Cradlepoint W-Series 5G Wideband Adapter W4005-GB


MSRP$4,499.00
$4,083.00
Cradlepoint W-Series 5G Wideband Adapter W4005-GB

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
  • Wireless router
  • WWAN
  • 2.5GbE
  • Wi-Fi 6
  • 2.4 GHz
Cradlepoint W-Series 5G Wideband Adapter W4005-GB
  • Wireless router
  • WWAN
  • 2.5GbE
  • Wi-Fi 6
  • 2.4 GHz
  • 3G, 4G, 5G
  • with 3 years NetCloud Branch 5G Adapter Essentials Plan and Advanced Plan
  Additional Details
Price: $4,083.00
MSRP: $4,499.00
Mfr Part #: BEA3-40055GB-GN
SHI Part #: 42821767
Category: Routers
UNSPSC: 43222609
Manufacturer: Cradlepoint
Product Type: Hardware
General Information
CategoryRouters
DescriptionCradlepoint W-Series 5G Wideband Adapter W4005-GB - Wireless router - WWAN - 2.5GbE - Wi-Fi 6 - 2.4 GHz - 3G, 4G, 5G - with 3 years NetCloud Branch 5G Adapter Essentials Plan and Advanced Plan
ManufacturerCradlepoint
MSRP$4,499.00
UNSPSC43222609
Main Specifications
Dimensions & Weight / Depth30 cm
Dimensions & Weight / Height7.9 cm
Dimensions & Weight / Weight5.26 kg
Dimensions & Weight / Width32.3 cm
Header / BrandCradlePoint
Header / Country KitsNorth America
Miscellaneous / Product ColorWhite
Networking / Connectivity Technology
  • Wired
  • Wireless
Networking / Data Link Protocol
  • 2.5 Gigabit Ethernet
  • 802.11ax
  • IEEE 802.11a
  • IEEE 802.11ac
  • IEEE 802.11ax (Wi-Fi 6)
  • IEEE 802.11b
  • IEEE 802.11g
  • IEEE 802.11n
  • LTE
Networking / Form FactorDesktop
Networking / TypeWireless router
Networking / Wireless Protocol802.11a/b/g/n/ac/ax
Packaged Quantity1
Service & Support / TypeLimited lifetime warranty
Antenna
AntennaExternal detachable
Antenna Qty4
Communications
Cellular BandLTE B13, LTE B17, LTE B2, LTE B4, LTE B12, LTE B3, LTE B7, LTE B20, LTE B1, LTE B25, LTE B26, LTE B5, LTE B39, LTE B28, LTE B29, LTE B8, LTE B66, LTE B30, LTE B40, LTE B41, LTE B38, LTE B18, LTE B19, LTE B46, 5G n261, 5G n260, LTE B14, LTE B32, LTE B42, LTE B48, LTE B71, 5G n78, 5G n1, 5G n2, 5G n3, 5G n5, 5G n7, 5G n8, 5G n12, 5G n20, 5G n25, 5G n28, 5G n40, 5G n41, 5G n66, 5G n71, 5G n77, 5G n79, LTE B34, 5G n38, 5G n48
Cellular ProtocolWCDMA, LTE Advanced Pro, 5G NR
Generation3G, 4G, 5G
Max Transfer Rate7.53 Gbps
TypeWireless cellular modem
Dimensions & Weight
Depth30 cm
Height7.9 cm
Weight5.26 kg
Width32.3 cm
Environmental Parameters
Humidity Range Operating0 - 100% (non-condensing)
Max Operating Temperature60 °C
Min Operating Temperature-30 °C
Expansion / Connectivity
Expansion Slots2 (total) / 2 (free) x Mini-SIM
Interfaces
  • WAN / LAN: 1 x 2.5GBase-T (PoE++) - RJ-45
  • Antenna: 4 x N connector
  • WAN / LAN: 1 x 2.5GBase-T - RJ-45
General
Built-in DevicesGPS, GNSS receiver
Bundled Services3 years NetCloud Branch 5G Adapter Essentials Plan and Advanced Plan
Compliant StandardsIEEE 802.3bt, UL, cUL, CB, WEEE, IP67, RoHS3
Connectivity TechnologyWireless, wired
Data Link Protocol2.5 Gigabit Ethernet, IEEE 802.11ax (Wi-Fi 6)
Device TypeWireless router
Enclosure TypeDesktop
FeaturesCloud managed, metal housing, 2x2 MU-MIMO technology, 4x4 MIMO technology, outdoor enclosure
Frequency Band2.4 GHz
Performance
  • Captive modem mode throughput: 2 Gbps
  • IP pass-through mode throughput: 2 Gbps
  • Standard NAT mode throughput: 2 Gbps
Status IndicatorsPower, signal strength, LAN, 4G, Wi-Fi, 5G
Line Properties
Line Coding Format256 QAM
Manufacturer Warranty
Service & SupportLimited warranty - lifetime
Miscellaneous
LocalizationNorth America
