SYMMETRA LX 16KVA SCALABLE TO16KVA N+1 EXT RUN TWR 220/230/240V


MSRP$38,115.00
$28,091.00
SYMMETRA LX 16KVA SCALABLE TO16KVA N+1 EXT RUN TWR 220/230/240V

Mfr Part #:
Copied To Clipboard
 Click To Copy
SHI Part #:
Copied To Clipboard
 Click To Copy
Quick Details
SYMMETRA LX 16KVA SCALABLE TO16KVA N+1 EXT RUN TWR 220/230/240V
  Additional Details
Price: $28,091.00
MSRP: $38,115.00
Mfr Part #: SYA16K16IXR
SHI Part #: 14690298
Category: Uninterruptible power supplies
UNSPSC: 39121011
Manufacturer: APC by Schneider Electric
Product Type: Hardware

Audio/Video Cables

APC - serial cable - RJ-45 to DB-9 - 4.57 m
  • 4.57 m
  • for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
MSRP $60.00 $49.00
APC Simple Signaling - serial cable
  • Serial cable
  • for P/N: SRV1KA-TW, SRV1KI-TW, SRV2KA-TW, SRV2KI-TW, SRV3KA-TW, SRV3KI-TW, SRV6KI-TW
MSRP $102.00 $82.00

Control/Interface Boards

APC KVM SUN Server Module - KVM extender
  • KVM extender
  • for P/N: SMX1500RMNCUS, SRT10KXLTW, SRT10RMXLIX806, SRT5KRMXLW-TW, SRT6KXLTUS, SRT6KXLTW
MSRP $129.99 $115.00
APC SmartSlot Expansion Chassis - system bus extender
  • System bus extender
  • for Matrix-UPS
MSRP $181.00 $133.00
General Information
CategoryUninterruptible power supplies
DescriptionSYMMETRA LX 16KVA SCALABLE TO16KVA N+1 EXT RUN TWR 220/230/240V
ManufacturerAPC by Schneider Electric
MSRP$38,115.00
UNSPSC39121011
Main Specifications
Dimensions & Weight / Depth73 cm
Dimensions & Weight / Height152 cm
Dimensions & Weight / Weight504 kg
Dimensions & Weight / Width48 cm
General / SubcategoryUPS
Header / BrandAPC
Miscellaneous / Product Color
  • Black
  • Silver
Packaged Quantity1
Power Device / Form FactorExternal
Power Device / Output Connector Qty1
Power Device / Power Capacity (VA)16000 VA
Power Device / Voltage RequiredAC 220/230/240/380/400/415 V
Product TypePower array
Service & Support / Type2-year warranty
Battery
Quantity9
Run Time (Up To)24.7 min at full load
TechnologyLead acid
Dimensions & Weight
Depth73 cm
Height152 cm
Weight504 kg
Width48 cm
Environmental Parameters
Humidity Range Operating0 - 95%
Max Operating Temperature40 °C
Min Operating Temperature0 °C
Expansion / Connectivity
Expansion Slots1 (free) x SmartSlot
Interfaces1 x management (RS-232) - 9 pin D-Sub (DB-9)
General
ColorBlack, silver
Device TypePower array - external
Manufacturer Warranty
Service & SupportLimited warranty - 2 years
Miscellaneous
Compliant StandardsC-Tick, GOST, EN 60950, VDE, IEC 60950, EN55024, EN55022 Class A, EN 50091-2
Power Device
Frequency Provided47 - 63 Hz
Frequency Required45 - 65 Hz
Input ConnectorsHardwire
Input VoltageAC 220/230/240/380/400/415 V
Input Voltage RangeAC 155/276 - 290/480 V
Output VoltageAC 230/240 V ± 5% - 47 - 63 Hz
Output WaveformSinewave
Power Capacity16000 VA
Power Output Connectors Details1 x hardwire
Supported Battery TechnologyLead acid
