Advantech SRP-FPV241-AE
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
Advantech SRP-FPV241-AE
- Thin client
- regular size
- 1 x Core i3 6100U up to
- RAM 8 GB
- no HDD
- Radeon
- Gigabit Ethernet
- monitor: none
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | SRP-FPV241-AE |
| SHI Part #: | 40299472 |
| Category: | Thin client or diskless workstations |
| UNSPSC: | 43211506 |
| Manufacturer: | Advantech |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Thin client or diskless workstations |
| Description | Advantech SRP-FPV241-AE - Thin client - regular size - 1 x Core i3 6100U up to - RAM 8 GB - no HDD - Radeon - Gigabit Ethernet - monitor: none |
| Manufacturer | Advantech |
| UNSPSC | 43211506 |
| Main Specifications | |
| Chassis / Form Factor | Small form factor |
| Dimensions & Weight / Depth | 14 cm |
| Dimensions & Weight / Height | 7 cm |
| Dimensions & Weight / Weight | 3 kg |
| Dimensions & Weight / Width | 20 cm |
| Display / Type | None. |
| Header / Brand | Advantech |
| Miscellaneous / Product Color | Gray |
| Networking / Data Link Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 2.3 GHz |
| Processor / Generation | 6 |
| Processor / Manufacturer | Intel |
| Processor / Number of Cores | Dual-Core |
| Processor / Processor Number | I3-6100U |
| Processor / Type | Core i3 |
| RAM / Memory Speed | 1866 MHz |
| RAM / Technology | DDR4 SDRAM |
| System / Hard Drive Capacity | 0 GB |
| System / Type | Thin client |
| Video Output / Graphics Processor | AMD Radeon / Intel HD Graphics 520 |
| Cache Memory | |
| Cache Per Processor | 3 MB |
| Installed Size | 3 MB |
| Dimensions & Weight | |
| Depth | 14 cm |
| Height | 7 cm |
| Weight | 3 kg |
| Width | 20 cm |
| Environmental Parameters | |
| Humidity Range Operating | 5 - 85% |
| Max Operating Temperature | 40 °C |
| Min Operating Temperature | -20 °C |
| Expansion / Connectivity | |
| Interfaces |
|
| General | |
| Product Form Factor | Regular size |
| Type | Thin client |
| Graphics Controller | |
| Graphics Processor | AMD Radeon / Intel HD Graphics 520 |
| Max Monitors Supported | 6 |
| Video Interfaces | HDMI, DisplayPort |
| Hard Drive | |
| Type | No HDD |
| Miscellaneous | |
| Compliant Standards | CCC, FCC, IEC 60068-2-27, cULus, IEC 60068-2-64, IP40, WEEE 2002/95/EC |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Compliant Standards | IEEE 802.3u, IEEE 802.1as, IEEE 1588-2008, IEEE 802.1Qav |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet |
| Ethernet Controller | Intel I219, I210-IT |
| Ethernet Ports | 2 x Gigabit Ethernet |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Installed Qty | 0 |
| Max Supported Qty | 1 |
| Power Consumption Operational | 60 Watt |
| Voltage Required | DC 10 - 36 V |
| Processor / Chipset | |
| Clock Speed | 2.3 GHz |
| CPU | Intel Core i3 (6th Gen) 6100U |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Number of Cores | Dual-Core |
| Processor Main Features | Intel Smart Cache |
| RAM | |
| Configuration Features | Provided memory is soldered |
| Effective Memory Speed | 1866 MHz |
| Installed Size | 8 GB |
| Technology | DDR4 SDRAM |
