ASUS ExpertCenter PN53 BB5000X1TD-NL
Mfr Part #:
Copied To Clipboard
Click To Copy
SHI Part #:
Copied To Clipboard
Click To Copy
|
Quick Details
|
|---|
|
ASUS ExpertCenter PN53 BB5000X1TD-NL
- Mini PC
- Ryzen 5 6600H / up to 4.5 GHz
- RAM 0 GB
- Radeon 660M
- Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
- no OS
- monitor: none
- black
| Additional Details | |
|---|---|
| Price: | |
| Mfr Part #: | PN53-BB5000X1TD-NL |
| SHI Part #: | 46215934 |
| Category: | Desktop computers |
| UNSPSC: | 43211507 |
| Manufacturer: | ASUS |
| Product Type: | Hardware |
| General Information | |
|---|---|
| Category | Desktop computers |
| Description | ASUS ExpertCenter PN53 BB5000X1TD-NL - Mini PC - Ryzen 5 6600H / up to 4.5 GHz - RAM 0 GB - Radeon 660M - Gigabit Ethernet, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) - no OS - monitor: none - black |
| Manufacturer | ASUS |
| MSRP | $369.00 |
| UNSPSC | 43211507 |
| Main Specifications | |
| Chassis / Form Factor | Ultra small form factor |
| Dimensions & Weight / Depth | 13 cm |
| Dimensions & Weight / Height | 5.8 cm |
| Dimensions & Weight / Weight | 900 g |
| Dimensions & Weight / Width | 12 cm |
| Display / Type | None. |
| Header / Brand | ASUS |
| Miscellaneous / Product Color | Black |
| Networking / Data Link Protocol |
|
| Networking / Wireless LAN Supported | Yes |
| Networking / Wireless Protocol |
|
| Optical Storage / Drive Type | No optical drive |
| Optical Storage / Type | None |
| OS Provided / Type | No operating system |
| Packaged Quantity | 1 |
| Processor / Clock Speed | 3.3 GHz |
| Processor / Manufacturer | AMD |
| Processor / Number of Cores | 6-core |
| Processor / Processor Number | 6600H |
| Processor / Type | Ryzen 5 |
| RAM / Technology | DDR4 SDRAM |
| Service & Support / Type | 3-year warranty |
| System / Hard Drive Capacity | 0 GB |
| System / Type | Personal computer |
| Video Output / Graphics Processor | AMD Radeon 660M |
| Cache Memory | |
| Cache Per Processor | 16 MB |
| Installed Size | L3 cache - 16 MB |
| Dimensions & Weight | |
| Depth | 13 cm |
| Height | 5.8 cm |
| Weight | 900 g |
| Width | 12 cm |
| Expansion / Connectivity | |
| Bays | 1 internal 2.5" |
| Interfaces |
|
| Slots | 2 M.2 Card |
| General | |
| Color | Black |
| Embedded Security | Trusted Platform Module (TPM 2.0) Security Chip |
| Product Form Factor | Mini PC |
| Type | Personal computer |
| Graphics Controller | |
| Graphics Processor | AMD Radeon 660M |
| Video Interfaces | HDMI, DisplayPort |
| Manufacturer Warranty | |
| Service & Support | Limited warranty - 3 years |
| Miscellaneous | |
| Compliant Standards | UL, VCCI, C-Tick, BSMI, CB, CCC, FCC |
| Security Slot Type | Kensington security slot |
| Theft/Intrusion Protection | Security lock slot (cable lock sold separately) |
| VESA Mounting Interface | VESA |
| Monitor | |
| Monitor Type | None. |
| Networking | |
| Data Link Protocol | Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, 2.5 Gigabit Ethernet, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E) |
| Ethernet Controller | Realtek RTL8125B-CG |
| Ethernet Ports | 2.5 Gigabit Ethernet |
| Features | Dual stream (2x2) |
| Wireless LAN Supported | Yes |
| Operating System / Software | |
| OS Provided | No operating system |
| Optical Storage | |
| Type | No optical drive |
| Power | |
| Device Type | Power adapter |
| Power Provided | 120 Watt |
| Processor / Chipset | |
| Clock Speed | 3.3 GHz |
| CPU | AMD Ryzen 5 6600H |
| CPU Qty | 1 |
| Max CPU Qty | 1 |
| Max Turbo Speed | 4.5 GHz |
| Number of Cores | 6-core |
| RAM | |
| Installed Size | 0 GB |
| Storage Controller | |
| Controller Interface Type | SATA 6Gb/s |
| Type | 1 x SATA |
| Sustainability Information | |
| ENERGY STAR Certified | Yes |
| ENERGY STAR Version | 8.0 |
