Features | Power-on password, hardware enforced firmware protection, BIOS protection |
| Included Accessories | Power adapter |
| Localization | Language: English / region: United States |
| Manufacturer Selling Program | HP Smart Buy |
| Security | Trusted Platform Module (TPM 2.0) Security Chip, fingerprint reader |
| Security Slot Type | Kensington nano security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| Processor / Chipset | |
| Cache | L3 - 8 MB |
| CPU | AMD Ryzen 3 5425U / 2.7 GHz |
| Max Turbo Speed | 4.1 GHz |
| Number of Cores | Quad-Core |
| Software | |
| Software Included | Citrix ICA, Microsoft RDP, HP Device Manager, HP Hotkey Support, VMware Horizon View, Microsoft 365, HP BIOS Config Utility, HP Connection Optimizer, HP Cloud Endpoint Manager, HP Write Filter, Microsoft RFX, Azure Virtual Desktop |
| Storage | |
| Main Storage | 256 GB SSD M.2 2280 PCIe 3.0 x4 - NVM Express (NVMe) |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| EOL (kg CO2e) | 0.7 |
| EPEAT Compliant | EPEAT Gold |
| Logistics (kg CO2e) | 10 |
| Manufacturing (kg CO2e) | 113 |
| TCO Certified | - TCO Certified Notebooks 9 |
| Total Carbon w/o Use Phase (kg CO2e) | 160 |
| Use (kg CO2e) | 31 |
