SMART UPS SRT 10000VA 208V


MSRP$13,690.00
$10,254.00
SMART UPS SRT 10000VA 208V

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
SMART UPS SRT 10000VA 208V
  Additional Details
Price: $10,254.00
MSRP: $13,690.00
Mfr Part #: SRT10KXLT
SHI Part #: 29839967
Category: Rechargeable batteries
UNSPSC: 26111701
Manufacturer: APC by Schneider Electric
Product Type: Hardware

Network Cables

APC Dry Contact I/O Accessory
  • Network adapter kit
  • black
  • for P/N: SMX1500RM2UCNC, SMX750C, SRTL10KRM4UT, SRTL2K2RM1UWNC, SRTL3KRM1UC, SRTL8KRM4UT
MSRP $198.00 $158.00
APC - Battery extension cable
  • 129 V
  • 4.57 m
  • for Smart-UPS SRT 10000VA, 10000VA RM, 8000VA, 8000VA RM
MSRP $604.00 $493.00

Network Interface Cards

APC Network Management Card 3 with PowerChute Network Shutdo
MSRP $538.00 $397.00
APC Network Management Card 3 with PowerChute Network Shutdo
MSRP $846.00 $624.00
General Information
CategoryRechargeable batteries
DescriptionSMART UPS SRT 10000VA 208V
ManufacturerAPC by Schneider Electric
MSRP$13,690.00
UNSPSC26111701
Main Specifications
Dimensions & Weight / Depth71.5 cm
Dimensions & Weight / Height43.2 cm
Dimensions & Weight / Weight111.58 kg
Dimensions & Weight / Width26.3 cm
General / SubcategoryUPS
Header / BrandAPC
Miscellaneous / Product ColorBlack
Networking / Remote Management Interface
  • Ethernet 10/100
  • RS-232
  • USB
Packaged Quantity1
Power Device / Form FactorExternal
Power Device / Output Connector Qty7
Power Device / Power Capacity (VA)10000 VA
Power Device / UPS TechnologyOn-line
Power Device / Voltage RequiredAC 208 V
Product TypeUPS
Service & Support / Type3-year warranty
Battery
FeaturesMaintenance free, sealed, leak-proof
Recharge Time1.5 hours
TechnologyLead acid
Compatibility Information
Designed ForP/N: SRT5KRMTF, SRT5KTF
Dimensions & Weight
Depth71.5 cm
Height43.2 cm
Weight111.58 kg
Width26.3 cm
Dimensions & Weight (Shipping)
Shipping Depth1 m
Shipping Height46.1 cm
Shipping Weight126.55 kg
Shipping Width60 cm
Environmental Parameters
Humidity Range Operating0 - 95% (non-condensing)
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Sound Emission55 dBA
Expansion / Connectivity
Expansion Slots1 (total) / 1 (free) x SmartSlot
Interfaces
  • 1 x management (Ethernet) - RJ-45
  • 1 x management (USB) - 4 pin USB Type B
  • 1 x EPO (emergency power off)
  • 1 x serial - RJ-45
General
ColorBlack
Device TypeUPS - external
Manufacturer Warranty
Service & Support
  • Limited warranty - 3 years
  • Limited warranty - batteries - 2 years
Miscellaneous
Compliant StandardsNOM, UL 1778, RoHS, FCC Part 15 A, REACH, CSA C22.2 No. 107.3, IP20
FeaturesAudible alarm, LCD display
Networking
Remote Management InterfaceEthernet 10/100, RS-232, USB
Power Device
Efficiency98%
Frequency Provided50/60 Hz ± 3Hz
Frequency Required40 - 70 Hz
Input ConnectorsHardwire 3-wire (1PH + N + G)
Input VoltageAC 208 V
Input Voltage RangeAC 160 - 275 V
Input Voltage Range (Adjustable)AC 100 - 275 V
Output VoltageAC 208 V ± 2% - 50/60 Hz
Output WaveformSinewave
Power Capacity10 kW / 10000 VA
Power Output Connectors Details
  • 1 x hardwire 3-wire (1PH + N + G)
  • 4 x power NEMA L6-20
  • 2 x power NEMA L6-30
Surge Energy Rating480 Joules
Surge SuppressionYes
UPS TechnologyOn-line
Sustainability Information
ENERGY STARYes
